TM241CE24R Schneider Electric Industrial Automation Components
Part#:TM241CE24R
Manufacturer:Schneider Electric
Product Lifecycle:Active
Get a quick Quote!
Schneider Electric TM241CE24R is a CPU unit designed with integrated I/Os, serving as a Programmable Logic Controller (PLC) CPU processor module. It features a PID Run/Stop switch, an industrial SD memory card slot, a backup battery slot, and a Mini-USB connector for programming. The unit is equipped with a terminal clip for locking onto symmetrical rail, supports firmware updates, and facilitates data exchange through NGVL and IEC VAR ACCESS. It includes a web server, SNMP-MIB2 network management, FTP (Client/Server), SNMP (Client/Server), SQL (Client), and an Email library, alongside DHCP Client functionalities for programming, downloading, and monitoring. The connection is established via a removable screw terminal block, 1 x RJ45 connector (RS-232 / RS-485 with +5V supply), and 1 x USB mini-B port. It operates on a supply voltage of 85-264Vac (100-240Vac nominal) and can be mounted on a symmetrical rail or panel. The ambient air temperature for operation ranges from +14 to +131°F (-10 to +55°C), with a memory capacity of 64MB (RAM), 128MB (flash), and 8MB (program size; for application and symbols). It has an IP20 degree of protection and uses Ethernet Modbus TCP for communication. The digital outputs include 6 x digital outputs (2A; relay contact outputs) and 4 x digital outputs (500mA; high-speed transistors; Source), with 14 x digital inputs (24Vdc; Sink/Source; 8 inputs can be used as high-speed HSC counters). The connection capacity allows for 7 x local I.O., 14 x distributed I.O., 7 x Modicon TM3 expansion modules (option for local I.O.), and 14 x Modicon TM3 expansion modules with bus expansion modules (option for remote I.O.), plus Modicon TM2 expansion modules (with restrictions) and 1 x slot for analog I.O. expansion or application cartridge. It is designed for storage in environments with ambient air temperatures ranging from -40 to +158°F (-40 to +70°C) and humidity levels of 5-95% (without condensation). The processing time is 300μs / 0.3 ms for 1k instructions (event and periodic task) and 700μs / 0.7 ms for other instructions, with a hold time of 0.01s (immunity to micro-breaks class PS-2), powered by a dual-core processor.
About the manufacturer: Schneider Electric is one of the manufacturers that offers Industrial Automation Components that you can order at marketplace.quotebeam.com. We provide digital solutions for energy and automation that improve efficiency and support sustainability. Our comprehensive solutions include cutting-edge energy technologies, real-time automation, software, and services for residential, commercial, and industrial settings.
Check out the TM241CE24R Schneider Electric price in the box on the right side or send a quick quote.
Product Details
- Discrete I/O Number 24
- Input Impedance 4.7 kOhm input
- Data Backed Up 128 MB built-in flash memory backup of user programs
- Web Services Web server
- Discrete Input Number 14, discrete input 8 fast input IEC 61131-2 Type 1
- Discrete Input Current 5 mA input
- [Us] Rated Supply Voltage 100...240 V AC
- Discrete Input Voltage 24 V
- Product Or Component Type Logic controller
- Discrete Input Voltage Type DC
- Backup Time 2 years 77 °F (25 °C)
- Height 3.54 in (90 mm)
- Response Time 50 µs turn-on, I0...I13 input
- Realtime Clock With
- Supply Voltage Limits 85…264 V
- Marking CE
- Depth 3.74 in (95 mm)
- Communication Port Protocol Non isolated serial link Modbus master/slave
- Range Of Product Modicon M241
- Discrete Input Logic Sink or source
- Discrete Output Logic Positive logic (source)
- Battery Type BR2032 lithium non-rechargeable 4 year(s)
- Configurable Filtering Time 1 µs fast input
- Supply Serial 1)serial link supply 5 V, <200 mA
