B-TL70DXN9-Q5 Banner Signal Towers
Part#:B-TL70DXN9-Q5
Manufacturer:Banner
Alt. Part#:94229
Product Lifecycle:Active
In-stock parts: 3
Jun 19, 2025
TL70 Wireless Base Module 900 MHz; Supports 1-3 Modules; Voltage: 12-30 V dc; Environmental Rating: IP65; 5-pin M12 Integral QD; Black Housing
About the manufacturer: Banner is one of the manufacturers that offers Signal Towers that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the B-TL70DXN9-Q5 Banner price in the box on the right side or send a quick quote.
Product Details
- Weight136.0776 g
- Country Of OriginUS
- Indication Yes
- Mounting Thread M30 x 1.5
- Supply Voltage 12-30 V dc
- Primary Housing Color Black
- Max Current Color (mA) 420
- Physical Dimensions (LxWxH or DxH mm) 70.0 x 47.5
- Wireless Radio Frequency 900 MHz
- Housing Style Segment - Base
- Number of Input Pins/Conductors 5
- Feature: Hazardous Area No
- Feature: Chemical Resistant No
- Quick Disconnect Type M12 (Euro)
- Storage Temp (°C) -40 to 70
- Primary Housing Material Polycarbonate
- Color Technology Standard LED
- Max Op. Relative Humidity Non-Condensing (%) 95% @ 50°C
- Wireless Yes
- Power DC
- Input Type PNP
- IO Link No
- Product Size (mm) 70
- Power Source DC
- Min Op. Temperature (°C) -40
- Feature: Quick Disconnect Yes
- Pro-Editor Compatible (Discrete) No
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Max Input Response Time (ms) 180
- Feature: Audible No
- Number of Colors / Segments 1
- Cable Length (m) 0.15
- Environmental Rating IP65
- Modbus RTU No
- Non-Illuminated Yes
- Connection Integral QD
- Max Op. Temperature (°C) 50
- Wireless Network Node
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
B-TL70DXN9-Q5 Description
Banner Engineering B-TL70DXN9-Q5 is a base unit belonging to the Modular SureCross series, designed for SureCross Wireless (900MHz) node base segment/module applications with a black polycarbonate housing. This unit supports 1-4 modules within the SureCross wireless architecture and operates on a supply voltage of 12Vdc-30Vdc, with 24Vdc nominal. It features a cylindrical shape with a diameter of 70mm / 2-3/4" and is pre-equipped with a 5-pin M12 Euro-style QD connector for connectivity. The B-TL70DXN9-Q5 offers an IP65 degree of protection, making it suitable for various environments, and can be mounted on a surface or base pole with an M30 thread. It operates within an ambient air temperature range of -40°C to +50°C and has a current consumption of 420mA.
Related documents B-TL70DXN9-Q5 Specs
This item can ship within 24h!
1-year warranty
$195.80
