12676924 WEG AC Motors
Part#:12676924
Manufacturer:WEG
Product Lifecycle:Discontinued
Get a quick Quote!
Rolled Steel JM Pump High Efficiency 10 HP 2P 213/5JM 3Ph 230/460//190-220/380-415 V 60 Hz IC01 - ODP - Foot-mounted
Check out the 12676924 WEG price in the box on the right side or send a quick quote.
Product Details
- LRC 6.4x(Code G)
- No load current 10.3/5.13 A
- Noise level² 66.0 dB(A)
- Frame 213/5JM
- Rated torque 14.9 ft.lb
- Starting Method Direct On Line
- Number of poles 2
- Frequency 60 Hz
- Moment of inertia (J) 0.3816 sq.ft.lb
- Ambient temperature -20°C to +40°C
- Flange C
- Number of Poles 2
- Design B
- Approx. weight³ 112 lb
- Rated speed 3530 rpm
- Breakdown torque 260 %
- Mounting F-1
- Rated current 24.4/12.2 A
- Locked rotor torque 180 %
- Duty Cycle Cont.(S1)
- Output rating 10 HP
- Slip 1.94 %
- Temperature rise 80 K
- Voltage 230/460//190-220/380-415 V
- Standard NEMA MG-1
- Rated voltage 230/460 V
- Locked rotor time 14s (cold) 8s (hot)
- Rotation¹ Both (CW and CCW)
- Terminal box¹ Left position
- L. R. Amperes 156/78.1 A
- Insulation Class F
- Altitude 1000 m.a.s.l.
- Synchronous speed 3600 rpm
- Output 10 HP (7.5 kW)
- Service factor 1.15
- Enclosure IC01 - ODP
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
