M18GRY2PQ Banner Indicator Lights
Part#:M18GRY2PQ
Manufacturer:Banner
Alt. Part#:74051
Product Lifecycle:Active
In-stock parts: 10
Jun 20, 2025
EZ-LIGHT: In-line 18 mm Barrel Housing; 3-Color 7-Function; Red Green Yellow Light; Flash or Cycle; PNP Hookup; M12 Integral QD
About the manufacturer: Banner is one of the manufacturers that offers Indicator Lights that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the M18GRY2PQ Banner price in the box on the right side or send a quick quote.
Product Details
- Weight72.57472 g
- Country Of OriginUS
- Power DC
- Wire Selectable Function Multi-Function
- Pro-Editor Compatible (Discrete) No
- Feature: Hazardous Area No
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Product Size (mm) 18
- Color Option 3 Yellow
- Feature: Quick Disconnect Yes
- Power Source DC
- Color Technology Standard LED
- Supply Voltage 10-30 V dc
- Multi-Color Device Single Color On
- Animation Option 1 Solid On
- Max Input Response Time (ms) 250
- Feature: Chemical Resistant No
- Number of Colors / Segments 3
- Indication Yes
- Max Current Color (mA) 40
- IO Link No
- Color Option 1 Green
- Input Type PNP
- Primary Window Material Thermoplastic Diffused
- Cable Length (m) 0.15
- Connection Integral QD
- Feature: Audible No
- Min Op. Temperature (°C) -20
- Mounting Thread M18 x 1.0
- Number of Input Pins/Conductors 5
- Max Op. Temperature (°C) 50
- Primary Housing Material Nickel-Plated Brass
- Quick Disconnect Type M12 (Euro)
- Modbus RTU No
- Environmental Rating IP67
- Housing Style Barrel Mount - Flat Window
- Color Option 2 Red
- Physical Dimensions (LxWxH or DxH mm) 16.5 x 70.4
- Wireless No
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
M18GRY2PQ Description
Banner Engineering M18GRY2PQ is a pilot light from the EZ-LIGHT series designed with a 3-color multifunction G/R/Y color pattern LED illumination. This part features a black housing with a round protruding window and a threaded cylindrical barrel made from nickel-plated brass and a thermoplastic diffused window. It is pre-equipped with a 5-pin M12 Euro-style QD connector for connectivity. The supply voltage required ranges from 10Vdc to 30Vdc, with a nominal range of 12Vdc to 24Vdc. It is designed for flush mounting in an 18mm hole with an M18 thread. The indicator has a diameter of 18mm and can operate in ambient air temperatures ranging from -20°C to +50°C. It offers a degree of protection of IP67, consumes 40mA of current, and includes 3 x digital inputs (10-30Vdc; PNP) for color control.
Related documents M18GRY2PQ Specs
