OTBVN6 Banner Sensor Accessories
Part#:OTBVN6
Manufacturer:Banner
Alt. Part#:28591
Product Lifecycle:Active
Get a quick Quote!
OTB Series: Momentary Action Touch Button w/Black F.C.; Input: 10-30 V dc; Upper Housing: Polysulfone; Output: Complementary NPN; 2 m (6.5 ft) Integral Cable
About the manufacturer: Banner is one of the manufacturers that offers Sensor Accessories that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the OTBVN6 Banner price in the box on the right side or send a quick quote.
Product Details
- Weight298.009944 g
- Country Of OriginMX
- Power DC
- Number of Input Pins/Conductors 4
- NEMA Type and UL Type Rating NEMA 1, 3, 4, 4X, 12, 13
- Feature: Audible No
- Power Source DC
- Input Type NPN
- Max Op. Relative Humidity Non-Condensing (%) 90% @ 50°C
- IO Link No
- Non-Illuminated Yes
- Operation Normally Open/Normally Closed
- Min Op. Temperature (°C) -20
- Feature: Quick Disconnect No
- Mounting Thread M30 x 1.5
- Max Input Response Time (ms) 100
- Button Operation Momentary
- Product Size (mm) Other
- Primary Housing Material Thermoplastic Polysulfone
- Physical Dimensions (LxWxH or DxH mm) 59.9 x 43.2 x 48.0
- Housing Style Base Mount - Saddle
- Supply Voltage 10-30 V dc
- Environmental Rating IP66
- Primary Housing Color Black
- Pro-Editor Compatible (Discrete) No
- Sensing Mode (General) Single Point Optical
- Connection Cable
- Max Op. Temperature (°C) 50
- Modbus RTU No
- Actuation Yes
- Max Output Response Time (ms) 100
- Field Cover Color Black
- Activation Function Optical
- Output Type NPN
- Number of Beams 1
- Feature: Hazardous Area No
- Feature: Chemical Resistant No
- Secondary Material Thermoplastic
- Wireless No
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
OTBVN6 Description
Banner Engineering OTBVN6 is a photo-electric optical touch-activated button designed for versatile mounting options, including surface or base flush with a 30mm hole requirement. It operates within an ambient air temperature range of -20°C to +50°C and features a black field cover for its design. This part is pre-wired with a 2m / 6.5ft 4-wire cable that terminates with bare end flying leads, ensuring easy installation. It boasts a high degree of protection, rated at IP66, NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 12, and NEMA 13, suitable for various environmental conditions. The OTBVN6 requires a supply voltage of 10Vdc to 30Vdc, with a nominal range of 12Vdc to 24Vdc. Its saddle/yoke-shaped body is constructed from a polysulfone upper housing and a thermoplastic polyester base, finished in black. The operating mode is momentary, offering NO (Normally Open) or NC (Normally Closed) configurations, complemented by 1 x digital output (10-30Vdc; NPN) for touch activation.
Related documents OTBVN6 Specs
