Variable Frequency Drives (VFD)

EDP11S1141GN12

STANDARD PANEL EDP11S1141GN12

WEG

I55AE240F10V11002S

Lenze I55AE240F10V11002S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed and frequency control, compact inverter DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and PID controller functionality. It features a built-in RFI filter, standard I.O. conformal coating, and utilizes the CANopen communication protocol. The device offers protection functions against overvoltage category, leakage current, earth fault resistance, and overtemperature of the motor. It supports rated currents of 11.9A (light-duty; 400Vac), 9.8A (light-duty; 480Vac), 9.5A (heavy-duty; 400Vac), and 8.2A (heavy-duty; 480Vac), with a supply voltage of 400Vac / 480Vac. Suitable for control cabinet or surface/wall mounting, it operates within an ambient air temperature range of up to 45°C (at a switching frequency of 2kHz or 4kHz) and up to 40°C (at a switching frequency of 8kHz or 16kHz), with a degree of protection of IP20. The network type is 3-phase (3P / 3AC), with network frequencies of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 x analog output (0-10Vdc; 0-20mA or 4-20mA), 5 x digital inputs (PNP/NPN logic), 1 x digital output (max. 100mA), and 2 x analog inputs (-10...+10Vdc; 0-20mA or 4-20mA). The rated active power is 5.5kW (light-duty; 400-480Vac) and 4kW (heavy-duty; 400-480Vac), with rated power of 7-1/2HP (light-duty; 400-480Vac) and 5HP (heavy-duty; 400-480Vac).

Lenze

CFW080130TGN4A1Z

WEG CFW080130TGN4A1Z - INVERTER USCFW080130T3848EON4A1Z, CFW08 / CFW500 Washdown Drives

WEG

M400-04200133A10101AB100

NIDEC M400-04200133A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M400 series designed with a built-in brake transistor and dual Safe Torque Off (STO) for air cooling. It features dimensions of frame size 4, measuring H10.9" x W4.5" x D6.9" (H277mm x W115mm x D175mm). This model supports multiple communication protocols including CANopen, DeviceNet, Ethernet/IP, Modbus RTU, Modbus TCP, PROFINET RT, and PROFIBUS DP. It operates with a rated current of 13.3A for both normal and heavy-duty applications and requires a supply voltage of 200Vac-240Vac (220Vac / 230Vac). The ambient air temperature for operation ranges from -20°C to +60°C, and it has a degree of protection of IP20 NEMA 1. It is compatible with both single-phase input (2P) and 3-phase input (3P) networks, with a supply input frequency of 45-66 Hz and an output frequency of 0-550 Hz. The device includes 2 analog outputs (0-20mA / 4-20mA / 0-10Vdc/ 0-24Vdc), 5 digital inputs plus an additional 3 digital inputs (all 0-24Vdc), and 3 digital outputs (including one 2A / 240Vac relay contact type). It also features 2 analog inputs with an 11-bit conversion resolution. The rated active power and power in HP for both normal and heavy-duty operations are 3kW and 3HP, respectively.

Nidec

EDP11S795GN12

STANDARD PANEL EDP11S795GN12

WEG

H300-08401840A10101AB103

NIDEC H300-08401840A10101AB103 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the H300 series designed with a built-in brake transistor, internal line choke, and air cooling. It features a frame size 8 with dimensions of H31.6" x W12.2" x D11.4" (H803mm x W310mm x D290mm). This model supports Modbus RTU communication protocol and operates with a rated current of 184A under normal duty. It is designed for a supply voltage of 380Vac-480Vac (400Vac / 415Vac) and can function within an ambient air temperature range of -20°C to +40°C. The device offers an IP20, NEMA 1, UL type 1 degree of protection and is suitable for a 3-phase input network with a supply input frequency of 60 Hz. It includes 2 analog outputs, 6 digital inputs (3 of which are configurable), and 1 digital input (0-24Vdc), along with 2 digital outputs (relay contact type), 1 analog input (4-20mA), and 1 analog input (0-10Vdc). The rated active power is 90kW (normal duty), equivalent to 125HP (normal duty).

Nidec

ESV752N04TFF

ESV752N04TFF Lenze Variable Frequency Drive (VFD) - The SMV 10.0 hp (7.5 kW) drive features a 400 / 480 VAC 3Ø filtered input in a fan cooled NEMA 4X (IP65) indoor/outdoor enclosure. The SMVector NEMA 4X (IP65) offers exemplary performance even in harsh environments. These decentralized drives are suitable for wall mounting and are available in two enclosure materials suitable for either indoor or outdoor use. This drive is also available with an integral disconnect switch and integrated line f

Lenze

HVW701C070T2N01-I-A

WEG HVW701C070T2N01-I-A - STANDARD PANEL HVW701C070T2N01-I-A, HVAC Enclosed Drives (HVW)

