DELSE-81D Banner Cordsets
Part#:DELSE-81D
Manufacturer:Banner
Alt. Part#:86942
Product Lifecycle:Active
Get a quick Quote!
Cordset: Double Ended LS-Custom to M12; 12-pin Straight Female; 8-pin Straight Male; 0.3 m 8x22 Yellow PVC Jacket; PVC Black; Nickel-Plated Brass Coupling Nuts
About the manufacturer: Banner is one of the manufacturers that offers Cordsets that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the DELSE-81D Banner price in the box on the right side or send a quick quote.
Product Details
- Weight40.82328 g
- Country Of OriginTW
- Minimum Temp. (°C) -20
- Primary AWG 22
- Current Rating (A) 2.0
- Number of Connectors 2
- Secondary Orientation Straight
- Trunk Length (m) No Trunk
- Voltage Rating (V) 60 V ac/75 V dc
- Secondary Connector Type EURO
- Connector Body Material/Color PVC Black
- Primary Coupling Method EZS-LS
- Secondary Number of Conductors 8
- Cable Jacket Material PVC
- Primary Orientation Straight
- Feature: Hazardous Area No
- Cordset Length (m) 0.3
- Primary Connector Type LS-Custom
- Secondary Coupling Method M12 Single Key
- Outside Cable Diameter (mm) 6
- Coupling Material/Color Custom
- Primary Gender Female
- Oil/Grease Resistant No
- Cable Jacket Color Yellow
- IP Rating IP67
- Primary Number of Conductors 8
- Number of Contacts 12
- Maximum Temp. (°C) 55
- Secondary AWG 22
- Shield/No Shield No Shield
- Secondary Gender Male
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
DELSE-81D Description
Banner Engineering DELSE-81D is a pre-assembled cable/cordset designed with a double-ended configuration, featuring an 8-pin LS female connector and an 8-pin Euro-style M12 male connector. This part is constructed from nickel-plated brass coupling nut and PVC cable, ensuring durability and resistance to environmental factors. It operates within an ambient air temperature range of -20 to +55°C and offers a degree of protection rated at IP67, making it suitable for various industrial applications. The cable has a diameter of 6mm and a length of 1ft (300mm), with a yellow sheathing for visibility. It is rated for a voltage of 60Vac and 75Vdc, accommodating a wide range of power supply requirements.
1-year warranty
