K90LBPQP Banner Signal Beacons

Banner K90LBPQP K90 Series EZ-LIGHT; 1-Color Indicator; Voltage: 12-30 V dc; Environmental Rating: IP67; Input: PNP; Colors: Blue; 150 mm (6 in) 5-pin M12 PVC Pigtail QD
Banner

Part#:K90LBPQP

Manufacturer:Banner

Alt. Part#:92819

Product Lifecycle:Active

Get a quick Quote!

K90 Series EZ-LIGHT; 1-Color Indicator; Voltage: 12-30 V dc; Environmental Rating: IP67; Input: PNP; Colors: Blue; 150 mm (6 in) 5-pin M12 PVC Pigtail QD

About the manufacturer: Banner is one of the manufacturers that offers Signal Beacons that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the K90LBPQP Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight217.72416 g
  • Country Of OriginMX
  • Color Input Control
    Individual (One wire/color, same number of colors as input wires)
  • Wire Selectable Function
    Flashing
  • Input Type
    PNP
  • Feature: Hazardous Area
    No
  • Power Source
    DC
  • Color Option 1
    Blue
  • Physical Dimensions (LxWxH or DxH mm)
    90.0 x 87.0
  • Modbus RTU
    No
  • Housing Style
    Base Mount - Dome Window
  • Color Technology
    Standard LED
  • Max Input Response Time (ms)
    75
  • Wireless
    No
  • Number of Colors / Segments
    1
  • Quick Disconnect Type
    M12 (Euro)
  • Supply Voltage
    12-30 V dc
  • Feature: Chemical Resistant
    No
  • Indication
    Yes
  • Max Current Color (mA)
    475
  • Max Op. Temperature (°C)
    50
  • Mounting Thread
    M30 x 1.5
  • Connection
    Pigtail QD
  • Environmental Rating
    IP67
  • Pro-Editor Compatible (Discrete)
    No
  • Primary Housing Material
    Polycarbonate
  • Animation Option 1
    Solid On
  • Number of Input Pins/Conductors
    5
  • Primary Window Material
    Polycarbonate Diffused
  • Product Size (mm)
    90
  • Lumens Color 1
    55.0
  • NEMA Type and UL Type Rating
    NEMA 4X, 13
  • Power
    DC
  • Color 1 - Wavelength/Color Temp/Coordinates
    470 nm
  • Min Op. Temperature (°C)
    -40
  • Feature: Audible
    No
  • IO Link
    No

Product condition

ORIGINAL PACKAGING

SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging

K90LBPQP Description

Banner Engineering K90LBPQP is a pilot light from the EZ-LIGHT series designed for various signaling applications. This part features a 1-color Blue LED illumination housed in a black casing. The dome window and base are made from polycarbonate (PC), ensuring durability. It is pre-wired with a 2m / 6.5ft 5-wire cable that terminates with bare end flying leads for easy installation. The K90LBPQP operates on a supply voltage of 12Vdc to 30Vdc, with a nominal voltage of 24Vdc, and can be mounted on a surface, base, or pole flush using a 30mm hole with an M30 thread. The dome has a diameter of 90mm / 3-1/2 inches. It is designed to operate in ambient air temperatures ranging from -40°C to +50°C. This part offers a degree of protection rated at IP67, NEMA 4X, and NEMA 13, with a current consumption of 475mA. It also includes 1 x digital input (12-30Vdc; NPN) for color control.

Related documents K90LBPQP Specs

K90LBPQP 181765.pdf

1-year warranty

Get a quick Quote!

Request a quote, and we will send you price and availability within minutes.

Select Qty:

Average response time: 11 minutes

By purchasing this item, you agree to the Terms & Conditions

Quotebeam is NOT an authorized distributor of Banner

Shipping and Delivery Worldwide

calculate costs and time

Secure Payment Processing

with money back guarantee

1 year warranty

on all parts

Responsive Customer Support

we're here to help!

Need more details?

Feel free to chat with us or check our FAQ

Banner Disclaimer:

The product is unused surplus. Quotebeam is not an authorized surplus dealer or affiliate for the Manufacturer of this product. Products may feature older date codes or be from an earlier series than what is currently available from the manufacturer or authorized dealers. Because Quotebeam is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Banner Controls products will have firmware already installed, Quotebeam makes no representation as to whether a Controls product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. Quotebeam also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Banner, its distributors, or any other source. Quotebeam also makes no representations as to your right to install any such firmware on the product. Quotebeam will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.
