LP4K09015BW3 Schneider Electric Industrial Automation Components
Part#:LP4K09015BW3
Manufacturer:Schneider Electric
Product Lifecycle:Active
Get a quick Quote!
Schneider Electric LP4K09015BW3 is a magnetic contactor within the K sub-range, featuring solder pins connections and a 3-pole (3P; 3NO) configuration. It has a rated current of 20A under AC-1 conditions and 9A at 440Vac under AC-3 conditions. This contactor is designed with an IP20 degree of protection and operates with a control voltage (DC) range of 16.8-31.2Vdc, nominally at 24Vdc (0.7...1.3 x Uc). The rated operating voltage (Ue) is up to 690 V, and it does not have Normally Open (NO) auxiliary contacts but includes 1 Normally Closed (NC) auxiliary contact. The rated active power varies with voltage, offering 2.2kW at 220-230Vac, and 4kW across 380-415Vac, 440Vac, 500Vac, and 660-690Vac, all under AC-3 conditions. Its mechanical durability is rated at 30 million operations at no load, with a power consumption of 1.8 W and a phase-to-phase rated voltage (AC) of 690 V.
About the manufacturer: Schneider Electric is one of the manufacturers that offers Industrial Automation Components that you can order at marketplace.quotebeam.com. We provide digital solutions for energy and automation that improve efficiency and support sustainability. Our comprehensive solutions include cutting-edge energy technologies, real-time automation, software, and services for residential, commercial, and industrial settings.
Check out the LP4K09015BW3 Schneider Electric price in the box on the right side or send a quick quote.
Product Details
- Overvoltage Category III
- Hold-In Power Consumption In W 1.8 W 68 °F (20 °C)
- Poles Description 3P
- Mounting Support Printed circuit boards
- Minimum Switching Current 5 mA signalling circuit
- [Uimp] Rated Impulse Withstand Voltage 8 kV
- Average Impedance 3 mOhm - Ith 20 A 50 Hz power circuit
- Product Or Component Type Contactor
- Pole Contact Composition 3 NO
- Inrush Power In W 1.8 W 68 °F (20 °C))
- Depth 2.24 in (57 mm)
- Mechanical Durability 30 Mcycles
- Range Of Product TeSys K
- Auxiliary Contacts Type type instantaneous 1 NC
- Width 1.77 in (45 mm)
- Height 2.28 in (58 mm)
- Net Weight 0.52 lb(US) (0.235 kg)
- Device Short Name LP4K
- Auxiliary Contact Composition 1 NC
- Minimum Switching Voltage 17 V signalling circuit
- Range TeSys
- Coil Technology Built-in bidirectional peak limiting diode suppressor
- Maximum Operating Rate 3600 cyc/h
- Insulation Resistance > 10 MOhm for signalling circuit
- Contactor Application Resistive load Motor control
- Safety Reliability Level B10d = 1369863 cycles contactor with nominal load EN/ISO 13849-1 B10d = 20000000 cycles contactor with mechanical load EN/ISO 13849-1
- [Ith] Conventional Free Air Thermal Current 20 A 122 °F (50 °C) power circuit 10 A 122 °F (50 °C) signalling circuit
- Control Circuit Voltage Limits Operational 0.7...1.30 Uc 122 °F (50 °C)) Drop-out 0.1...0.7 Uc 122 °F (50 °C))
- Operating Time 10...20 ms coil de-energisation and NO opening 30...40 ms coil energisation and NO closing
- [Ue] Rated Operational Voltage Power circuit 690 V AC 50/60 Hz Signalling circuit <= 690 V AC 50/60 Hz
- Utilisation Category AC-3 AC-4 AC-1
- [Ie] Rated Operational Current 20 A 122 °F (50 °C)) <= 440 V AC AC-1 power circuit 9 A<= 440 V AC AC-3 power circuit 16 A 158 °F (70 °C)) 690 V AC AC-1 power circuit
- Flame Retardance V1 conforming to UL 94 Requirement 2 conforming to NF F 16-101 Requirement 2 conforming to NF F 16-102
- Irms Rated Making Capacity 110 A AC power circuit NF C 63-110 110 A AC power circuit IEC 60947 110 A AC signalling circuit IEC 60947
- Associated Fuse Rating 25 A gG <= 440 V power circuit 25 A aM power circuit 10 A gG signalling circuit IEC 60947 10 A gG signalling circuit VDE 0660
- Rated Breaking Capacity 110 A 415 V IEC 60947 110 A 440 V IEC 60947 80 A 500 V IEC 60947 110 A 220...230 V IEC 60947 110 A 380...400 V IEC 60947 70 A 660...690 V IEC 60947
- [Ui] Rated Insulation Voltage Power circuit 600 V UL 508 Power circuit 690 V IEC 60947-4-1 Signalling circuit 690 V IEC 60947-4-1 Signalling circuit 690 V IEC 60947-5-1 Signalling circuit 600 V UL 508 Power circuit 600 V CSA C22.2 No 14 Signalling circuit
