Variable Frequency Drives (VFD)

H300-07401120A10101AB103

NIDEC H300-07401120A10101AB103 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the H300 series designed with a built-in brake transistor, internal line choke, and air cooling. It features dimensions of frame size 7, measuring H21.9" x W10.6" x D11" (H557mm x W270mm x D280mm). This model supports Modbus RTU communication protocol and operates with a rated current of 112A under normal duty. It is designed for a supply voltage of 380Vac-480Vac (400Vac / 415Vac) and can function within an ambient air temperature range of -20°C to +40°C. The device offers an IP20, NEMA 1, UL type 1 degree of protection and is suitable for a 3-phase input network with a supply input frequency of 60 Hz. It includes 2 analog outputs, 6 digital inputs (3 x 24Vdc and 3 x 24Vdc/configurable), 1 digital input (0-24Vdc), and 2 digital outputs (relay contact type), alongside 1 analog input (4-20mA) and 1 analog input (0-10Vdc). The rated active power is 55kW, and the rated power is 75HP under normal duty conditions.

Nidec

QMP350A4

NIDEC QMP350A4 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for 2 quadrant operation with air cooling. It operates within an ambient air temperature range of 0°C to +55°C and has a rated current of 350A. This model supports a supply voltage range of 208Vac-480Vac, accommodating various standard voltages such as 220Vac, 230Vac, 240Vac, 380Vac, 400Vac, and 415Vac. The dimensions of the QMP350A4 are frame size 2A, measuring H38.5" x W20.3" x D13.5" (H978mm x W516mm x D343mm), and it has a degree of protection rated at IP00. It is designed for a single-phase input network (2P) and uses the Modbus RTU communication protocol. The device features 3 x digital outputs (240mA / 0-24Vdc; source) and 2 x digital outputs (5A / 240Vac; source; relay contact type), along with 1 x analog input (-10Vdc...10Vdc; differential) and 2 x analog inputs (0-20mA / 4-20mA / -10Vdc...10Vdc; single-ended). Additionally, it includes 3 x digital inputs (0-24Vdc) and 2 x analog outputs (0-20mA / 4-20mA / -10Vdc...10Vdc; source; single-ended). The rated active power is 125kW, and the rated power is 200HP.

Nidec

CFW500B04P3T4DBN1

WEG CFW500B04P3T4DBN1 - DRIVE CFW500B04P3T4DBN1, CFW500/700 Drives

WEG

M702-05500040A10101AB100

NIDEC M702-05500040A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M702 series designed with a built-in brake transistor and dual Safe Torque Off (STO) for air cooling. It features dimensions of frame size 5, measuring H14.37" x W5.63" x D7.87" (H365mm x W143mm x D200mm). This model supports multiple communication protocols including Ethernet, Ethernet/IP, Modbus TCP, and PROFINET RT. It operates with a rated current of 6.1A under normal duty and 4A under heavy-duty conditions, with a supply voltage range of 500Vac-575Vac. The ambient air temperature for operation is specified from -20°C to +40°C. It has an IP20, NEMA 1, and UL open degree of protection. The network type is a 3-phase input (3P) with a supply input frequency of 45-66 Hz and an output frequency range of 0-599 Hz. It includes 2 x digital inputs (0-24Vdc, with terminal 8 configurable as a motor protection thermistor), 2 x digital outputs (100mA / 0-24Vdc; source), and 1 x digital output (2A / 240Vac; source; relay contact type). The rated active power is 4kW under normal duty and 2.2kW under heavy-duty, corresponding to 5HP and 3HP, respectively.

