M18GRY2PQP Banner Electronic Components
Part#:M18GRY2PQP
Manufacturer:Banner
Product Lifecycle:Active
Get a quick Quote!
Banner Engineering M18GRY2PQP, part of the EZ-LIGHT series, is a pilot light designed with a 3-color multifunction LED illumination in green, red, and yellow color patterns. This unit features a black housing with a round protruding window and a threaded cylindrical barrel made from nickel-plated brass and a thermoplastic diffused window. It is pre-wired with a 6-inch (15cm) pigtail that terminates with a 5-pin M12 Euro-style quick disconnect (QD) connector. The M18GRY2PQP operates on a supply voltage range of 10Vdc to 30Vdc, with a nominal range of 12Vdc to 24Vdc, and is designed for flush mounting in an 18mm hole using an M18 thread. It can operate in ambient air temperatures ranging from -20°C to +50°C and offers a degree of protection rated at IP67. The current consumption is 40mA, and it includes 3 digital inputs (10-30Vdc; PNP) for color control.
About the manufacturer: Banner is one of the manufacturers that offers Electronic Components that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the M18GRY2PQP Banner price in the box on the right side or send a quick quote.
Product Details
- Product Size (mm) 18
- Color Option 3 Yellow
- Environmental Rating IP67
- Pro-Editor Compatible (Discrete) No
- Power Source DC
- Max Current Color (mA) 40
- Min Op. Temperature (°C) -20
- Feature: Quick Disconnect Yes
- Power DC
- Color Option 1 Green
- Supply Voltage 10-30 V dc
- Feature: Chemical Resistant No
- Housing Style Barrel Mount - Flat Window
- Connection Pigtail QD
- Max Input Response Time (ms) 250
- Feature: Audible No
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Quick Disconnect Type M12 (Euro)
- Physical Dimensions (LxWxH or DxH mm) 16.5 x 51.5
- Number of Colors / Segments 3
- Color Option 2 Red
- Max Op. Temperature (°C) 50
- Multi-Color Device Single Color On
- Mounting Thread M18 x 1.0
- Animation Option 1 Solid On
- Input Type PNP
- Wireless No
- Indication Yes
- Color Technology Standard LED
- Number of Input Pins/Conductors 5
- Feature: Hazardous Area No
- Primary Housing Material Nickel-Plated Brass
- Wire Selectable Function Multi-Function
- IO Link No
- Primary Window Material Thermoplastic Diffused
- Modbus RTU No
