S18DLHRQ Banner Signal Beacons
Part#:S18DLHRQ
Manufacturer:Banner
Alt. Part#:87903
Product Lifecycle:Active
Get a quick Quote!
S18 EZ-LIGHT Daylight Visible High Intensity 18 mm 1-Color; Voltage: 9-30 V dc; Environmental Rating: IP67; Color: Red; Input: PNP; 4-pin M12 Integral QD
About the manufacturer: Banner is one of the manufacturers that offers Signal Beacons that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the S18DLHRQ Banner price in the box on the right side or send a quick quote.
Product Details
- Weight4.53592 g
- Country Of OriginCN
- Power Source DC
- Animation Option 1 Solid On
- Max Input Response Time (ms) 1
- Feature: Audible No
- Primary Housing Material Polycarbonate
- Product Size (mm) 18
- Max Current Color (mA) 60
- Min Op. Temperature (°C) -40
- Feature: Quick Disconnect Yes
- Mounting Thread M18 x 1.0
- Color 1 - Wavelength/Color Temp/Coordinates 625 nm
- Physical Dimensions (LxWxH or DxH mm) 23.5 x 35.7
- Indication Intensity High Brightness & Daylight Visible
- Housing Style Barrel Mount - Flat Window
- Color Technology Standard LED
- Number of Input Pins/Conductors 4
- Primary Housing Color Black
- Modbus RTU No
- Power DC
- Color Option 1 Red
- Supply Voltage 9-30 V dc
- Primary Window Material Polycarbonate Clear
- IO Link No
- Number of Colors / Segments 1
- Feature: Washdown Rated Yes
- NEMA Type and UL Type Rating NEMA and UL 4X, 13
- Cable Length (m) 2
- Lumens Color 1 12.5
- Input Type Bimodal (PNP/NPN)
- Feature: Chemical Resistant No
- Pro-Editor Compatible (Discrete) No
- Indication Yes
- Connection Integral QD
- Max Op. Temperature (°C) 60
- Feature: Hazardous Area No
- Wireless No
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Quick Disconnect Type M12 (Euro)
- Environmental Rating IP67; IP69
- Multi-Color Device Single Color On
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
S18DLHRQ Description
Banner Engineering S18DLHRQ, part of the EZ-LIGHT series, is a pilot light designed with daylight-visible 1-color Red LED illumination. This high-intensity LED pilot light indicator features a clear Polycarbonate (PC) window and base, with a black housing. It has an 18mm indicator diameter and is equipped with a 4-pin M12 Euro-style QD connector for connectivity. The S18DLHRQ operates on a supply voltage of 9Vdc-30Vdc (12Vdc-24Vdc nom.) and is designed for flush mounting in an 18mm hole with an M18 thread. It can operate in ambient air temperatures ranging from -40°C to +60°C. This part boasts a degree of protection rated at IP67, IP69K, NEMA 4X, NEMA 13, UL type 4X, and UL type 13, ensuring durability in various environments. The shape is characterized by a round protruding window and a threaded cylindrical barrel. It has a current consumption of 60mA and includes 1 x digital input (9-30Vdc; PNP) for color control.