Nidec

ATV71HU15M3Z

Schneider Electric ATV71HU15M3Z is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 71 series. It features variable speed/frequency drive capabilities with U/F ratio (2 points / 5 points), sensorless flux vector control, ENA System, and vector control with or without speed feedback. It can deliver 220% of the nominal motor torque for 2 seconds and 170% of the nominal motor torque for 60 seconds. The design includes a built-in EMC filter, a non-detachable display, and a built-in heatsink. It operates on a supply voltage of 170-264Vac (200Vac / 220Vac / 230Vac / 240Vac nom.) and has dimensions of H230mm x W130mm x D175mm. The degree of protection is IP20, IP21, UL type 1. The rated current is 8A (230Vac; 4kHz; 3-phase), 4.8A (230Vac; 4kHz; single-phase), with maximum currents of 7.9A (single-phase; for 2s), 13.2A (3-phase; for 2s), 7.2A (single-phase; for 60s), and 12A (3-phase; for 60s). It supports wall mounting and uses Modbus and CANopen communication protocols. It is compatible with single-phase (1P) / 3-phase (3P) networks and offers an output frequency range of 0.1-599 Hz. The device includes 1 analog output (0-10Vdc / 0-20mA), 5 digital inputs (24Vdc; sink/source) programmable (LI1-LI5), 1 digital input programmable as discrete or PTC input (LI6), 1 digital input (PWR safety input), 1 digital output (C/O SPDT relay contact) (R1), and 2 digital outputs (NO relay contacts) (R2). It also features 1 analog input (-10...+10Vdc) and 1 analog input (0-10Vdc / 0-20mA). The current consumption is 12A (200Vac; 0.75kW; single-phase), 9.6A (240Vac; 1.5kW; 3-phase), 9.9A (240Vac; 0.75kW; single-phase), and 11.3A (200Vac; 1.5kW; 3-phase). The rated active power is 1.5kW (3-phase) and 750W / 0.75kW (single-phase), with a rated power of 2HP (3-phase) and 1HP (single-phase).

Schneider Electric

GA80UT371AAM

GA80UT371AAM Yaskawa - Variable frequency drive (VFD), 12 Pulse, 480 VAC, 371 A, IP00, General Purpose GA800 Series

Yaskawa

HVW701B017GN01200001

WEG HVW701B017GN01200001 - STANDARD PANEL HVW701B017GN01200001, HVAC Enclosed Drives (HVW)

WEG

UMI-2500EU-B7

UMI-2500EU-B7 Unitronics - Unitronics VFD - B7 Series, 380-480V, 3 Phase, 250kW, 350HP, STO included

Unitronics

ESV183N06TMD

ESV183N06TMD Lenze Variable Frequency Drive (VFD) - The SMV 25.0 hp (18.5 kW) drive features a 480 / 600 VAC 3Ø input with input disconnect in a fan cooled NEMA 4X (IP65) indoor enclosure. The SMVector NEMA 4X (IP65) offers exemplary performance even in harsh environments. These decentralized drives are suitable for wall mounting and are available in two enclosure materials suitable for either indoor or outdoor use. This drive is also available with an integral disconnect switch and integrated l

Lenze

C200-01200033A10101AB100

NIDEC C200-01200033A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the C200 series designed with air cooling. It operates on a supply voltage of 200Vac-240Vac (220Vac / 230Vac) and has dimensions of frame size 1 H6.3" x W2.95" x D5.1" (H160mm x W75mm x D130mm). This model offers a degree of protection of IP20 NEMA 1 and is rated for a current of 3.3A for both normal and heavy-duty operations. It supports Modbus RTU communication protocol over a single-phase input (2P) network with a frequency range of 45-66 Hz for supply input and 0-550 Hz for output. The ambient air temperature for operation ranges from -20°C to +60°C. It features 1 x analog output (10Vdc; source; single-ended), 5 x digital inputs (0-24Vdc; PNP/NPN) plus 1 x digital input (0-24Vdc), and 2 x digital outputs (one 50mA / 0-24Vdc; source; PWM and one 2A / 240Vac; source; relay contact type). Additionally, it includes 2 x analog inputs (one 0-20mA / 4-20mA / 0-10Vdc; single-ended; 11-bit conversion resolution and one 0-10Vdc; single-ended; 11-bit conversion resolution). The rated active power is 0.55kW and the rated power is 3/4HP for both normal and heavy-duty applications.

