Q12RB6FF15 W/30 Banner Electronic Components
Part#:Q12RB6FF15 W/30
Manufacturer:Banner
Product Lifecycle:Active
Get a quick Quote!
WORLD-BEAM Q12 Series: Fixed-Field, Range: 15 mm; Input: 10-30V dc, Output: DO (Dark Operate) Bipolar: 1 NPN; 1 PNP, 9 m (30 ft) Cable
About the manufacturer: Banner is one of the manufacturers that offers Electronic Components that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the Q12RB6FF15 W/30 Banner price in the box on the right side or send a quick quote.
Product Details
- Sensing Beam Visible Red LED
- Power DC
- Sensing Mode (General) Proximity
- Max Sensing Distance (mm) 15
- Output response time (ms) 0.85 ON/OFF
- Special Feature: Intrinsically Safe No
- Special Feature: Water Detection No
- Sensing Beam Wavelength 640
- Lens Material Polycarbonate
- Feature: Audible No
- DeviceNet No
- Delay at Power-up (ms) 120
- Barrel Diameter (mm) N/A
- Repeatability (µs) 175
- Feature: Timing (Hold/Delay) No
- Number of Pins 3
- Feature: Encapsulated No
- IP Rating IP67
- Feature: Hazardous Area No
- Max Op. Relative Humidity [%] 95% @ 50°C
- Feature: Chemical Resistant No
- Adjustments N/A
- IO Link No
- Opposed Mode Emitter/Receiver N/A
- Indicator LEDs
- Sensing Mode (Detailed) Background Suppression (Fixed)
- Cable Length (m) 9
- Small Visible Spot LED
- Primary Housing Material Thermoplastic
- Min Op. Temp. (°C) -20
- Housing Style Rectangular
- Operation Dark Operate
- Connection Cable
- Power Supply/Supply Voltage 10-30 V dc
- Max Op. Temp. (°C) 55
- Input/Output Discrete
- Quick Disconnect Type No QD
- Special Feature: Remote Teach No
- Outputs Bipolar (NPN & PNP)
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
Related documents Q12RB6FF15 W/30 Specs
1-year warranty
