S18LGXXP Banner Signal Beacons
Part#:S18LGXXP
Manufacturer:Banner
Alt. Part#:20819
Product Lifecycle:Active
In-stock parts: 1
Jun 20, 2025
S18 EZ-LIGHT - 18 mm - IP67; Single Color: Green; 10-30 V dc PNP Input; 4-Wire 2 m Cable
About the manufacturer: Banner is one of the manufacturers that offers Signal Beacons that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the S18LGXXP Banner price in the box on the right side or send a quick quote.
Product Details
- Weight81.64656 g
- Country Of OriginCN
- Power Source DC
- Color Option 1 Green
- Pro-Editor Compatible (Discrete) No
- Number of Input Pins/Conductors 4
- Supply Voltage 10-30 V dc
- Environmental Rating IP67; IP69
- Power DC
- Animation Option 1 Solid On
- Feature: Washdown Rated Yes
- Modbus RTU No
- Indication Yes
- Product Size (mm) 18
- Primary Housing Color Black
- Feature: Chemical Resistant No
- Color 1 - Wavelength/Color Temp/Coordinates 525 nm
- Input Type PNP
- NEMA Type and UL Type Rating NEMA and UL 4X, 13
- Wireless No
- Max Current Color (mA) 25
- Min Op. Temperature (°C) -40
- Primary Window Material Polycarbonate Diffused
- IO Link No
- Mounting Thread M18 x 1.0
- Lumens Color 1 4.1
- Max Input Response Time (ms) 1
- Housing Style Barrel Mount - Flat Window
- Color Technology Standard LED
- Physical Dimensions (LxWxH or DxH mm) 23.5 x 35.7
- Feature: Hazardous Area No
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Connection Cable
- Max Op. Temperature (°C) 50
- Multi-Color Device Single Color On
- Number of Colors / Segments 1
- Primary Housing Material Polycarbonate
- Feature: Audible No
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
S18LGXXP Description
Banner Engineering S18LGXXP, part of the EZ-LIGHT series, is a pilot light designed with a 1-color Green LED illumination. This product features an LED pilot light indicator encased in a polycarbonate (PC) diffused window and base. It has an 18mm indicator diameter and is pre-wired with a 2m / 6.5ft 4-wire cable terminated with bare end flying leads. The housing is black, and it operates on a supply voltage of 10Vdc-30Vdc (12Vdc-24Vdc nom.). The S18LGXXP is designed for flush mounting in an 18mm hole with an M18 thread. It can operate in ambient air temperatures ranging from -40°C to +50°C. This part offers a degree of protection rated at IP67, IP69K, NEMA 4X, NEMA 13, UL type 4X, and UL type 13. The shape is characterized by a round protruding window and a threaded cylindrical barrel. It has a current consumption of 25mA and includes 1 x digital input (10-30Vdc; PNP) for color control.
Related documents S18LGXXP Specs
