M18GRYNQ Banner Indicator Lights
Part#:M18GRYNQ
Manufacturer:Banner
Alt. Part#:74040
Product Lifecycle:Active
In-stock parts: 157
Jun 20, 2025
EZ-LIGHT: Nickel-Plated Brass Housing M18x1 Thread; 3 Color General Purpose; Green Red Yellow Light; Steady Display; NPN (Sourcing): Encapsulated IP67; M12 Integral QD
About the manufacturer: Banner is one of the manufacturers that offers Indicator Lights that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the M18GRYNQ Banner price in the box on the right side or send a quick quote.
Product Details
- Weight72.57472 g
- Country Of OriginUS
- Primary Housing Material Nickel-Plated Brass
- Product Size (mm) 18
- Max Op. Temperature (°C) 50
- IO Link No
- Power Source DC
- Color Option 1 Green
- Supply Voltage 10-30 V dc
- Primary Window Material Thermoplastic Diffused
- Wireless No
- Indication Yes
- Connection Integral QD
- Number of Input Pins/Conductors 4
- Feature: Hazardous Area No
- Cable Length (m) 2
- Quick Disconnect Type M12 (Euro)
- Environmental Rating IP67
- Multi-Color Device Single Color On
- Number of Colors / Segments 3
- Animation Option 1 Solid On
- Input Type NPN
- Feature: Chemical Resistant No
- Mounting Thread M18 x 1.0
- Color Technology Standard LED
- Max Input Response Time (ms) 1
- Feature: Quick Disconnect Yes
- Housing Style Barrel Mount - Flat Window
- Color Option 3 Yellow
- Min Op. Temperature (°C) -40
- Pro-Editor Compatible (Discrete) No
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Color Option 2 Red
- Physical Dimensions (LxWxH or DxH mm) 16.5 x 70.4
- Modbus RTU No
- Power DC
- Max Current Color (mA) 25
- Feature: Audible No
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
M18GRYNQ Description
Banner Engineering M18GRYNQ is a pilot light from the EZ-LIGHT series designed with a 3-color G/R/Y color pattern LED illumination. This part features a black housing with a round protruding window and a threaded cylindrical barrel made from nickel-plated brass and a thermoplastic diffused window. It is pre-equipped with a 4-pin M12 Euro-style QD connector for connectivity. The supply voltage required for operation ranges from 10Vdc to 30Vdc, with a nominal range of 12Vdc to 24Vdc. It is designed for flush mounting in an 18mm hole with an M18 thread. The diameter of the indicator is 18mm. This part can operate in ambient air temperatures ranging from -40°C to +50°C. It has a degree of protection of IP67, indicating it is dust tight and protected against the effects of immersion. The current consumption is 25mA. Additionally, it features 3 x digital inputs (10-30Vdc; NPN) for color control.
Related documents M18GRYNQ Specs
This item can ship within 5 days!
1-year warranty
$17.50
Stock:
157
Select Qty:
$17.50
$17.50 each
By purchasing this item, you agree to the Terms & Conditions
Quotebeam is NOT an authorized distributor of Banner
Shipping and Delivery Worldwide
calculate costs and time
Secure Payment Processing
with money back guarantee
1 year warranty
on all parts
Responsive Customer Support
we're here to help!
Need more details?
Feel free to chat with us or check our FAQ
Banner Disclaimer:
The product is unused surplus. Quotebeam is not an authorized surplus dealer or affiliate for the Manufacturer of this product. Products may feature older date codes or be from an earlier series than what is currently available from the manufacturer or authorized dealers. Because Quotebeam is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Banner Controls products will have firmware already installed, Quotebeam makes no representation as to whether a Controls product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. Quotebeam also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Banner, its distributors, or any other source. Quotebeam also makes no representations as to your right to install any such firmware on the product. Quotebeam will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.
