Q12RN6LPQ3 Banner Proximity Sensors
Part#:Q12RN6LPQ3
Manufacturer:Banner
Alt. Part#:77112
Product Lifecycle:Active
Get a quick Quote!
WORLD-BEAM Q12 Series: Polarized Retro; Range: 1 m; Input: 10-30 V dc; Output: DO; 1 NPN; 150 mm (6 in) 3-pin M8 Pigtail QD
About the manufacturer: Banner is one of the manufacturers that offers Proximity Sensors that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the Q12RN6LPQ3 Banner price in the box on the right side or send a quick quote.
Product Details
- Weight22.6796 g
- Country Of OriginMX
- Product series / family name WORLD-BEAM series
- Main function Sensor (Photo-electric)
- Functions Polarized photo-electric sensor green LED (power ON) yellow LED (signal)
- Light Color Visible red
- Wavelength 640 nm
- Material thermoplastic housing Glass lns.
- Sub-range name Q12 series
- Design retro-reflective mode
- Connection type Pre-wired with 6" / 150mm pigtail terminated with 3-pin Pico-style M8 connector
- Ambient air temperature for operation -20...+55 °C
- Primary brand Banner Engineering
- Supply voltage (DC) 10Vdc-30Vdc (12Vdc / 24Vdc nom.)
- Shape Rectangular
- Digital outputs 1 x digital output (NPN transistor)
- Order code / Manufacturer SKU 77112
- Sensing distance 1m
- Operating mode Dark-ON
- Compliant with standard(s) cURus CE
- Response time 0.7ms / 0.0007 s
- Degree of protection IP67
- Cable Length (m) 0.15
- Connection Pigtail QD
- Power DC
- Output response time (ms) 0.7
- Lens Material Glass
- Sensing Mode (Detailed) Polarized
- Max Sensing Distance (mm) 1000
- Quick Disconnect Type M8 (Pico)
- Special Feature: Remote Teach No
- Outputs NPN
- Housing Style Rectangular
- Sensing Beam Visible Red LED
- Max Op. Temp. (°C) 55
- Sensing Mode (General) Retroreflective
- Opposed Mode Emitter/Receiver N/A
- Feature: Audible No
- Indicator LEDs
- DeviceNet No
- Feature: Chemical Resistant No
- Feature: Hazardous Area No
- IO Link No
- Special Feature: Water Detection No
- Max Op. Relative Humidity [%] 95% @ 50°C
- Input/Output Discrete
- Sensing Beam Wavelength 640
- IP Rating IP67
- Min Op. Temp. (°C) -20
- Primary Housing Material Thermoplastic
- Power Supply/Supply Voltage 10-30 V dc
- Number of Pins 3
- Operation Dark Operate
- Delay at Power-up (ms) 120
- Adjustments N/A
- Feature: Timing (Hold/Delay) No
- Special Feature: Intrinsically Safe No
- Repeatability (µs) 175
- Barrel Diameter (mm) N/A
- Feature: Encapsulated No
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
Q12RN6LPQ3 Description
Banner Engineering Q12RN6LPQ3 is a polarized photo-electric sensor designed for retro-reflective mode operation. It features a pre-wired 6-inch (150mm) pigtail terminated with a 3-pin Pico-style M8 connector, ensuring compatibility with various installations. This sensor operates within an ambient air temperature range of -20 to +55 degrees Celsius and offers a degree of protection rated at IP67, making it suitable for challenging environments. It requires a supply voltage of 10Vdc to 30Vdc, with 12Vdc and 24Vdc as nominal values. The Q12RN6LPQ3, part of the Q12 series, is housed in a rectangular, thermoplastic casing with a glass lens and is capable of sensing distances up to 1 meter. It emits visible red light at a wavelength of 640 nm and operates in a Dark-ON mode. This sensor provides one digital output via an NPN transistor and boasts a quick response time of 0.7ms (0.0007 seconds).
