Variable Frequency Drives (VFD)

HVW701A016T2N01-X-B

WEG HVW701A016T2N01-X-B - STANDARD PANEL HVW701A016T2N01-X-B, HVAC Enclosed Drives (HVW)

WEG

ATV61HU30N4S337

Schneider Electric ATV61HU30N4S337 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 61 series designed for variable speed and frequency control. It features a U/F ratio with options for 2 points, 5 points, and energy saving modes, along with sensorless flux vector control in standard and energy-saving configurations, and vector control without speed feedback capable of delivering 120% of the nominal motor torque. This model includes a DC choke, an EMC filter (class C2), a built-in heatsink, and a coated version for enhanced durability. It operates on a supply voltage of 323-528Vac, accommodating 380Vac, 400Vac, 480Vac, and 500Vac nominal values, and has dimensions of H260mm x W150mm x D187mm. The device is chemically resistant with a conformal coating (reinforced version) and offers an IP20 UL type 1 degree of protection. It supports a rated current of 7.8A at 380Vac (12kHz), 6.2A at 460Vac (12kHz), and can handle a maximum current of 9.3A for 60 seconds. Wall mounting is the prescribed mounting mode, and it utilizes Modbus and CANopen for communication protocols. Designed for a 3-phase network with an output frequency range of 0.1-599 Hz, it includes 1 analog output (0-10Vdc / 0-20mA), 5 digital inputs (24Vdc; sink/source), an additional programmable digital input, and a PWR safety input. It also features 1 digital output (C/O SPDT relay contact) and 1 digital output (NO relay contact), alongside 2 analog inputs for comprehensive connectivity. The current consumption is rated at 10.7A for 380Vac and 9A for 480Vac, with a rated active power of 3kW.

Schneider Electric

SF210

Lenze SF210 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for precise control of motor speed and frequency. It features dimensions of H146mm x W73mm x D120mm and operates on a supply voltage of 200Vac-240Vac, supporting 208Vac, 220Vac, and 230Vac inputs. The rated current is 4.8A at 200Vac and 4.2A at 230Vac. This device can be mounted in a cabinet or on a DIN rail and is designed to operate within an ambient air temperature range of 0 to +50°C, with a derating of 2.5% per °C above +50°C. It utilizes an RS-485 communication protocol and operates with a network frequency of 48-62 Hz on input and 0-240 Hz on output. The SF210 includes 2 digital outputs (open-collector outputs; 50mA at 30Vdc), 2 analog inputs (1 x 0-10Vdc and 1 x 4-20mA), and 2 analog outputs (both 0-10Vdc or adjustable within specified ranges), suitable for various control applications. It supports a 3-phase network and delivers a rated active power of 0.75kW and a rated power of 1HP at 208-240Vac.

Lenze

ATV71HU55N4S337

Schneider Electric ATV71HU55N4S337 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 71 series. It features variable speed/frequency drive capabilities with U/F ratio adjustment (2 points / 5 points), sensorless flux vector control, ENA System, and vector control with or without speed feedback. It can deliver 220% of the nominal motor torque for 2 seconds and 170% of the nominal motor torque for 60 seconds. The design includes a built-in DC choke, EMC filter, heatsink, and a coated version for enhanced chemical resistance. It operates on a supply voltage of 323-528Vac (380Vac / 400Vac / 480Vac / 500Vac nom.), with dimensions of H295mm x W175mm x D187mm. The degree of protection is IP20 UL type 1, with a rated current of 14.3A (380Vac; 4kHz), 11A (460Vac; 4kHz), and a maximum current of 23.6A for 2 seconds and 21.5A for 60 seconds. It supports wall mounting and uses Modbus and CANopen communication protocols. Designed for a 3-phase (3P) network with an output frequency of 0.1-599 Hz, it includes 1 analog output (0-10Vdc / 0-20mA), 5 digital inputs (24Vdc; sink/source), 1 digital input (24Vdc; sink/source) programmable as discrete or PTC input, 1 digital input (24Vdc) for PWR safety, and 3 digital outputs. It also features 2 analog inputs for versatile connectivity. The current consumption is 20.3A (380Vac) and 17A (480Vac), with a rated active power of 5.5kW and rated power of 7.5HP / 7-1/2HP.

