Variable Frequency Drives (VFD)

I55AE125D10V01003S

Lenze I55AE125D10V01003S is a variable speed/frequency drive (VSD/VFD) and compact inverter designed for precise control and efficiency in automation applications. It features DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, a flying restart circuit, and a PID controller. The standard I.O. comes with a conformal coating, and its dimensions are H155mm x W60mm x D130mm. It supports Modbus RTU communication protocol and offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. The rated current is 1.7A for heavy-duty applications at 230-240Vac, and it is suitable for control cabinet or surface/wall mounting. The ambient air temperature for operation varies with the switching frequency, allowing a maximum of 45°C at 2kHz or 4kHz and 40°C at 8kHz or 16kHz. It has an IP20 degree of protection and is compatible with both single-phase and three-phase networks, with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). The device includes 1 analog output, 5 digital inputs with flexible functionality, 1 digital output, and 2 analog inputs, all designed to accommodate a wide range of control and feedback requirements. The rated active power is 0.25kW, and the rated power is 1/3HP for heavy-duty applications at 230-240Vac.

Lenze

HVW701E142T2N12-J-A

WEG HVW701E142T2N12-J-A - STANDARD PANEL HVW701E142T2N12-J-A, HVAC Enclosed Drives (HVW)

WEG

UMI-0110FU-B7

UMI-0110FU-B7 Unitronics - Unitronics VFD - B7 Series, 520-600V, 3 Phase, 11kW, 15HP, STO included

Unitronics

SL215S

Lenze SL215S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed with a built-in line filter. It features dimensions of H146mm x W96mm x D124mm and operates on a supply voltage of 200Vac-240Vac (208Vac / 220Vac / 230Vac) with a rated current of 6.9A at 208Vac and 6A at 230Vac. This part is suitable for control cabinet or surface/wall mounting and can operate within an ambient air temperature range of 0-40°C. Although it does not include a communication interface, it supports a network frequency of 48-62 Hz on input and 0-240 Hz on output. The SL215S offers 1 x digital output (normally open relay; contacts rated 3A at 250Vac), 1 x digital output (current-sourcing; rated 50mA at 12Vdc), and 4 x digital inputs (active-high) (terminal 1; 13A; 13B; 13E). It is designed for a single-phase / 1P network, with a rated active power of 1.1kW (208Vac-240Vac) and a rated power of 1-1/2HP (208Vac-240Vac).

Lenze

I55AE175F1AV11004S

Lenze I55AE175F1AV11004S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed and frequency control, compact inverter applications, DC-injection braking, brake management, S-ramps for smooth acceleration and deceleration, and includes a flying restart circuit and PID controller. It features a built-in RFI filter, safe torque off (STO) safety standard, I.O. conformal coating, and has dimensions of H180mm x W60mm x D130mm. This model supports PROFIBUS communication protocol and offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It operates with a rated current of 2.4A at 400Vac and 2.1A at 480Vac, with a supply voltage of 400Vac / 480Vac. Suitable for control cabinet or surface/wall mounting, it can operate in ambient air temperatures up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at 8kHz or 16kHz, with an IP20 degree of protection. The network type is 3-phase (3P / 3AC), with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 analog output, 5 digital inputs with flexible functionality, 1 digital output, and 2 analog inputs, supporting a rated active power of 0.75kW and rated power of 1HP at 400-480Vac.

Lenze

EDP11S033DN1201000

STANDARD PANEL EDP11S033DN1201000

WEG

HS71-04400172A10101AB100

NIDEC HS71-04400172A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the HS71 series designed for variable speed/frequency control with rated frequency outputs of 0-3000Hz in open loop and 0-1250Hz in closed loop applications. It features a built-in brake transistor and a single Safe Torque Off (STO) function suitable for high-speed applications, utilizing air cooling for temperature management. The device has dimensions of frame size 4, measuring H15.4" x W4.9" x D7.9" (H391mm x W124mm x D200mm), and supports RS-485 communication protocol. It operates with a rated current of 24A under normal duty and 17.2A under heavy-duty conditions, requiring a supply voltage of 380Vac-480Vac (400Vac / 415Vac). The operational ambient air temperature range is -20°C to +40°C, with a degree of protection rated at IP20 NEMA 1 UL open. This VSD/VFD is designed for a 3-phase input network with a supply input frequency of 45-66 Hz and an output frequency up to 3000 Hz. It includes 2 x analog outputs, 6 x digital inputs, 4 x digital outputs, and 3 x analog inputs, with the analog signals offering a 10-bit or 11-bit conversion resolution. The rated active power is 11kW for normal duty and 7.5kW for heavy-duty, corresponding to 15HP and 10HP, respectively.

