WLS27CGYRXX3-0570DS24Q Banner Signal Towers
Part#:WLS27CGYRXX3-0570DS24Q
Manufacturer:Banner
Alt. Part#:802068
Product Lifecycle:Active
Get a quick Quote!
WLS27 Multicolor Light Strip; Length: 570 mm; Voltage: 24 V dc; Environmental Rating: IP66; IP67; IP69K; Colors: Green, Yellow, Red; Cascadable; 4-pin M12 Integral QD
About the manufacturer: Banner is one of the manufacturers that offers Signal Towers that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the WLS27CGYRXX3-0570DS24Q Banner price in the box on the right side or send a quick quote.
Product Details
- Weight453.592 g
- Country Of OriginMX
- Power DC
- Connection Integral QD
- Lumens Color 2 1140
- Max Op. Temperature (°C) 50
- Multi-Color Device Single Color On
- Indication Yes
- Animation Option 2 Solid On
- Illuminated Length (LxWxH mm) 570.0
- Feature: Cascade Yes
- Cable Length (m) 9
- Product Size (mm) 27
- Color Option 3 Red
- Physical Dimensions (LxWxH or DxH mm) 27.0 x 642.5
- Feature: Audible No
- Illumination Yes
- Animation Option 1 Solid On
- Color 3 - Wavelength/Color Temp/Coordinates 625 nm
- Primary Window Material Copolyester Diffused
- Mounting Thread No Thread
- Color Option 1 Green
- Color 2 - Wavelength/Color Temp/Coordinates 580 nm
- Environmental Rating IP66; IP67; IP69
- IO Link No
- Power Source DC
- Quick Disconnect Type M12 (Euro)
- Supply Voltage 24 V dc
- Feature: Washdown Rated Yes
- Pro-Editor Compatible (Discrete) No
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Color Technology Standard LED
- Number of Input Pins/Conductors 4
- Min Op. Temperature (°C) -40
- Wireless No
- Housing Style Linear Strip
- Number of Colors / Segments 3
- Color 1 - Wavelength/Color Temp/Coordinates 525 nm
- Max Current Color (mA) 800
- Feature: Chemical Resistant Yes
- Primary Housing Material FDA Copolyester
- Lumens Color 1 800
- Animation Option 3 Solid On
- Storage Temp (°C) -40 to 70
- Modbus RTU No
- Color Option 2 Yellow
- Lumens Color 3 370
- Feature: Hazardous Area No
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
WLS27CGYRXX3-0570DS24Q Description
Banner Engineering WLS27CGYRXX3-0570DS24Q is a task light from the EZ-STATUS series designed for harsh environments. This product features a shatterproof LED strip light with a diffused window, override control, and is capable of cascading. It offers 3-color G/Y/R color pattern LED illumination within a black housing. The supply voltage required is 24Vdc, and it has dimensions of L570mm x D27mm. The material used includes an anodized aluminum inner housing and FDA-grade copolyester outer housing, making the tube 27mm in diameter. It is pre-equipped with a 4-pin M12 Euro-style QD connector for connectivity. The shape is a cylindrical linear strip, offering a high degree of protection with ratings of IP66, IP67, and IP69K. It can operate in ambient air temperatures ranging from -40°C to +50°C and includes 3 x digital inputs (24Vdc) for color control.
Related documents WLS27CGYRXX3-0570DS24Q Specs
