YS36L Hubbell Industrial Automation Components
Part#:YS36L
Manufacturer:Hubbell
Product Lifecycle:Active
Get a quick Quote!
600 kcmil CU, Standard Barrel, Internal Chamfer, Tin Plated, UL/CSA, 90°C, Up to 35kV, GREEN Color Code, 22 or 472 Die Index ; Features: Standard Barrel Length, Ideal For Limited Space Applications While Providing Ample Barrel Length For Proper Crimp, Fo
About the manufacturer: Hubbell is one of the manufacturers that offers Industrial Automation Components that you can order at marketplace.quotebeam.com. Hubbell offers a variety of products that are specifically designed to tackle challenges faced by businesses, increase energy efficiency, enhance safety, perform well in harsh environments, streamline wiring organization, and improve grounding systems in and around buildings.
Check out the YS36L Hubbell price in the box on the right side or send a quick quote.
Product Details
- Color Code Green
- Feature - Barrel Type Standard
- Dimension - L Length Overall mm 82 mm
- Conductor - Copper Str Compact Size 600
- UPC 781810526408
- Certification - cULus No
- UL Listed Yes
- Plating Type Tin - Electro Plated
- Dimension - Length Overall inch 3.22 in
- Conductor - Copper Str Size 600 kcmil
- Certification - UL Recognized No
- UPC 12 Digit 7818105264088
- Minimum Pack Quantity 1
- Sub Brand HYLINK
- Feature - Barrel Style Chamfered
- Trade Name HYLINK™
- Voltage Rating 35 kV
- Wire Size 600 kcmil
- Industry Standard(s) UL 486A-486B
- Rating - KVA 35 kV
- EU RoHS Indicator Yes
- Plated Y
- Dimension - B Length fraction 1-3/8 in
- Connector Type Splice
- Voltage - Maximum 35000
- Conductor - Copper Str Size Range 600 kcmil
- Standards - Industry Standards Met UL 486A-486B
- Die Index 22 or 472
- Dimension - Strip Length inch 1-7/16
- Type YS-L, Standard Barrel
- Certification - ETL No
- Dimension - B Length inch 1.38 in
- Certification - CSA Approved Yes
- Standards - RoHS Compliance Status CM
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
Related documents YS36L Specs
