S18DLGRYP Banner Signal Beacons
Part#:S18DLGRYP
Manufacturer:Banner
Alt. Part#:25820
Product Lifecycle:Active
Get a quick Quote!
S18 Daylight Visible EZ-LIGHT - 18 mm - IP67; Three Color: Green Red Yellow; 10-30 V dc PNP Input; 4-Wire 2 m Cable
About the manufacturer: Banner is one of the manufacturers that offers Signal Beacons that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the S18DLGRYP Banner price in the box on the right side or send a quick quote.
Product Details
- Weight81.64656 g
- Country Of OriginCN
- Number of Colors / Segments 3
- Color 2 - Wavelength/Color Temp/Coordinates 625 nm
- Color 1 - Wavelength/Color Temp/Coordinates 525 nm
- Min Op. Temperature (°C) -40
- Pro-Editor Compatible (Discrete) No
- Environmental Rating IP67; IP69
- Color Technology Standard LED
- Supply Voltage 10-30 V dc
- Physical Dimensions (LxWxH or DxH mm) 23.5 x 35.7
- Power Source DC
- Mounting Thread M18 x 1.0
- Color Option 2 Red
- Lumens Color 3 1.2
- Indication Intensity High Brightness & Daylight Visible
- Feature: Washdown Rated Yes
- Primary Housing Material Polycarbonate
- Connection Cable
- Max Input Response Time (ms) 1
- Max Op. Temperature (°C) 50
- IO Link No
- Power DC
- Animation Option 1 Solid On
- Color Option 3 Yellow
- Color 3 - Wavelength/Color Temp/Coordinates 590 nm
- Feature: Audible No
- Feature: Quick Disconnect No
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Color Option 1 Green
- Max Current Color (mA) 25
- Feature: Hazardous Area No
- Housing Style Barrel Mount - Flat Window
- Indication Yes
- Lumens Color 2 1.4
- Input Type PNP
- NEMA Type and UL Type Rating NEMA and UL 4X, 13
- Multi-Color Device Single Color On
- Product Size (mm) 18
- Lumens Color 1 2.3
- Number of Input Pins/Conductors 4
- Primary Housing Color Black
- Feature: Chemical Resistant No
- Primary Window Material Polycarbonate Clear
- Modbus RTU No
- Wireless No
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
S18DLGRYP Description
Banner Engineering S18DLGRYP, part of the EZ-LIGHT series, is a pilot light designed with a daylight-visible 3-color G/R/Y color pattern LED illumination. This LED pilot light indicator features a clear Polycarbonate (PC) window and base, with a diameter of 18mm. It comes pre-wired with a 2m / 6.5ft 4-wire cable terminated with bare end flying leads, housed in a black casing. The S18DLGRYP operates on a supply voltage of 10Vdc-30Vdc (12Vdc-24Vdc nom.) and is designed for flush mounting in an 18mm hole with an M18 thread. It can operate in ambient air temperatures ranging from -40°C to +50°C. This part boasts a degree of protection rated at IP67, IP69K, NEMA 4X, NEMA 13, UL type 4X, and UL type 13, ensuring durability in various environments. The shape is characterized by a round protruding window and a threaded cylindrical barrel. It has a current consumption of 25mA and includes 3 x digital inputs (10-30Vdc; PNP) for color control.
