T18RW3LPQP1 Banner Proximity Sensors
Part#:T18RW3LPQP1
Manufacturer:Banner
Alt. Part#:19430
Product Lifecycle:Active
Get a quick Quote!
EZ-BEAM T18 Series: Polarized Retro; Range: 2 m; Input: 20-250 V ac; Output: SPST Solid-state Dark Operate; 150 mm (6 in) 4-pin Micro Pigtail QD
About the manufacturer: Banner is one of the manufacturers that offers Proximity Sensors that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the T18RW3LPQP1 Banner price in the box on the right side or send a quick quote.
Product Details
- Weight68.0388 g
- Country Of OriginUS
- Max Sensing Distance (mm) 2000
- Operation Dark Operate
- Barrel Diameter (mm) 18
- Feature: Chemical Resistant Yes
- Connection Pigtail QD
- Power AC
- Special Feature: Water Detection No
- Feature: Washdown Rated Yes
- Sensing Mode (General) Retroreflective
- Output response time (ms) 16
- Adjustments N/A
- IO Link No
- Quick Disconnect Type 1/2 in. (Micro)
- Input/Output Solid-State AC Switch
- Number of Pins 4
- Opposed Mode Emitter/Receiver N/A
- DeviceNet No
- Max Op. Temp. (°C) 70
- Primary Housing Material Thermoplastic
- IP Rating IP67, IP69
- Indicator LEDs
- Feature: Audible No
- Sensing Beam Visible Red LED
- Power Supply/Supply Voltage 20-250 V ac
- Special Feature: Intrinsically Safe No
- Max Op. Relative Humidity [%] 90% @ 50°C
- Feature: Encapsulated Yes
- Outputs Solid-State AC Switch
- Repeatability (µs) 4000
- Feature: Timing (Hold/Delay) No
- Sensing Mode (Detailed) Polarized
- Special Feature: Remote Teach No
- NEMA Rating NEMA 6P
- Feature: Ecolab Certified Yes
- Housing Style Barrel
- Min Op. Temp. (°C) -40
- Delay at Power-up (ms) 100
- Lens Material Acrylic
- Feature: Hazardous Area No
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
T18RW3LPQP1 Description
Banner Engineering T18RW3LPQP1 is a polarized photo-electric sensor from the T18 series, designed in a retro-reflective mode. It features a thermoplastic housing with an acrylic lens and is pre-wired with a 6" / 150mm pigtail terminated with a 4-pin 1/2" micro connector. This sensor operates within a supply voltage range of 20Vac-250Vac (200Vac / 220Vac / 240Vac nom.) and can be mounted using a threaded mount. It is designed to work within an ambient air temperature range of -40 to +70°C and offers a degree of protection rated at IP67, IP69K, and NEMA 6P. The T18RW3LPQP1 has an M18 cylindrical threaded/barrel shape, includes 1 x digital output (Solid-state AC output; SPST contact type), and provides a sensing distance of 2m. It utilizes infrared (IR) light, has a response time of 16ms / 0.016 s, and operates in a Dark-ON mode. The thread size for mounting is M18.
Related documents T18RW3LPQP1 Specs
