S18DLBXXPQ Banner Signal Beacons

Banner S18DLBXXPQ S18 Daylight Visible EZ-LIGHT - 18 mm - IP67; Single Color: Blue; 10-30 V dc PNP Input; 4-pin M12 QD
Banner

Part#:S18DLBXXPQ

Manufacturer:Banner

Alt. Part#:25807

Product Lifecycle:Active

Get a quick Quote!

S18 Daylight Visible EZ-LIGHT - 18 mm - IP67; Single Color: Blue; 10-30 V dc PNP Input; 4-pin M12 QD

About the manufacturer: Banner is one of the manufacturers that offers Signal Beacons that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the S18DLBXXPQ Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight54.43104 g
  • Country Of OriginCN
  • Power
    DC
  • Animation Option 1
    Solid On
  • Number of Input Pins/Conductors
    4
  • Feature: Washdown Rated
    Yes
  • Pro-Editor Compatible (Discrete)
    No
  • Number of Colors / Segments
    1
  • Max Current Color (mA)
    25
  • Physical Dimensions (LxWxH or DxH mm)
    23.5 x 35.7
  • Multi-Color Device
    Single Color On
  • Primary Housing Material
    Polycarbonate
  • Lumens Color 1
    0.60
  • NEMA Type and UL Type Rating
    NEMA and UL 4X, 13
  • Modbus RTU
    No
  • Color Input Control
    Individual (One wire/color, same number of colors as input wires)
  • Quick Disconnect Type
    M12 (Euro)
  • Min Op. Temperature (°C)
    -40
  • Indication Intensity
    High Brightness & Daylight Visible
  • Mounting Thread
    M18 x 1.0
  • Color Technology
    Standard LED
  • Max Op. Temperature (°C)
    50
  • Feature: Hazardous Area
    No
  • IO Link
    No
  • Indication
    Yes
  • Color 1 - Wavelength/Color Temp/Coordinates
    470 nm
  • Environmental Rating
    IP67; IP69
  • Wireless
    No
  • Power Source
    DC
  • Connection
    Integral QD
  • Max Input Response Time (ms)
    1
  • Primary Housing Color
    Black
  • Feature: Chemical Resistant
    No
  • Cable Length (m)
    0.15
  • Product Size (mm)
    18
  • Supply Voltage
    10-30 V dc
  • Feature: Audible
    No
  • Color Option 1
    Blue
  • Housing Style
    Barrel Mount - Flat Window
  • Input Type
    PNP
  • Primary Window Material
    Polycarbonate Clear
  • Feature: Quick Disconnect
    Yes

Product condition

ORIGINAL PACKAGING

SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging

S18DLBXXPQ Description

Banner Engineering S18DLBXXPQ is a pilot light from the EZ-LIGHT series featuring daylight-visible 1-color blue LED illumination. This part is designed with a clear Polycarbonate (PC) window and a Polycarbonate (PC) base, housed in a black casing. It has an 18mm indicator diameter and is equipped with a 4-pin M12 Euro-style QD connector for connectivity. The S18DLBXXPQ operates on a supply voltage range of 10Vdc to 30Vdc, with a nominal range of 12Vdc to 24Vdc, and is designed for flush mounting in an 18mm hole with an M18 thread. It can operate in ambient air temperatures ranging from -40°C to +50°C. This part boasts a degree of protection rated at IP67, IP69K, NEMA 4X, NEMA 13, UL type 4X, and UL type 13, ensuring its durability in various environments. The shape of the S18DLBXXPQ is characterized by a round protruding window and a threaded cylindrical barrel, with a current consumption of 25mA. It also features 1 x digital input (10-30Vdc; PNP) for color control.

Related documents S18DLBXXPQ Specs

S18DLBXXPQ 160690.pdf
