Variable Frequency Drives (VFD)

M1551B

Lenze M1551B is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for general purpose applications. It features dimensions of H200mm x W200mm x D151mm and supports Modbus communication protocol. The device is equipped with thermal overload protection and solid state motor overload protection. It operates at a rated current of 6.1A for supply voltages of 480Vac / 590Vac and is suitable for mounting in a control cabinet or on a surface/wall. The M1551B can operate in ambient air temperatures ranging from -10 to +50 °C and has a NEMA 1 degree of protection. It is designed for a 3-phase network (3P / 3AC) with an input frequency of 48-62 Hz and an output frequency of 0-120 Hz. The unit includes 1 analog output proportional to speed (frequency), 1 analog output proportional to load, 4 digital inputs (terminal 13A-13D), 1 digital input (terminal 12A START), 1 digital input (terminal 1 STOP), and 2 digital outputs (NPN; sinking) (terminal 14 and 15). Additionally, it has 1 analog input (0-10Vdc) (terminal 5A) and 1 analog input (4-20mA) (terminal 5B). The rated active power is 3.7kW, and the rated power is 5HP for supply voltages of 480Vac / 590Vac.

Lenze

I55AE330F1AV11003S

Lenze I55AE330F1AV11003S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed/frequency control, compact inverter DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and PID controller functionality. It features a built-in RFI filter, safe torque off (STO) safety standard, I.O. conformal coating, and dimensions of H450mm x W250mm x D230mm. Communication is facilitated via Modbus RTU protocol, and it includes protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. The rated current varies with duty and voltage: 73.2A (light-duty; 400Vac), 62.4A (light-duty; 480Vac), 61A (heavy-duty; 400Vac), and 52A (heavy-duty; 480Vac). It operates on a supply voltage of 400Vac / 480Vac, suitable for control cabinet or surface/wall mounting. The ambient air temperature for operation is capped at 45°C (at a switching frequency of 2kHz or 4kHz) and 40°C (at a switching frequency of 8kHz or 16kHz), with a degree of protection of IP20. It supports a 3-phase (3P / 3AC) network, with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). The device includes 1 x analog output (0-10Vdc; 0-20mA or 4-20mA), 5 x digital inputs (PNP/NPN logic), 1 x digital output (max. 100mA), and 2 x analog inputs (-10...+10Vdc; 0-20mA or 4-20mA). Rated active power is 37kW (light-duty; 400-480Vac) and 30kW (heavy-duty; 400-480Vac), with rated power of 50HP (light-duty; 400-480Vac) and 40HP (heavy-duty; 400-480Vac).

Lenze

HVW701A016T2N01-J-A

WEG HVW701A016T2N01-J-A - STANDARD PANEL HVW701A016T2N01-J-A, HVAC Enclosed Drives (HVW)

WEG

I51AE211F10V11001S

Lenze I51AE211F10V11001S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for compact applications, featuring DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, and a flying restart circuit. It includes a PID controller, built-in RFI filter, basic I.O., and conformal coating. The dimensions are H250mm x W60mm x D130mm. It supports CANopen and Modbus RTU communication protocols and offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. The rated current is 3.2A for 400Vac and 3A for 480Vac, with a supply voltage of 400Vac / 480Vac. It is suitable for control cabinet or surface/wall mounting, operates within an ambient air temperature of up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at a switching frequency of 8kHz or 16kHz, with an IP20 degree of protection. The network type is 3-phase (3P / 3AC), with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It features 1 x analog output, 5 x digital inputs with optional uses for two of them, 2 x analog inputs with optional uses, a digital output, a rated active power of 1.1kW, and a rated power of 1-1/2HP for heavy-duty applications at 400-480Vac.

Lenze

EDP11S515GN3R11000

STANDARD PANEL EDP11S515GN3R11000

WEG

CFW700B04P2T5DB20

DRIVE CFW700B04P2T5DB20

WEG

M000-09402000DU0100AN100

NIDEC M000-09402000DU0100AN100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the M000 series, designed with a built-in DC to AC inverter featuring air cooling. It has dimensions of frame size 9D, measuring H28.11" x W12.2" x D11.4" (H714mm x W310mm x D290mm). This model is rated for a heavy-duty current of 200A and operates on a supply voltage of 380Vac-480Vac (400Vac / 415Vac), with a network frequency supply input of 50 Hz. It offers a degree of protection of IP20 NEMA 1. The rated active power ranges from 90kW to 250kW for heavy-duty applications, equivalent to 125HP to 400HP.

