S18DLHBQP Banner Signal Beacons
Part#:S18DLHBQP
Manufacturer:Banner
Alt. Part#:87918
Product Lifecycle:Active
Get a quick Quote!
S18 EZ-LIGHT Daylight Visible High Intensity 18 mm 1-Color; Voltage: 9-30 V dc; Environmental Rating: IP67; Color: Blue; Input: PNP; 150 mm (6 in) 4-pin M12 PVC Pigtail QD
About the manufacturer: Banner is one of the manufacturers that offers Signal Beacons that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the S18DLHBQP Banner price in the box on the right side or send a quick quote.
Product Details
- Weight63.50288 g
- Country Of OriginUS
- Power DC
- Color Technology Standard LED
- Input Type Bimodal (PNP/NPN)
- Feature: Hazardous Area No
- Housing Style Barrel Mount - Flat Window
- Connection Pigtail QD
- Max Input Response Time (ms) 1
- Indication Intensity High Brightness & Daylight Visible
- Number of Input Pins/Conductors 4
- Feature: Washdown Rated Yes
- Pro-Editor Compatible (Discrete) No
- Primary Housing Material Polycarbonate
- Color Option 1 Blue
- Physical Dimensions (LxWxH or DxH mm) 23.5 x 35.7
- Feature: Audible No
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Color 1 - Wavelength/Color Temp/Coordinates 478 nm
- Min Op. Temperature (°C) -40
- Multi-Color Device Single Color On
- Indication Yes
- Animation Option 1 Solid On
- NEMA Type and UL Type Rating NEMA and UL 4X, 13
- Feature: Chemical Resistant No
- Power Source DC
- Quick Disconnect Type M12 (Euro)
- Max Op. Temperature (°C) 60
- IO Link No
- Number of Colors / Segments 1
- Max Current Color (mA) 60
- Primary Window Material Polycarbonate Clear
- Feature: Quick Disconnect Yes
- Mounting Thread M18 x 1.0
- Lumens Color 1 6.5
- Environmental Rating IP67; IP69
- Modbus RTU No
- Product Size (mm) 18
- Supply Voltage 9-30 V dc
- Primary Housing Color Black
- Wireless No
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
S18DLHBQP Description
Banner Engineering S18DLHBQP, part of the EZ-LIGHT series, is a pilot light designed with daylight-visible 1-color blue LED illumination. This high-intensity LED pilot light indicator features a clear Polycarbonate (PC) window and base, with a diameter of 18mm. It is pre-wired with a 6" / 15cm pigtail that terminates with a 4-pin M12 Euro-style QD connector. The housing is black, and it operates on a supply voltage of 9Vdc-30Vdc (12Vdc-24Vdc nom.). The S18DLHBQP is designed for flush mounting in an 18mm hole with an M18 thread. It can operate in ambient air temperatures ranging from -40°C to +60°C. This part offers a degree of protection rated at IP67, IP69K, NEMA 4X, NEMA 13, UL type 4X, and UL type 13. The shape is characterized by a round protruding window and a threaded cylindrical barrel. It has a current consumption of 60mA and includes 1 x digital input (9-30Vdc; PNP) for color control.
Related documents S18DLHBQP Specs