Schneider Electric

I5DAE337F10V10000S

Lenze I5DAE337F10V10000S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Power units sub-range, designed with a built-in RFI filter. This inverter power unit does not feature a communication interface but is equipped with protection functions including overvoltage category, leakage current, earth fault resistance, and overtemperature of the motor. It supports rated currents of 91.2A for light-duty at 400Vac, 78A for light-duty at 480Vac, 76A for heavy-duty at 400Vac, and 65A for heavy-duty at 480Vac. The supply voltage is rated for both 400Vac and 480Vac. It is designed for mounting in a control cabinet or on a surface/wall with an IP20 degree of protection. This unit operates on a 3-phase (3P / 3AC) network and delivers a rated active power of 37kW and rated power of 50HP for heavy-duty applications at 400-480Vac.

Lenze

CFW500D47P0T2DBN1

WEG CFW500D47P0T2DBN1 - DRIVE CFW500D47P0T2DBN1, CFW500/700 Drives

WEG

M400-02400018A10101AB100

NIDEC M400-02400018A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M400 series designed with a built-in brake transistor and dual Safe Torque Off (STO) for air cooling. It features dimensions of frame size 2, measuring H8.1" x W3.1" x D5.9" (H205mm x W78mm x D150mm). This model supports multiple communication protocols, including CANopen, DeviceNet, Ethernet/IP, Modbus RTU, Modbus TCP, PROFINET RT, and PROFIBUS DP. It operates with a rated current of 1.8A for both normal and heavy-duty applications and requires a supply voltage of 380Vac-480Vac (400Vac / 415Vac). The ambient air temperature for operation ranges from -20°C to +60°C, and it is protected by an IP20 NEMA 1 enclosure. Designed for a 3-phase input network with a frequency of 45-66 Hz (supply input) and an output frequency range of 0-550 Hz, it includes 2 analog outputs, 8 digital inputs, and 3 digital outputs, alongside 2 analog inputs with an 11-bit conversion resolution. The rated active power and power rating are 0.55kW and 3/4HP for both normal and heavy-duty operations, respectively.

Nidec

M000-11602380EU0100AN100

NIDEC M000-11602380EU0100AN100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter, part of the M000 series, designed for heavy-duty applications. It requires an external choke for air cooling and has dimensions of frame size 11E, measuring H46.9" x W12.2" x D12.3" (H1190mm x W310mm x D312mm). The rated current is 238A for heavy-duty operations, with a supply voltage range of 500Vac-690Vac (600Vac typical). It offers a degree of protection of IP20 NEMA 1 and operates on a network frequency of 50 Hz. The rated active power ranges from 90kW to 250kW, equivalent to 125HP to 400HP for heavy-duty tasks.

Nidec

CFW110150T6ON1NBYZ

DRIVE CFW110150T6ON1NBYZ

WEG

I55AE222B10V11001S

Lenze I55AE222B10V11001S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed and frequency control with additional features including DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and a PID controller. It incorporates a built-in RFI filter, application I.O., and conformal coating. The dimensions are H250mm x W60mm x D130mm. This model does not include a communication interface but offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It has a rated current of 9.6A for heavy-duty applications at 230-240Vac, with a supply voltage of 230Vac / 240Vac. It is suitable for control cabinet or surface/wall mounting, operates within an ambient air temperature range of up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at a switching frequency of 8kHz or 16kHz, with a degree of protection of IP20. The network type is single-phase / 1P, with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It features 2 x analog outputs, 7 x digital inputs with flexible functionality, 2 x digital outputs, and 2 x analog inputs, supporting both voltage and current input/output configurations. The rated active power is 2.2kW, and the rated power is 3HP for heavy-duty applications at 230-240Vac.