Nidec

HVW701E211T4N12-X-X

WEG HVW701E211T4N12-X-X - STANDARD PANEL HVW701E211T4N12-X-X, HVAC Enclosed Drives (HVW)

WEG

CFW110180T4O55DSZ

DRIVE CFW110180T4O55DSZ

WEG

I55AE240C10V01002S

Lenze I55AE240C10V01002S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for compact inverter applications including DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and a PID controller. It features a standard I.O. with conformal coating, dimensions of H250mm x W90mm x D130mm, and utilizes the CANopen communication protocol. Protection functions include overvoltage category, leakage current, earth fault resistance, and overtemperature of motor. The rated current is 20.6A for light-duty (230-240Vac) and 16.5A for heavy-duty (230-240Vac), with a supply voltage of 230Vac / 240Vac. It is designed for control cabinet or surface/wall mounting, operates within an ambient air temperature of 45°C at a switching frequency of 2kHz or 4kHz and 40°C at 8kHz or 16kHz, and has an IP20 degree of protection. The network type is 3-phase (3P / 3AC) with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 x analog output, 5 x digital inputs with flexible functionality, 1 x digital output, and 2 x analog inputs, supporting both voltage and current input/output configurations. The rated active power is 5.5kW for light-duty and 4kW for heavy-duty, corresponding to 7-1/2HP and 5HP, respectively.

Lenze

C300-09201760A10101AB100

NIDEC C300-09201760A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the C300 series designed with dual Safe Torque Off (STO) and air cooling. It operates on a supply voltage of 200Vac-240Vac, suitable for 220Vac or 230Vac systems, and features a frame size 9A with dimensions of H43.62" x W12.21" x D11.42" (H1108mm x W310mm x D290mm). This model offers an IP20 NEMA 1 degree of protection and supports a rated current of 216A for Normal duty and 176A for Heavy-duty applications. It utilizes Modbus RTU for communication and is designed for a 3-phase input network with a frequency range of 45-66 Hz for supply input and 0-550 Hz for output. The ambient air temperature for operation ranges from -20°C to +60°C. It includes 1 analog output (10Vdc), 5 digital inputs (0-24Vdc; PNP/NPN) plus 1 additional digital input (0-24Vdc), 1 digital output (50mA / 0-24Vdc; source; PWM) and 1 digital output (2A / 240Vac; source; relay contact type), along with 2 analog inputs with 11-bit conversion resolution (0-20mA / 4-20mA / 0-10Vdc and 0-10Vdc). The rated active power is 55kW for Normal duty and 45kW for Heavy-duty, corresponding to 75HP and 60HP, respectively.

Nidec

HVW701B031T4N01-X-B

WEG HVW701B031T4N01-X-B - STANDARD PANEL HVW701B031T4N01-X-B, HVAC Enclosed Drives (HVW)

WEG

CFW500C07P0T5DB20

DRIVE CFW500C07P0T5DB20

WEG

HVW701E211T2N12-I-B

WEG HVW701E211T2N12-I-B - STANDARD PANEL HVW701E211T2N12-I-B, HVAC Enclosed Drives (HVW)

WEG

C300-05400270A10101AB100

NIDEC C300-05400270A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the C300 series designed with dual Safe Torque Off (STO) and air cooling. It operates on a supply voltage of 380Vac-480Vac, including 400Vac and 415Vac, within a frame size of 5 measuring H15.39" x W5.63" x D7.87" (H391mm x W143mm x D200mm). This model offers a degree of protection rated at IP20 NEMA 1 and supports a rated current of 30A under normal duty and 27A under heavy-duty conditions. It utilizes the Modbus RTU communication protocol over a 3-phase input network with a supply input frequency range of 45-66 Hz and an output frequency range of 0-550 Hz. The ambient air temperature for operation spans from -20°C to +60°C. It features 1 analog output (10Vdc; source; single-ended), 5 digital inputs (0-24Vdc; PNP/NPN) plus 1 additional digital input (0-24Vdc), and 2 digital outputs (one 50mA / 0-24Vdc; source; PWM and another 2A / 240Vac; source; relay contact type). The analog inputs include 1 x analog input (0-20mA / 4-20mA / 0-10Vdc; single-ended; 11-bit conversion resolution) and 1 x analog input (0-10Vdc; single-ended; 11-bit conversion resolution). It is rated for an active power of 15kW under normal duty and 11kW under heavy-duty, with a rated power of 20HP for both conditions.

Nidec

HVW701D088T4N12-J-B

WEG HVW701D088T4N12-J-B - STANDARD PANEL HVW701D088T4N12-J-B, HVAC Enclosed Drives (HVW)

WEG

EDP11S007DN1211000

STANDARD PANEL EDP11S007DN1211000

WEG

CFW701E0180T2NBN1C3

DRIVE CFW701E0180T2NBN1C3

WEG

CFW110877T4OYZ

DRIVE CFW110877T4OYZ

WEG

VFD015C4EA-21

Variable Frequency Drive, 3 phase, 460 VAC build-in EMI Input, 2 HP, frame A, wall mount, IP20, NEMA 1

Delta