Nidec

GA80U4720ABM

GA80U4720ABM Yaskawa - Variable frequency drive (VFD), 3 phase, 480 VAC, 720 A, IP20, General Purpose GA800 Series

Yaskawa

ATV71HD45N4Z

Schneider Electric ATV71HD45N4Z is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 71 series, designed for variable speed and frequency control with a U/F ratio of 2 points / 5 points. It features sensorless flux vector control, ENA System, and vector control with or without speed feedback, capable of delivering 220% of the nominal motor torque for 2 seconds and 170% of the nominal motor torque for 60 seconds. This model includes a built-in DC choke, EMC filter, non-detachable display, and built-in heatsink. It operates on a supply voltage of 323-528Vac (380Vac / 400Vac / 480Vac / 500Vac nominal), with dimensions of H630mm x W320mm x D290mm, and offers an IP20 UL type 1 degree of protection. The rated current is 94A at 380Vac (2.5kHz), 77A at 460Vac (2.5kHz), with a maximum current of 155A for 2 seconds and 141A for 60 seconds. It supports wall mounting, uses Modbus and CANopen communication protocols, and is designed for a 3-phase network with an output frequency range of 0.1-500 Hz. The unit has 1 analog output (0-10Vdc / 0-20mA), 5 digital inputs (24Vdc; sink/source) plus 1 programmable digital input and 1 PWR safety input, 3 digital outputs, and 2 analog inputs for comprehensive connectivity. The current consumption is 104A at 380Vac and 85A at 480Vac, with a rated active power of 45kW and rated power of 60HP.

Schneider Electric

ACS35503U23A14J404

MACHINERY DRIVE, 15 HP, 23.1 A, 480 VAC, Voltage Range: 380-480V, UL TYPE OPEN (IP20), Cabinet-mounted, Basic Panel, 3-Phase Input, 3-Phase Output, Frame: R3

ABB Control

CFW701D44P0T5NBN1C3

DRIVE CFW701D44P0T5NBN1C3

WEG

I55AE137A10V01004S

Lenze I55AE137A10V01004S is a Variable Speed/Frequency Drive (VSD/VFD) from the Drives sub-range, designed for compact inverter applications including DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and a PID controller. It features a standard I.O. with conformal coating, dimensions of H180mm x W60mm x D130mm, and supports PROFIBUS communication protocol. The drive offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It has a rated current of 2.4A for heavy-duty applications at 120Vac, with a supply voltage of 120Vac. Suitable for control cabinet or surface/wall mounting, it operates within an ambient air temperature range of up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at a switching frequency of 8kHz or 16kHz, with an IP20 degree of protection. The network type is single-phase / 1P, with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 analog output (0-10Vdc; 0-20mA or 4-20mA), 5 digital inputs (PNP/NPN logic), 1 digital output (max. 100mA), and 2 analog inputs (-10...+10Vdc; 0-20mA or 4-20mA). The rated active power is 0.37kW, and the rated power is 1/2HP for heavy-duty applications at 120Vac.

Lenze

M400-09501310A10101AB100

NIDEC M400-09501310A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M400 series designed with a built-in brake transistor and dual Safe Torque Off (STO) for air cooling. It features dimensions of frame size 9A, measuring H43.6" x W12.2" x D11.4" (H1107mm x W310mm x D290mm). This model supports a wide range of communication protocols including CANopen, DeviceNet, Ethernet/IP, Modbus RTU, Modbus TCP, PROFINET RT, and PROFIBUS DP. It operates with a rated current of 150A under normal duty and 131A under heavy-duty conditions, and it is designed for a supply voltage of 500Vac-575Vac. The ambient air temperature for operation ranges from -20°C to +55°C, and it offers a degree of protection of IP20 NEMA 1. The M400-09501310A10101AB100 is suitable for a 3-phase input network with a supply input frequency of 45-66 Hz and an output frequency of 0-550 Hz. It includes 2 analog outputs, 8 digital inputs, and 3 digital outputs, alongside 2 analog inputs with an 11-bit conversion resolution. The rated active power is 110kW under normal duty and 90kW under heavy-duty, corresponding to 150HP and 125HP, respectively.