Nidec

SP3201-HF

NIDEC SP3201-HF is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for high frequency applications up to 3000Hz max in an open-loop configuration with a single Safe Torque Off (STO) and air cooling. It features a frame size 3 with dimensions of H15.32" x W9.84" x D10.23" (H389mm x W250mm x D260mm), and operates on a supply voltage of 200Vac-240Vac (220Vac / 230Vac). The rated current is 42A under normal duty and 31A under heavy-duty conditions. This wall-mounted unit is designed to operate within an ambient air temperature range of 0°C to +40°C and has a degree of protection rated at IP20 NEMA 1. It supports Modbus RTU RS-485 communication protocol, with a network frequency of 48-65 Hz on the supply input and 0-3000 Hz on the output. The SP3201-HF includes 3 x digital outputs (0-24Vdc; source), 1 x digital output (2A / 240Vac; source; relay contact type), 3 x digital inputs (0-24Vdc), and analog inputs comprising 1 x (-9.8Vdc...9.8Vdc; differential) and 2 x (0-20mA / 4-20mA / -9.8Vdc...9.8Vdc; single-ended) with a 10-bit conversion resolution. Analog outputs include 2 x (0-20mA / 4-20mA / -10Vdc...10Vdc; single-ended; source) with a 10-bit conversion resolution. The rated active power is 11kW for normal duty and 7.5kW for heavy-duty, corresponding to 15HP and 10HP, respectively.

Nidec

I55AE155F10V11003S

Lenze I55AE155F10V11003S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed and frequency control, compact inverter functionality, DC-injection braking, brake management, S-ramps for smooth acceleration and deceleration, flying restart circuit, and PID controller operations. It features a built-in RFI filter, standard I.O. conformal coating, and dimensions of H180mm x W60mm x D130mm. This model supports Modbus RTU communication protocol and includes protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It operates with a rated current of 1.8A at 400Vac and 1.6A at 480Vac, with a supply voltage of 400Vac / 480Vac. Suitable for control cabinet or surface/wall mounting, it can operate within an ambient air temperature of up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at 8kHz or 16kHz, with an IP20 degree of protection. The network type is 3-phase (3P / 3AC), with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 analog output, 5 digital inputs with optional uses, 1 digital output, and 2 analog inputs with optional uses. The rated active power is 0.55kW, and the rated power is 3/4HP for heavy-duty applications at 400-480Vac.

Lenze

H300-07200750A10101AB103

NIDEC H300-07200750A10101AB103 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the H300 series designed with a built-in brake transistor, internal line choke, and air cooling. It features a frame size 7 with dimensions of H21.9" x W10.6" x D11" (H557mm x W270mm x D280mm). This model supports Modbus RTU communication protocol and operates with a rated current of 75A under normal duty. It is designed for a supply voltage of 200Vac-240Vac (220Vac / 230Vac) and can function within an ambient air temperature range of -20°C to +40°C. The device offers an IP20, NEMA 1, UL type 1 degree of protection and is suitable for a 3-phase input network with a supply input frequency of 60 Hz. It includes 2 analog outputs, 6 digital inputs (3 x 24Vdc and 3 x 24Vdc/configurable), 1 digital input (0-24Vdc), and 2 digital outputs (relay contact type), along with 1 analog input (4-20mA) and 1 analog input (0-10Vdc). The rated active power is 18.5kW, and the rated power is 25HP under normal duty conditions.