WEG

I55AE215F1AV11012S

Lenze I55AE215F1AV11012S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for compact inverter applications with DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and a PID controller. It features a built-in RFI filter, safe torque off (STO) safety standard, I.O. conformal coating, and dimensions of H250mm x W60mm x D130mm. This model supports Ethernet POWERLINK communication protocol and offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It has a rated current of 3.9A for heavy-duty applications at 400Vac and 3.5A at 480Vac, with a supply voltage of 400Vac / 480Vac. The mounting mode is suitable for control cabinet or surface/wall mounting. It operates within an ambient air temperature range, with a maximum of 45°C at a switching frequency of 2kHz or 4kHz and 40°C at 8kHz or 16kHz, featuring an IP20 degree of protection. The network type is 3-phase (3P / 3AC) with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 x analog output, multiple digital inputs with flexible functionality, 1 x digital output, and 2 x analog inputs that can be optionally used as voltage or current inputs. The rated active power is 1.5kW, and the rated power is 2HP for heavy-duty applications at 400-480Vac.

Lenze

CFW110054T2ON1Z-PGS

DRIVE CFW110054T2ON1Z-PGS

WEG

M600-11404640E10101AB100

NIDEC M600-11404640E10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M600 series designed with a built-in brake transistor, single Safe Torque Off (STO), and requires an external choke with air cooling for operation. It features dimensions of frame size 11E, measuring H46.9" x W12.2" x D48.9" (H1190mm x W310mm x D312mm), and utilizes the RS-485 Modbus RTU communication protocol. The drive operates with a rated current of 507A under normal duty and 464A under heavy-duty conditions, supported by a supply voltage range of 380Vac-480Vac (specifically 400Vac / 415Vac). It is designed for an ambient air temperature range of -20°C to +40°C and comes with an IP20 NEMA 1 degree of protection. This model is suitable for a 3-phase input network with a supply input frequency of 45-66 Hz and an output frequency range of 0-550 Hz. It includes 2 x analog outputs, 3 x digital inputs, 3 x digital outputs, and 3 x analog inputs with varying specifications detailed in the description. The rated active power is 315kW for normal duty and 250kW for heavy-duty, equivalent to 450HP and 400HP respectively.

Nidec

M000-10403200DU0100AB100

NIDEC M000-10403200DU0100AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the M000 series, designed with a built-in brake transistor and a built-in DC to AC inverter featuring air cooling. It has dimensions of frame size 10D, measuring H28.11" x W12.2" x D11.4" (H714mm x W310mm x D290mm). This model is rated for a heavy-duty current of 320A and operates on a supply voltage of 380Vac-480Vac (400Vac / 415Vac), with a network frequency supply input of 50 Hz. It offers a degree of protection of IP20 NEMA 1. The rated active power ranges from 90kW to 250kW, and the rated power is between 125HP and 400HP for heavy-duty applications.

Nidec

I55AE211A1AV01012S

Lenze I55AE211A1AV01012S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for compact inverter applications including DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and a PID controller. It adheres to the safe torque off (STO) safety standard and features an I.O. conformal coating. The dimensions are H250mm x W60mm x D130mm. It supports Ethernet POWERLINK as its communication protocol and offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. The rated current is 6A for heavy-duty applications at 120Vac, with a supply voltage of 120Vac. It is suitable for control cabinet or surface/wall mounting, operates within an ambient air temperature range of up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at a switching frequency of 8kHz or 16kHz, with an IP20 degree of protection. This single-phase device operates on a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 analog output (0-10Vdc; 0-20mA or 4-20mA), 5 digital inputs (PNP/NPN logic), 1 digital output (max. 100mA), and 2 analog inputs (-10...+10Vdc; 0-20mA or 4-20mA). The rated active power is 1.1kW, and the rated power is 1-1/2HP for heavy-duty applications at 120Vac.

Lenze

M000-09202190DU0100AB100

NIDEC M000-09202190DU0100AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the M000 series, designed with a built-in brake transistor and a built-in DC to AC inverter featuring air cooling. It has dimensions of frame size 9D, measuring H28.11" x W12.2" x D11.4" (H714mm x W310mm x D290mm). This model is rated for a heavy-duty current of 219A and operates on a supply voltage of 200Vac-240Vac (220Vac / 230Vac), with a network frequency supply input of 50 Hz. It offers a degree of protection of IP20 NEMA 1. The rated active power ranges from 90kW to 250kW for heavy-duty applications, equivalent to 125HP to 400HP.