- Width 5.91 in (150 mm)
- Voltage State 1 Guaranteed >= 15 V input
- Positioning Functions PTO 4 100 kHz)
- Network Frequency 50/60 Hz
- Data Storage Equipment <= 16 GB SD card optional)
- Sensor Power Supply 24 V DC 400 mA supplied by the controller
- Net Weight 1.17 lb(US) (0.53 kg)
- Voltage State 0 Guaranteed <= 5 V input
- Clock Drift <= 60 s/month 77 °F (25 °C)
- Port Ethernet 10BASE-T/100BASE-TX - 1 copper cable
- Memory Capacity 8 MB program 64 MB system memory RAM
- Maximum Number Of I/O Expansion Module 7 local 14 remote
- Discrete Output Number 6 relay 4 transistor 4 fast output
- Counting Input Number 4 fast input (HSC mode) 200 kHz 14 standard input 1 kHz
- Execution Time For 1 Kinstruction 0.3 ms event and periodic task 0.7 ms other instruction
- Number Of Slave 64 Modbus TCP 16 EtherNet/IP
- Electrical Connection removable screw terminal block for inputs and outputs pitch 5.08 mm) removable screw terminal block for connecting the 24 V DC power supply pitch 5.08 mm)
- Insulation Between supply and internal logic 500 V AC Non-insulated between supply and ground
- Accuracy +/- 0.1 % 0.02…0.1 kHz fast output +/- 1 % 0.1…1 kHz fast output
- Discrete Output Type Relay Transistor
- Reset Time 10 ms automatic reset output 12 s automatic reset fast output
- Cycle Time 10 ms 16 EtherNet/IP 64 ms 64 Modbus TCP
- Discrete Output Voltage 5...125 V DC relay output 5...250 V AC relay output 24 V DC transistor output
- Mounting Support Top hat type TH35-15 rail IEC 60715 Top hat type TH35-7.5 rail IEC 60715 plate or panel with fixing kit
- Maximum Output Frequency 1 kHz transistor output 20 kHz fast output (PWM mode) 100 kHz fast output (PLS mode)
- Output Voltage Limits 125 V DC relay output 30 V DC transistor output 277 V AC relay output
- Control Signal Type A/B 100 kHz fast input (HSC mode) Pulse/direction 200 kHz fast input (HSC mode) Single phase 200 kHz fast input (HSC mode)
- Discrete Output Current 2 A relay output Q4...Q9) 0.1 A fast output (PTO mode) TR0...TR3) 0.5 A transistor output TR0...TR3)
- Transmission Rate 1.2...115.2 kbit/s (115.2 kbit/s by default) 49.21 ft (15 m) RS485 1.2...115.2 kbit/s (115.2 kbit/s by default) 9.84 ft (3 m) RS232 480 Mbit/s 9.84 ft (3 m) USB 10/100 Mbit/s Ethernet
- Protection Type Short-circuit protection transistor output Short-circuit and overload protection with automatic reset transistor output Reverse polarity protection transistor output Without protection relay output
- Application Structure 8 external event tasks 3 cyclic master tasks + 1 freewheeling task 8 event tasks 4 cyclic master tasks
- Maximum Cable Distance Between Devices Unshielded cable <164.04 ft (50 m) input Shielded cable <32.81 ft (10 m) fast input Unshielded cable <164.04 ft (50 m) output Shielded cable <9.84 ft (3 m) fast output
- Integrated Connection Type Non isolated serial link serial 1 RJ45 RS232/RS485 Non isolated serial link serial 2 removable screw terminal block RS485 USB port mini B USB 2.0 Ethernet RJ45
- Surge Withstand 2 kV power lines (AC) common mode EN/IEC 61000-4-5 2 kV relay output common mode EN/IEC 61000-4-5 1 kV shielded cable common mode EN/IEC 61000-4-5 1 kV power lines (AC) differential mode EN/IEC 61000-4-5 1 kV relay output differential
- Maximum Number Of Connections 8 Modbus server 8 SoMachine protocol 10 web server 4 FTP server 16 Ethernet/IP target 8 Modbus client
- Local Signalling for PWR 1 LED (green) for RUN 1 LED (green) for module error (ERR) 1 LED (red) for I/O error (I/O) 1 LED (red) for SD card access (SD) 1 LED (green) for BAT 1 LED (red) for SL1 1 LED (green) for SL2 1 LED (green)<
- Ethernet Services FDR DHCP server via TM4 Ethernet switch network module DHCP client embedded Ethernet port SMS notifications Updating firmware SNMP client/server Programming NGVL Monitoring IEC VAR ACCESS FTP client/server
