K90TLGRNQP Banner Electronic Components
Part#:K90TLGRNQP
Manufacturer:Banner
Product Lifecycle:Active
Get a quick Quote!
K90T Series EZ-LIGHT; 2-Color Indicator, Voltage: 12-30 V dc; Environmental Rating: IP67, Input: NPN; Colors: Green Red, Euro 5-pin 150 mm (6 in) PVC Pigtail
About the manufacturer: Banner is one of the manufacturers that offers Electronic Components that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the K90TLGRNQP Banner price in the box on the right side or send a quick quote.
Product Details
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Color Option 2 Red
- Input Type NPN
- Feature: Audible No
- Primary Housing Material Polycarbonate
- Color Option 1 Green
- Number of Input Pins/Conductors 5
- Min Op. Temperature (°C) -40
- Wireless No
- Cable Length (m) 2
- Number of Colors / Segments 2
- Power DC
- Product Size (mm) 90
- Max Current Color (mA) 475
- NEMA Type and UL Type Rating NEMA 4X, 13
- Modbus RTU No
- Housing Style Base Mount - Dome Window
- Color Technology Standard LED
- Color 2 - Wavelength/Color Temp/Coordinates 625 nm
- Max Op. Temperature (°C) 50
- Pro-Editor Compatible (Discrete) No
- Power Source DC
- Animation Option 1 Solid On
- Lumens Color 2 65.0
- Physical Dimensions (LxWxH or DxH mm) 90.0 x 87.0
- Mounting Thread M30 x 1.5
- Lumens Color 1 150
- Max Input Response Time (ms) 150
- Feature: Chemical Resistant No
- Indication Yes
- Color 1 - Wavelength/Color Temp/Coordinates 525 nm
- Wire Selectable Function Multi-Function
- Primary Window Material Polycarbonate Diffused
- Connection Pigtail QD
- Supply Voltage 12-30 V dc
- Feature: Hazardous Area No
- Quick Disconnect Type M12 (Euro)
- Environmental Rating IP67
- IO Link No
- Multi-Color Device Single Color On - Alternating
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
Related documents K90TLGRNQP Specs