Lenze

ATV312HU30N4B

Schneider Electric ATV312HU30N4B is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 312 series designed for sensorless flux vector control with an energy-saving ratio of 170-200% of the nominal motor torque. It features a built-in EMC filter and heatsink, and it is a version without a control I.O. card to allow space for a communication card. The supply voltage ranges from 323-550Vac, supporting 380Vac, 400Vac, 480Vac, and 500Vac nominal values. Its dimensions are H184mm x W142mm x D152mm, with an IP21 degree of protection. The rated current is 7.1A at 380Vac with a 4kHz frequency and a maximum current of 10.7A for 60 seconds. It is designed for wall mounting and supports Modbus and CANopen communication protocols. This 3-phase network device outputs frequencies from 0.1 to 500 Hz. It includes 1 analog output (0-10Vdc), 1 analog output (0-20mA), 6 digital inputs (24Vdc; sink/source), 1 digital output (C/O SPDT relay contact), 1 digital output (NO relay contact), and 3 analog inputs for varied voltage and current ranges. The current consumption is 10.9A at 380Vac with an Isc of 5kA and 8.3A at 500Vac. It has a rated active power of 3kW and power dissipation/losses of 125 W.

Schneider Electric

HVW701B033DN01200000

WEG HVW701B033DN01200000 - STANDARD PANEL HVW701B033DN01200000, HVAC Enclosed Drives (HVW)

WEG

M701-11404640E10101AB100

NIDEC M701-11404640E10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M701 series designed with a built-in brake transistor, single Safe Torque Off (STO), and requires an external choke with air cooling for operation. It features dimensions of frame size 11E, measuring H46.9" x W12.2" x D48.9" (H1190mm x W310mm x D312mm). This model supports RS-485 Modbus RTU communication protocol and operates with a rated current of 507A under normal duty and 464A under heavy-duty conditions. It is designed for a supply voltage of 380Vac-480Vac (400Vac / 415Vac) and can function within an ambient air temperature range of -20°C to +40°C. The device offers an IP20 degree of protection, NEMA 1 UL open, and is suitable for a 3-phase input network with a supply input frequency of 45-66 Hz and an output frequency range of 0-599 Hz. It includes 2 analog outputs (0-20mA / 4-20mA / -10...+10Vdc; source; 10-bit conversion resolution), 6 digital inputs (0-24Vdc), 4 digital outputs (0-24Vdc; source and 2A / 240Vac; source; relay contact type), and 3 analog inputs (0-20mA / 4-20mA / -10...+10Vdc; differential and single-ended; 11-bit conversion resolution). The rated active power is 315kW under normal duty and 250kW under heavy-duty, with a rated power of 450HP (normal duty) and 400HP (heavy-duty).

Nidec

I55AE255F10V11000S

Lenze I55AE255F10V11000S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed and frequency control with additional features including compact inverter DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and a PID controller. It is equipped with a built-in RFI filter, standard I.O., and conformal coating. The dimensions are H250mm x W90mm x D130mm. This model does not include a communication interface but offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It supports rated currents of 15.6A (light-duty; 400Vac), 13.2A (light-duty; 480Vac), 13A (heavy-duty; 400Vac), and 11A (heavy-duty; 480Vac) with a supply voltage of 400Vac / 480Vac. Suitable for control cabinet or surface/wall mounting, it operates within an ambient air temperature range of up to 45°C (at a switching frequency of 2kHz or 4kHz) and up to 40°C (at a switching frequency of 8kHz or 16kHz), with a degree of protection of IP20. It is designed for a 3-phase network (3P / 3AC) with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). The drive includes 1 x analog output, 5 x digital inputs with flexible functionality, 1 x digital output, and 2 x analog inputs, supporting a rated active power of 7.5kW (light-duty; 400-480Vac) and 5.5kW (heavy-duty; 400-480Vac), equivalent to 10HP (light-duty) and 7-1/2HP (heavy-duty).