Nidec

EDP11S054DN3R

STANDARD PANEL EDP11S054DN3R

WEG

GA80UT302AWM

GA80UT302AWM Yaskawa - Variable frequency drive (VFD), 12 Pulse, 480 VAC, 302 A, Flange (Type 12 Backside), General Purpose GA800 Series

Yaskawa

EDP11S105DN1201000

STANDARD PANEL EDP11S105DN1201000

WEG

I55AE125A10V01003S

Lenze i55AE125A10V01003S is a variable speed/frequency drive (VSD/VFD) or inverter within the Drives sub-range, designed for compact inverter applications including DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and a PID controller. It features a standard I.O. with conformal coating, dimensions of H180mm x W60mm x D130mm, and supports Modbus RTU communication protocol. The drive offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It has a rated current of 1.7A for heavy-duty applications at 120Vac, with a supply voltage of 120Vac. Suitable for control cabinet or surface/wall mounting, it operates within an ambient air temperature range of up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at a switching frequency of 8kHz or 16kHz, with an IP20 degree of protection. The network type is single-phase / 1P, with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 analog output, 5 digital inputs with flexible functionality, 1 digital output, and 2 analog inputs, supporting both voltage and current input/output configurations. The rated active power is 0.25kW, and the rated power is 1/3HP for heavy-duty applications at 120Vac.

Lenze

I51AE175B10V11000S

Lenze I51AE175B10V11000S is a Variable Speed/Frequency Drive (VSD/VFD) also known as a compact inverter, designed for variable speed control with additional features including DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, a flying restart circuit, and a PID controller. It incorporates a built-in RFI filter, basic input/output, and conformal coating. The dimensions are H180mm x W60mm x D130mm. This model does not include a communication interface but offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It has a rated current of 4.2A for heavy-duty applications at 230-240Vac, with a supply voltage of 230Vac / 240Vac. It is suitable for control cabinet or surface/wall mounting, operates within an ambient air temperature range of up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at a switching frequency of 8kHz or 16kHz, with an IP20 degree of protection. The network type is single-phase / 1P, with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It features 1 analog output (0-10Vdc; 0-20mA or 4-20mA), 5 digital inputs (PNP/NPN logic), 1 digital output (max. 100mA), and 2 analog inputs (0-10Vdc; 0-20mA or 4-20mA). The rated active power is 0.75kW, and the rated power is 1HP for heavy-duty applications at 230-240Vac.

Lenze

ATV71HD30N4383

Schneider Electric ATV71HD30N4383 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 71 series designed for synchronous motor control. It features a built-in DC choke, EMC filter, and heatsink, offering variable speed/frequency drive capabilities with U/F ratio (2 points / 5 points), sensorless flux vector control, ENA System, and vector control with or without speed feedback. This model can deliver 220% of the nominal motor torque for 2 seconds and 170% of the nominal motor torque for 60 seconds. It operates on a supply voltage of 323-528Vac (380Vac / 400Vac / 480Vac / 500Vac nom.), with dimensions of H550mm x W240mm x D266mm and offers a degree of protection of IP20, IP21, and UL type 1. The rated current is 66A (380Vac; 4kHz), 52A (460Vac; 4kHz), with a maximum current of 109A for 2 seconds and 99A for 60 seconds. It supports wall mounting and uses Modbus and CANopen communication protocols. Designed for a 3-phase (3P) network with an output frequency of 0.1-599 Hz, it includes 1 analog output (0-10Vdc / 0-20mA), 5 digital inputs (24Vdc; sink/source) plus 1 additional digital input programmable as discrete or PTC input and another for PWR safety, along with 3 digital outputs. It also features 2 analog inputs for comprehensive control. The current consumption is rated at 66A (380Vac) and 56A (480Vac), with a rated active power of 30kW and rated power of 40HP.

Schneider Electric

F600-06500120A10101AB653

NIDEC F600-06500120A10101AB653 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for 3-phase input with a supply voltage range of 500Vac-575Vac and a network frequency of 60 Hz. It features a built-in brake transistor, an internal line choke, and air cooling for its operation. The device operates within an ambient air temperature range of -20°C to +40°C and offers a degree of protection rated at IP65. It has dimensions of frame size 6, measuring H15.4" x W8.3" x D8.9" (H391mm x W210mm x D227mm). For connectivity, it includes 1 x analog input (4-20mA / 0-10Vdc; single-ended), 1 x analog output (0-10Vdc), 3 x digital inputs (24Vdc), 3 x digital inputs (0-24Vdc; configurable), and 2 x digital outputs (240Vac; relay contact type). The F600 series drive supports Modbus RTU communication protocol, has a rated current of 12A (Normal duty), a rated active power of 7.5kW (Normal duty), and a rated power of 10HP (Normal duty).

Nidec
