Contactors

BFK8000A110

BFK8000A110 Lovato - Contactor for power factor correction with AC control circuit, including limiting resistors, maximum IEC operational power 400V = 50kvar, coil 110VAC 50/60Hz

Lovato Electric

CWB32-11-30C02

WEG CWB32-11-30C02 - CONTACTOR CWB32-11-30C02, Contactors (CWB)

WEG

LC2D12JD

Schneider Electric LC2D12JD is a pre-assembled reversing magnetic contactor from the Deca sub-range, featuring a mechanical interlock and screw connections. It has 2 x 3-poles (2x3P; 2x3NO) with a rated current of 25A (AC-1) and 12A (440Vac; AC-3). The contactor offers a degree of protection of IP20 and operates with a control voltage (DC) of 9-15Vdc (12Vdc nom.; 0.75...1.25 x Uc). Its rated operating voltage (Ue) is 690 V, and it includes 2 Normally Open (NO) auxiliary contacts and 2 Normally Closed (NC) auxiliary contacts. The rated impulse voltage (Uimp) is 6 kV. The rated active power (kW) spans from 3kW at 220-230Vac to 7.5kW at 660-690Vac, all within AC-3 classification. It also features 1NO+1NC instantaneous auxiliary contacts per contactor. The rated power (HP) ranges from 0.5HP at 115Vac to 10HP at 575-600Vac, accommodating various single-phase and 3-phase configurations under UL/CSA standards. The rated voltage (AC) for phase-to-phase connections is 690 V.

Schneider Electric

11B630L00110110

11B630L00110110 Lovato - Three-pole contactor, IEC operating current Ie (AC3) = 630A, AC/DC coil, already fitted with mechanical latch (G495), 110...125VAC/DC, mechanical latch 110...125VAC

Lovato Electric
