SRB402NE 24V Schmersal Electronic Components
Part#:SRB402NE 24V
Manufacturer:Schmersal
Alt. Part#:101178395
Product Lifecycle:Active
Get a quick Quote!
Safety-monitoring modules; Combination (double evaluation); Suitable for the signal processing of outputs with contact sensors; Possibility to connect a non-contact end switch or speed reduction switch; 2 safety contacts, switch-off level 1;2 safety conta
About the manufacturer: Schmersal is one of the manufacturers that offers Electronic Components that you can order at marketplace.quotebeam.com. Schmersal produces a wide range of high-quality switchgears specifically engineered to protect machinery and facilities in industrial automation and the elevator industry.
Check out the SRB402NE 24V Schmersal price in the box on the right side or send a quick quote.
Product Details
- Gross weight 370 g
- Automatic reset function Yes
- Cable section, minimum 0.25 mm²
- Storage and transport temperature, maximum +85 °C
- Rated AC voltage for controls, 60 Hz, minimum 20.4 VAC
- Rated impulse withstand voltage Uimp 4 kV
- Drop-out delay in case of power failure, typically 80 ms
- Switching capacity, minimum 10 mA
- Removable Terminals Yes
- Standards IEC 61508, EN 60947-5-1, EN 60204-1
- Number of safety contacts 4
- Material of the contacts, electrical Ag-Ni, self-cleaning, positive drive
- Short-circuit recognition Yes
- Number of LEDs 7
- Enclosure material Glass-fibre reinforced thermoplastic, ventilated
- Stop-Category 0
- Earth connection detection Yes
- Mechanical life, minimum 10,000,000 Operations
- Storage and transport temperature, minimum -40 °C
- Degree of pollution to IEC/EN 60664-1 2
- Climatic stress EN 60068-2-78
- Number of openers 4
- Mounting Snaps onto standard DIN rail to EN 60715
- Wire breakage detection Yes
- Feedback circuit Yes
- Width 45 mm
- Rated operating voltage 24 VAC -15% / +10%, 24 VDC -15% / +20%, residual ripple max. 10 %
- Integral System Diagnostics, status Yes
- Degree of protection of the mounting space IP54
- Frequency range 50 Hz, 60 Hz
- Rated control voltage at AC 60 Hz, maximum 26.4 VAC
- Pull-in delay at RESET, typically 20 ms
- Number of auxiliary contacts 2
- Terminal Connector Screw connection, rigid or flexible
- Degree of protection of clips or terminals IP20
- Ambient temperature, minimum -25 °C
- Overvoltage category III
- Drop-out delay in case of emergency, typically 20 ms
- Pull-in delay at automatic start, maximum, typically 100 ms
- Height 100 mm
- Restistance to shock 30 g / 11 ms
- Rated control voltage at AC 50 Hz, maximum 26.4 VAC
- Voltage, Utilisation category DC13 24 VDC
- Resistance to vibrations to EN 60068-2-6 10...55 Hz, Amplitude 0.35 mm, ± 15 %
- Ambient temperature, maximum +45 °C
- Current, Utilisation category AC-15 4 A
- Terminal designations IEC/EN 60947-1
- Depth 121 mm
- Note (Contact resistance) in new state
- Switching capacity, maximum 2 A
- Rated AC voltage for controls, 50 Hz, minimum 20.4 VAC
- Contact resistance, maximum 0.1 Ω
- Number of signalling outputs 2
- Cable section, maximum 2.5 mm²
- Degree of protection of the enclosure IP40
- Rated AC voltage for controls at DC minimum 20.4 VDC
- Rated control voltage at DC, maximum 28.8 VDC
- Voltage, Utilisation category AC15 230 VAC
- EMC rating EMC-Directive
- Tightening torque of Clips 0.6 Nm
- Electrical power consumption 6 VA
- Current, Utilisation category DC13 4 A
- Conduction resistance, maximum 40 Ω
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
Related documents SRB402NE 24V Specs
