S18DLYXXPT Banner Signal Beacons

Banner S18DLYXXPT S18 DAYLIGHT VISIBLE EZ Light - 18 mm - IP67; Single Color: Yellow; 10-30 V dc PNP Input; 4-screw Terminal Wiring
Banner

Part#:S18DLYXXPT

Manufacturer:Banner

Alt. Part#:31667

Product Lifecycle:Active

Get a quick Quote!

S18 DAYLIGHT VISIBLE EZ Light - 18 mm - IP67; Single Color: Yellow; 10-30 V dc PNP Input; 4-screw Terminal Wiring

About the manufacturer: Banner is one of the manufacturers that offers Signal Beacons that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the S18DLYXXPT Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight63.50288 g
  • Country Of OriginCN
  • Mounting Thread
    M18 x 1.0
  • Color 1 - Wavelength/Color Temp/Coordinates
    590 nm
  • Supply Voltage
    10-30 V dc
  • Indication Intensity
    High Brightness & Daylight Visible
  • Power Source
    DC
  • Lumens Color 1
    1.2
  • Physical Dimensions (LxWxH or DxH mm)
    23.5 x 34.6
  • Feature: Hazardous Area
    No
  • Wireless
    No
  • Number of Colors / Segments
    1
  • NEMA Type and UL Type Rating
    NEMA and UL 4X, 13
  • Multi-Color Device
    Single Color On
  • Indication
    Yes
  • Connection
    Terminal
  • Input Type
    PNP
  • Primary Housing Color
    Black
  • Feature: Quick Disconnect
    No
  • Power
    DC
  • Color Technology
    Standard LED
  • Number of Input Pins/Conductors
    4
  • Min Op. Temperature (°C)
    -40
  • Modbus RTU
    No
  • Color Input Control
    Individual (One wire/color, same number of colors as input wires)
  • Max Current Color (mA)
    25
  • IO Link
    No
  • Primary Window Material
    Polycarbonate Clear
  • Primary Housing Material
    Polycarbonate
  • Color Option 1
    Yellow
  • Environmental Rating
    IP67; IP69
  • Feature: Audible
    No
  • Pro-Editor Compatible (Discrete)
    No
  • Housing Style
    Barrel Mount - Flat Window
  • Animation Option 1
    Solid On
  • Max Input Response Time (ms)
    1
  • Feature: Washdown Rated
    Yes
  • Product Size (mm)
    18
  • Max Op. Temperature (°C)
    50
  • Feature: Chemical Resistant
    No

Product condition

ORIGINAL PACKAGING

SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging

S18DLYXXPT Description

Banner Engineering S18DLYXXPT, part of the EZ-LIGHT series, is a pilot light designed with daylight-visible 1-color yellow LED illumination. This part features a clear Polycarbonate (PC) window and a Polycarbonate (PC) base, housed in a black casing. It has an 18mm indicator diameter and utilizes a screw-clamp terminal connection for installation. The S18DLYXXPT operates on a supply voltage range of 10Vdc to 30Vdc, with a nominal range of 12Vdc to 24Vdc, and is designed for flush mounting in an 18mm hole with an M18 thread. It is suitable for operation in ambient air temperatures ranging from -40°C to +50°C. This part boasts a high degree of protection with ratings of IP67, IP69K, NEMA 4X, NEMA 13, UL type 4X, and UL type 13, ensuring durability in various environments. The design features a round protruding window and a threaded cylindrical barrel, with a current consumption of 25mA. Additionally, it includes 1 x digital input (10-30Vdc; PNP) for color control.

Related documents S18DLYXXPT Specs

S18DLYXXPT 160690.pdf

1-year warranty
