DELSEF-40D Banner Cordsets
Part#:DELSEF-40D
Manufacturer:Banner
Alt. Part#:85962
Product Lifecycle:Active
Get a quick Quote!
Cordset: Double Ended LS-Custom to M12; 12-pin Straight Female; 4-pin Straight Female; 0.07 m (0.23 ft) Yellow PVC Jacket; Nickel-Plated Brass Coupling Nut
About the manufacturer: Banner is one of the manufacturers that offers Cordsets that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the DELSEF-40D Banner price in the box on the right side or send a quick quote.
Product Details
- Weight27.21552 g
- Country Of OriginTW
- Number of Contacts 12
- Primary Connector Type LS-Custom
- Coupling Material/Color Custom
- Cable Jacket Color Yellow
- Primary Orientation Straight
- Cable Jacket Material PVC
- Minimum Temp. (°C) -20
- Primary Coupling Method EZS-LS
- Secondary Orientation Straight
- Shield/No Shield No Shield
- Primary AWG 22
- Secondary Gender Female
- Number of Connectors 2
- Maximum Temp. (°C) 55
- Primary Gender Female
- Cordset Length (m) 0.07
- Current Rating (A) 2.0
- Secondary AWG 22
- Trunk Length (m) No Trunk
- Primary Number of Conductors 5
- Secondary Number of Conductors 5
- Connector Body Material/Color PVC Black
- IP Rating IP67
- Secondary Connector Type EURO
- Outside Cable Diameter (mm) 6
- Voltage Rating (V) 60 V ac/75 V dc
- Secondary Coupling Method M12 Single Key
- Oil/Grease Resistant No
- Feature: Hazardous Area No
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
DELSEF-40D Description
Banner Engineering DELSEF-40D is a pre-assembled, double-ended cable designed for automation applications, featuring a nickel-plated brass coupling nut and PVC cable sheathing in yellow. This part includes a 5-pin LS female connector and a 5-pin Euro-style M12 female connector, ensuring compatibility with a variety of devices. The cable has a diameter of 6mm and a length of 70mm. It operates within an ambient air temperature range of -20 to +55°C and offers a degree of protection rated at IP67, making it suitable for environments requiring dust and water resistance. The DELSEF-40D is rated for a voltage of 60Vac and 75Vdc, accommodating diverse electrical requirements.
1-year warranty