Lenze

EP216-IDN-EN00

NIDEC EP216-IDN-EN00 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Indexer series designed for point-to-point positioning with air cooling. It operates within an ambient air temperature range of 0°C to +40°C and offers a degree of protection rated at IP20. This model features dimensions of H9.6" x W3.4" x D5.23" (H243.84mm x W86.3mm x D132.84mm). It is equipped with 2 analog outputs (20mA / -10...+10Vdc; single-ended; 10-bit conversion resolution), 1 analog input (-10...+10Vdc; differential; 14-bit conversion resolution), 8 digital outputs (150mA / 10-30Vdc; source), and 16 digital inputs (10-30Vdc; source). The EP216-IDN-EN00 supports a supply voltage (AC) range of 90Vac-264Vac (120Vac / 220Vac / 230Vac / 240Vac), utilizes DeviceNet RS-485 Modbus RTU for communication, and can handle a rated current of 16A. It is suitable for both single-phase input (2P) and 3-phase input (3P) networks, with a rated active power of 4.8kW.

Nidec

CFW110006B2ON1Z-PGM

DRIVE CFW110006B2ON1Z-PGM

WEG

HVW701D088T4N12-J-X

WEG HVW701D088T4N12-J-X - STANDARD PANEL HVW701D088T4N12-J-X, HVAC Enclosed Drives (HVW)

WEG

HVW701E142T4N12-I-A

WEG HVW701E142T4N12-I-A - STANDARD PANEL HVW701E142T4N12-I-A, HVAC Enclosed Drives (HVW)

WEG

HS71-03400100A10101AB100

NIDEC HS71-03400100A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the HS71 series designed for variable speed/frequency control with rated frequency outputs of 0-3000Hz in open loop and 0-1250Hz in closed loop applications. It features a built-in brake transistor and a single Safe Torque Off (STO) function, suitable for high-speed applications, and utilizes air cooling. The dimensions are frame size 3, measuring H15" x W3.3" x D7.9" (H382mm x W83mm x D200mm). It supports RS-485 communication protocol and operates with a rated current of 12.3A under normal duty and 10A under heavy-duty conditions. The supply voltage required is 380Vac-480Vac (400Vac / 415Vac), and it can operate in ambient air temperatures ranging from -20°C to +40°C. This model has an IP20 NEMA 1 UL open degree of protection and is designed for a 3-phase input network with a supply input frequency of 45-66 Hz and an output frequency of 0-3000 Hz. It includes 2 x analog outputs, 3 x digital inputs, 3 x digital outputs, and 3 x analog inputs with varying specifications for comprehensive control and feedback. The rated active power is 5.5kW under normal duty and 4kW under heavy-duty, equivalent to 7.5HP / 7-1/2HP and 5HP respectively.

Nidec

C200-09601040E10101AB100

NIDEC C200-09601040E10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the C200 series designed with an external line reactor air cooling system. It operates on a supply voltage of 500Vac-690Vac (600Vac) and has dimensions of frame size 9E H42.09" x W12.21" x D11.42" (H1069mm x W310mm x D290mm), with a degree of protection rated at IP20 NEMA 1. The rated current is 125A for Normal duty and 104A for Heavy-duty applications. It supports Modbus RTU communication protocol over a 3-phase input (3P) network with a supply input frequency of 45-66 Hz and an output frequency range of 0-550 Hz. The ambient air temperature for operation ranges from -20°C to +60°C. It features 1 x analog output (10Vdc; source; single-ended), 5 x digital inputs (0-24Vdc; PNP/NPN) plus 1 x digital input (0-24Vdc), and 1 x digital output (50mA / 0-24Vdc; source; PWM) plus 1 x digital output (2A / 240Vac; source; relay contact type). Additionally, it includes 1 x analog input (0-20mA / 4-20mA / 0-10Vdc; single-ended; 11-bit conversion resolution) and 1 x analog input (0-10Vdc; single-ended; 11-bit conversion resolution). The rated active power is 110kW for Normal duty and 90kW for Heavy-duty, with a rated power of 150HP for Normal duty and 125HP for Heavy-duty.

Nidec
