15009ET3G449T-W22 WEG AC Motors
Part#:15009ET3G449T-W22
Manufacturer:WEG
Alt. Part#:7909018744766
Product Lifecycle:Active
Get a quick Quote!
W22 NEMA Premium Efficiency 150 HP 8P 447/9T 3Ph 460 V 60 Hz IC411 - TEFC - Foot-mounted
Check out the 15009ET3G449T-W22 WEG price in the box on the right side or send a quick quote.
Product Details
- Output Rating150 HP
- Rated Speed890 rpm
- Number of Poles8 Pole
- Voltage460 V
- Flange TypeWithout
- Frequency 60 Hz
- Locked rotor torque 200 %
- Duty Cycle Cont.(S1)
- Rotation¹ Both (CW and CCW)
- Rated speed 890 rpm
- Locked rotor time 32s (cold) 18s (hot)
- Enclosure IC411 - TEFC
- Frame 447/9T
- No load current 84.3 A
- Temperature rise 80 K
- Noise level² 66.0 dB(A)
- Output rating 150 HP
- Slip 1.11 %
- Moment of inertia (J) 161 sq.ft.lb
- Voltage 460 V
- Rated voltage 460 V
- Design B
- Altitude 1000 m.a.s.l.
- Terminal box¹ Left position
- Output 150 HP (110 kW)
- Rated torque 885 ft.lb
- Starting Method Direct On Line
- Approx. weight³ 2858 lb
- Service factor 1.15
- L. R. Amperes 1178 A
- Mounting F-1
- Number of Poles 8
- Breakdown torque 220 %
- Ambient temperature -20°C to +40°C
- Standard NEMA MG-1
- LRC 6.2x(Code G)
- Number of poles 8
- Insulation Class F
- Degree of Protection IP55
- Rated current 190 A
- Flange Without
- Synchronous speed 900 rpm
