M18GRXPQ Banner Indicator Lights
Part#:M18GRXPQ
Manufacturer:Banner
Alt. Part#:76375
Product Lifecycle:Active
In-stock parts: 3
Jun 20, 2025
M18 Series EZ-LIGHT: 2-Color General Purpose Indicator; Voltage: 10-30 V dc; Housing: Nickel-Plated Brass; Input: PNP; Colors: Green Red; M12 Integral QD
About the manufacturer: Banner is one of the manufacturers that offers Indicator Lights that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the M18GRXPQ Banner price in the box on the right side or send a quick quote.
Product Details
- Weight68.0388 g
- Country Of OriginUS
- Supply Voltage 10-30 V dc
- Feature: Audible No
- Primary Housing Material Nickel-Plated Brass
- Max Current Color (mA) 25
- Wireless No
- Modbus RTU No
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Connection Integral QD
- Environmental Rating IP67
- Cable Length (m) 0.15
- Color Option 1 Green
- Number of Input Pins/Conductors 4
- Feature: Chemical Resistant No
- Color Technology Standard LED
- Color Option 2 Red
- Primary Window Material Thermoplastic Diffused
- IO Link No
- Indication Yes
- Quick Disconnect Type M12 (Euro)
- Min Op. Temperature (°C) -40
- Multi-Color Device Single Color On
- Power Source DC
- Animation Option 1 Solid On
- Physical Dimensions (LxWxH or DxH mm) 16.5 x 70.4
- Mounting Thread M18 x 1.0
- Product Size (mm) 18
- Max Op. Temperature (°C) 50
- Number of Colors / Segments 2
- Housing Style Barrel Mount - Flat Window
- Max Input Response Time (ms) 1
- Pro-Editor Compatible (Discrete) No
- Power DC
- Input Type PNP
- Feature: Hazardous Area No
- Feature: Quick Disconnect Yes
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
M18GRXPQ Description
Banner Engineering M18GRXPQ is a pilot light from the EZ-LIGHT series designed with a 2-color G/R color pattern LED illumination for clear indication. This part features a black housing with a round protruding window and a threaded cylindrical barrel made from nickel-plated brass and a thermoplastic diffused window. It is pre-equipped with a 4-pin M12 Euro-style QD connector for easy connection. The supply voltage requirement ranges from 10Vdc to 30Vdc, with a nominal range of 12Vdc to 24Vdc. It is designed for flush mounting in an 18mm hole with an M18 thread. The indicator has a diameter of 18mm and can operate in ambient air temperatures ranging from -40°C to +50°C. It boasts an IP67 degree of protection, ensuring durability in various environmental conditions. The current consumption is 25mA, and it includes 2 x digital inputs (10-30Vdc; PNP) for color control.
