S18LGXXPT Banner Signal Beacons
Part#:S18LGXXPT
Manufacturer:Banner
Alt. Part#:31602
Product Lifecycle:Active
Get a quick Quote!
S18 EZ Light - 18 mm - IP67; Single Color: Green; 10-30 V dc PNP Input; 4-screw Terminal Wiring
About the manufacturer: Banner is one of the manufacturers that offers Signal Beacons that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the S18LGXXPT Banner price in the box on the right side or send a quick quote.
Product Details
- Weight63.50288 g
- Country Of OriginCN
- Product Size (mm) 18
- Max Input Response Time (ms) 1
- Primary Window Material Polycarbonate Diffused
- Number of Colors / Segments 1
- Max Current Color (mA) 25
- Input Type PNP
- Feature: Chemical Resistant No
- Color Option 1 Green
- NEMA Type and UL Type Rating NEMA and UL 4X, 13
- Feature: Quick Disconnect No
- Housing Style Barrel Mount - Flat Window
- Animation Option 1 Solid On
- Modbus RTU No
- Feature: Audible No
- Power Source DC
- Lumens Color 1 4.1
- Feature: Hazardous Area No
- Wireless No
- Cable Length (m) 2
- Supply Voltage 10-30 V dc
- Min Op. Temperature (°C) -40
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Mounting Thread M18 x 1.0
- Number of Input Pins/Conductors 4
- Primary Housing Color Black
- Indication Yes
- Color 1 - Wavelength/Color Temp/Coordinates 525 nm
- Max Op. Temperature (°C) 50
- Pro-Editor Compatible (Discrete) No
- Power DC
- Color Technology Standard LED
- Physical Dimensions (LxWxH or DxH mm) 23.5 x 34.6
- Feature: Washdown Rated Yes
- Primary Housing Material Polycarbonate
- Connection Terminal
- Environmental Rating IP67; IP69
- Multi-Color Device Single Color On
- IO Link No
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
S18LGXXPT Description
Banner Engineering S18LGXXPT, part of the EZ-LIGHT series, is a pilot light designed with a 1-color Green LED illumination. This LED pilot light indicator features a polycarbonate (PC) diffused window and a polycarbonate (PC) base, ensuring durability. It has an 18mm indicator diameter and utilizes a screw-clamp terminal connection for secure installation. The housing is black, complementing various industrial environments. It operates on a supply voltage range of 10Vdc-30Vdc, with a nominal range of 12Vdc-24Vdc, and is designed for flush mounting in an 18mm hole with an M18 thread. The S18LGXXPT can operate in ambient air temperatures ranging from -40°C to +50°C. It boasts a high degree of protection with ratings of IP67, IP69K, NEMA 4X, NEMA 13, UL type 4X, and UL type 13, suitable for challenging conditions. The design features a round protruding window and a threaded cylindrical barrel. It has a current consumption of 25mA and includes 1 x digital input (10-30Vdc; PNP) for color control.
