S18DLHGT Banner Signal Beacons

Banner S18DLHGT S18 EZ-LIGHT Daylight Visible High Intensity 18 mm 1-Color; Voltage: 9-30 V dc; Environmental Rating: IP67; Color: Green; Input: PNP; 4-screw Terminal Wiring
Banner

Part#:S18DLHGT

Manufacturer:Banner

Alt. Part#:87920

Product Lifecycle:Active

Get a quick Quote!

S18 EZ-LIGHT Daylight Visible High Intensity 18 mm 1-Color; Voltage: 9-30 V dc; Environmental Rating: IP67; Color: Green; Input: PNP; 4-screw Terminal Wiring

About the manufacturer: Banner is one of the manufacturers that offers Signal Beacons that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the S18DLHGT Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight63.50288 g
  • Country Of OriginCN
  • Color Input Control
    Individual (One wire/color, same number of colors as input wires)
  • Indication
    Yes
  • Color Option 1
    Green
  • Supply Voltage
    9-30 V dc
  • Feature: Chemical Resistant
    No
  • Pro-Editor Compatible (Discrete)
    No
  • Housing Style
    Barrel Mount - Flat Window
  • Color 1 - Wavelength/Color Temp/Coordinates
    530 nm
  • Max Input Response Time (ms)
    1
  • Power
    DC
  • Product Size (mm)
    18
  • Physical Dimensions (LxWxH or DxH mm)
    23.5 x 34.6
  • Indication Intensity
    High Brightness & Daylight Visible
  • Cable Length (m)
    0.15
  • Color Technology
    Standard LED
  • Primary Housing Color
    Black
  • IO Link
    No
  • Number of Colors / Segments
    1
  • Lumens Color 1
    20.0
  • Input Type
    Bimodal (PNP/NPN)
  • Feature: Washdown Rated
    Yes
  • Mounting Thread
    M18 x 1.0
  • Animation Option 1
    Solid On
  • Max Op. Temperature (°C)
    60
  • Feature: Audible
    No
  • Primary Housing Material
    Polycarbonate
  • Number of Input Pins/Conductors
    4
  • Min Op. Temperature (°C)
    -40
  • Multi-Color Device
    Single Color On
  • Power Source
    DC
  • Max Current Color (mA)
    60
  • NEMA Type and UL Type Rating
    NEMA and UL 4X, 13
  • Modbus RTU
    No
  • Connection
    Terminal
  • Environmental Rating
    IP67; IP69
  • Primary Window Material
    Polycarbonate Clear
  • Wireless
    No
  • Feature: Hazardous Area
    No

Product condition

ORIGINAL PACKAGING

SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging

S18DLHGT Description

Banner Engineering S18DLHGT, part of the EZ-LIGHT series, is a pilot light designed with daylight-visible 1-color green LED illumination. This high-intensity LED pilot light indicator features a clear Polycarbonate (PC) window and base, with a black housing. It has an 18mm indicator diameter and utilizes a screw-clamp terminal connection for installation. The S18DLHGT operates on a supply voltage of 9Vdc-30Vdc (12Vdc-24Vdc nominal) and is designed for flush mounting in an 18mm hole with an M18 thread. It can operate in ambient air temperatures ranging from -40°C to +60°C. This part is protected to IP67, IP69K, NEMA 4X, NEMA 13, UL type 4X, and UL type 13 standards, ensuring durability in various environments. The shape is characterized by a round protruding window and a threaded cylindrical barrel. It has a current consumption of 60mA and includes 1 x digital input (9-30Vdc; PNP) for color control.

Related documents S18DLHGT Specs

S18DLHGT 177054.pdf