Nidec

C300-07600240A10101AB100

NIDEC C300-07600240A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the C300 series designed with dual Safe Torque Off (STO) and air cooling. It operates on a supply voltage of 500Vac-690Vac (600Vac) and is housed within a frame size 7, measuring H21.93" x W10.63" x D11.02" (H557mm x W270mm x D280mm). This model offers a degree of protection rated at IP20 NEMA 1 and supports a rated current of 30A under normal duty and 24A under heavy-duty conditions. Communication is facilitated via Modbus RTU over a 3-phase input network, with a network frequency range of 45-66 Hz for supply input and 0-550 Hz for output. It is designed to operate within an ambient air temperature range of -20°C to +60°C. The unit features 1 analog output (10Vdc; source; single-ended), 5 digital inputs (0-24Vdc; PNP/NPN) plus 1 additional digital input (0-24Vdc), and 2 digital outputs (one 50mA / 0-24Vdc; source; PWM and another 2A / 240Vac; source; relay contact type). It also includes 2 analog inputs with one supporting 0-20mA / 4-20mA / 0-10Vdc (single-ended; 11-bit conversion resolution) and the other 0-10Vdc (single-ended; 11-bit conversion resolution). The rated active power is 22kW under normal duty and 18.5kW under heavy-duty, corresponding to a rated power of 30HP and 25HP, respectively.

Nidec

EDP11S180GN12

STANDARD PANEL EDP11S180GN12

WEG

EDP11S370GN1210000

STANDARD PANEL EDP11S370GN1210000

WEG

CFW701B10P0T5DBN1C3

DRIVE CFW701B10P0T5DBN1C3

WEG

I55AE230F10V1100KS

Lenze I55AE230F10V1100KS is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed and frequency control, compact inverter DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and PID controller functionalities. It features a built-in RFI filter, standard I.O. conformal coating, and supports EtherCAT communication protocol. The device offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It operates with a rated current of 8.8A for light-duty at 400Vac, 7.6A for light-duty at 480Vac, 7.3A for heavy-duty at 400Vac, and 6.3A for heavy-duty at 480Vac. The supply voltage is 400Vac / 480Vac, suitable for control cabinet or surface/wall mounting. The ambient air temperature for operation can reach up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at 8kHz or 16kHz, with a degree of protection of IP20. It is designed for a 3-phase network (3P / 3AC), with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). The device includes 1 analog output (0-10Vdc; 0-20mA or 4-20mA), 5 digital inputs (PNP/NPN logic), 1 digital output (max. 100mA), and 2 analog inputs (-10...+10Vdc; 0-20mA or 4-20mA). It has a rated active power of 4kW for light-duty and 3kW for heavy-duty at 400-480Vac, corresponding to 5HP for light-duty and 4HP for heavy-duty.

Lenze

HS30-01200017A10101AB100

NIDEC HS30-01200017A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) from the HS30 series designed for high-speed applications with a rated frequency output of 0-3000Hz in open loop. It features a built-in brake transistor and dual Safe Torque Off (STO) functionality, utilizing air cooling for temperature management. The device has dimensions of frame size 1, measuring H6.3" x W3" x D5.1" (H160mm x W75mm x D130mm). It supports multiple communication protocols including CANopen, DeviceNet, Ethernet/IP, Modbus RTU, Modbus TCP, PROFINET RT, and PROFIBUS DP. The drive operates with a rated current of 1.7A for both normal and heavy-duty applications and requires a supply voltage of 200Vac-240Vac (220Vac / 230Vac). It is designed to function within an ambient air temperature range of -20°C to +55°C and has a degree of protection rated at IP20 NEMA 1. This VSD/VFD is suitable for single-phase input (2P) networks with a supply input frequency of 45-66 Hz and an output frequency of 0-3000 Hz. It includes 1 analog output, 5 digital inputs plus an additional digital input, 2 digital outputs, and 2 analog inputs with an 11-bit conversion resolution. The rated active power is 0.25kW, and the rated power is 1/3HP for both normal and heavy-duty operations.

Nidec

EDP11S477GN3R

STANDARD PANEL EDP11S477GN3R

WEG
