M18GRYPQ Banner Indicator Lights
Part#:M18GRYPQ
Manufacturer:Banner
Alt. Part#:74039
Product Lifecycle:Active
In-stock parts: 1
Jun 20, 2025
EZ-LIGHT: Nickel-Plated Brass Housing M18x1 Threa; 3-Color General Purpose; Green Red Yellow Light; Steady Display; PNP (Sourcing): Encapsulated IP67; M12 Integral QD
About the manufacturer: Banner is one of the manufacturers that offers Indicator Lights that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the M18GRYPQ Banner price in the box on the right side or send a quick quote.
Product Details
- Weight72.57472 g
- Country Of OriginUS
- Housing Style Barrel Mount - Flat Window
- Color Technology Standard LED
- Indication Yes
- Color Option 2 Red
- Max Op. Temperature (°C) 50
- Modbus RTU No
- Primary Housing Material Nickel-Plated Brass
- Max Current Color (mA) 25
- Supply Voltage 10-30 V dc
- Feature: Hazardous Area No
- Power DC
- Quick Disconnect Type M12 (Euro)
- Max Input Response Time (ms) 1
- Feature: Quick Disconnect Yes
- Cable Length (m) 0.15
- Product Size (mm) 18
- Environmental Rating IP67
- Multi-Color Device Single Color On
- Number of Colors / Segments 3
- Animation Option 1 Solid On
- Min Op. Temperature (°C) -40
- IO Link No
- Mounting Thread M18 x 1.0
- Connection Integral QD
- Primary Window Material Thermoplastic Diffused
- Pro-Editor Compatible (Discrete) No
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Color Option 3 Yellow
- Physical Dimensions (LxWxH or DxH mm) 16.5 x 70.4
- Feature: Chemical Resistant No
- Power Source DC
- Color Option 1 Green
- Input Type PNP
- Feature: Audible No
- Number of Input Pins/Conductors 4
- Wireless No
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
M18GRYPQ Description
Banner Engineering M18GRYPQ is a pilot light from the EZ-LIGHT series designed with a 3-color G/R/Y color pattern LED illumination for clear indication. It features a black housing with a round protruding window and a threaded cylindrical barrel made from nickel-plated brass and a thermoplastic diffused window. This part is equipped with a 4-pin M12 Euro-style QD connector for connectivity and operates on a supply voltage of 10Vdc-30Vdc (12Vdc-24Vdc nom.). It is designed for flush mounting in an 18mm hole with an M18 thread. The indicator has a diameter of 18mm and can operate in ambient air temperatures ranging from -40°C to +50°C. It offers a degree of protection of IP67, consumes 25mA of current, and includes 3 x digital inputs (10-30Vdc; PNP) for color control.
Related documents M18GRYPQ Specs
This item can ship within 24h!
1-year warranty
$122.04