Nidec

GA80U2012AWM

GA80U2012AWM Yaskawa - Variable frequency drive (VFD), 3 phase, 240 VAC, 12 A, Flange (Type 12 Backside), General Purpose GA800 Series

Yaskawa

M702-03200106A10101AB100

NIDEC M702-03200106A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M702 series designed with a built-in brake transistor and dual Safe Torque Off (STO) for air cooling. It features dimensions of frame size 3, measuring H14.37" x W3.27" x D7.87" (H365mm x W83mm x D200mm). This model supports multiple communication protocols including Ethernet, Ethernet/IP, Modbus TCP, and PROFINET RT. It operates with a rated current of 12.7A under normal duty and 10.6A under heavy-duty conditions. The supply voltage required is 200Vac-240Vac (220Vac / 230Vac), and it is designed to function within an ambient air temperature range of -20°C to +40°C. The degree of protection provided is IP20 NEMA 1 UL open. It is suitable for a 3-phase input network with a supply input frequency of 45-66 Hz and an output frequency range of 0-599 Hz. The device includes 2 x digital inputs (0-24Vdc, with terminal 8 configurable as a motor protection thermistor) and 3 x digital outputs (2 x 100mA / 0-24Vdc source and 1 x 2A / 240Vac source; relay contact type). The rated active power is 3kW under normal duty and 2.2kW under heavy-duty, with a rated power of 3HP for both conditions.

Nidec

SM4150

Lenze SM4150 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for variable speed and frequency control. It features dimensions of H197mm x W128mm x D182mm and operates on a supply voltage of either 400Vac or 480Vac, with rated currents of 24A at 400Vac and 21A at 460Vac. This model is suitable for control cabinet or surface/wall mounting and can operate within an ambient air temperature range of 0-40°C. Although it lacks a communication interface, it supports a network frequency of 48-62 Hz on input and 0-240 Hz on output. The SM4150 includes 1 digital output (normally open relay; contacts rated 3A at 250Vac), 1 digital output (current-sourcing; rated 50mA at 12Vdc), and 4 digital inputs (active-high) (terminal 1; 13A; 13B; 13E). It is designed for a 3-phase network (3P / 3AC) and offers a rated active power of 11kW and a rated power of 15HP at both 400Vac and 480Vac.

Lenze

HVW701B033DN01200001

WEG HVW701B033DN01200001 - STANDARD PANEL HVW701B033DN01200001, HVAC Enclosed Drives (HVW)

WEG

SP0403

NIDEC SP0403 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed with a single Safe Torque Off (STO) and air cooling feature. It has dimensions of frame size 0, measuring H12.677" x W2.441" x D8.898" (H322mm x W62mm x D226mm). The SP0403 operates on a supply voltage of 380Vac-480Vac (400Vac / 415Vac) with a rated current of 2.1A for heavy-duty applications. It is designed for wall-mounted installation and can operate in ambient air temperatures ranging from 0°C to +40°C. This model offers an IP20 NEMA 1 degree of protection and utilizes the Modbus RTU RS-485 communication protocol. The network frequency ranges from 48-65 Hz for supply input and 0-550 Hz for output. It features 3 x digital outputs (0-24Vdc; source), 1 x digital output (2A / 240Vac; source; relay contact type), 3 x digital inputs (0-24Vdc), and 3 x digital inputs (0-24Vdc). The analog inputs include 1 x analog input (-9.8Vdc...9.8Vdc; differential) with a 16-bit conversion resolution and 2 x analog inputs (0-20mA / 4-20mA / -9.8Vdc...9.8Vdc; single-ended) with a 10-bit conversion resolution. Additionally, it has 2 x analog outputs (0-20mA / 4-20mA / -10Vdc...10Vdc; single-ended; source) with a 10-bit conversion resolution. The rated active power is 0.75kW for both normal and heavy-duty operations, with a rated power of 1HP for heavy-duty applications.

Nidec

ATV312HU30N4B

Schneider Electric ATV312HU30N4B is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 312 series designed for sensorless flux vector control with an energy-saving ratio of 170-200% of the nominal motor torque. It features a built-in EMC filter and heatsink, and it is a version without a control I.O. card to allow space for a communication card. The supply voltage ranges from 323-550Vac, supporting 380Vac, 400Vac, 480Vac, and 500Vac nominal values. Its dimensions are H184mm x W142mm x D152mm, with an IP21 degree of protection. The rated current is 7.1A at 380Vac with a 4kHz frequency and a maximum current of 10.7A for 60 seconds. It is designed for wall mounting and supports Modbus and CANopen communication protocols. This 3-phase network device outputs frequencies from 0.1 to 500 Hz. It includes 1 analog output (0-10Vdc), 1 analog output (0-20mA), 6 digital inputs (24Vdc; sink/source), 1 digital output (C/O SPDT relay contact), 1 digital output (NO relay contact), and 3 analog inputs for varied voltage and current ranges. The current consumption is 10.9A at 380Vac with an Isc of 5kA and 8.3A at 500Vac. It has a rated active power of 3kW and power dissipation/losses of 125 W.

Schneider Electric
