YS34 Hubbell Industrial Automation Components
Part#:YS34
Manufacturer:Hubbell
Product Lifecycle:Active
Get a quick Quote!
500 kcmil CU, Long Barrel, Internal Chamfer, Tin Plated, UL/CSA, 90°C, Up to 35kV, BROWN Color Code, 20 or 299 Die Index ; Features: UL Listed 90 DEG C, 600 Volts to 35 kV, Long Barrel Length: Ideal For 600 Volt Heavy Duty Applications, Also May Be Used
About the manufacturer: Hubbell is one of the manufacturers that offers Industrial Automation Components that you can order at marketplace.quotebeam.com. Hubbell offers a variety of products that are specifically designed to tackle challenges faced by businesses, increase energy efficiency, enhance safety, perform well in harsh environments, streamline wiring organization, and improve grounding systems in and around buildings.
Check out the YS34 Hubbell price in the box on the right side or send a quick quote.
Product Details
- Connector Type Splice
- Feature - Barrel Style Chamfered
- Sub Brand HYLINK
- Type YS, Long Barrel
- Dimension - Strip Length inch 2-1/4
- Standards - RoHS Compliance Status CM
- Certification - CSA Approved Yes
- Finish Type Tin-Plated
- Trade Name HYLINK™
- Dimension - B Length inch 2.20 in
- Voltage - Maximum 35000
- Standards - Industry Standards Met UL 486A-486B
- Wire Size 500 kcmil
- Die Index 20 or 299
- Plating Type Tin - Electro Plated
- Dimension - L Length Overall mm 125 mm
- Conductor - Copper Str Size 500 kcmil
- Industry Standard(s) UL 486A-486B
- Material Copper
- EU RoHS Indicator Yes
- Plated Y
- Application Wire Splice
- UPC 12 Digit 7818105085033
- Rating - KVA 35 kV
- Voltage Rating 35 kV
- Certification - ETL No
- Certification - UL Recognized No
- Color Code Brown
- Feature - Barrel Type Long
- UPC 781810508503
- Dimension - Length Overall inch 4.91 in
- Conductor - Copper Str Size Range 500 kcmil
- Certification - cULus No
- UL Listed Yes
- Minimum Pack Quantity 1
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
Related documents YS34 Specs
