Variable Frequency Drives (VFD)

M000-11404640DU0100AN100

NIDEC M000-11404640DU0100AN100 is a Variable Speed/Frequency Drive (VSD/VFD) from the M000 series, featuring a built-in DC to AC inverter with air cooling. It has dimensions of frame size 11D, measuring H31.7" x W12.2" x D12.3" (H804mm x W310mm x D312mm). This model is designed for heavy-duty applications, with a rated current of 464A. It operates on a supply voltage of 380Vac-480Vac (400Vac / 415Vac) and is compatible with a network frequency of 50 Hz. The degree of protection provided is IP20 NEMA 1. Its rated active power ranges from 90kW to 250kW, and the rated power is between 125HP and 400HP for heavy-duty operations.

Nidec

M600-10203000E10101AN100

NIDEC M600-10203000E10101AN100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M600 series designed for variable speed control with a single Safe Torque Off (STO) and requires an external choke with air cooling. It features dimensions of frame size 10E, measuring H39.7" x W12.21" x D11.42" (H1010mm x W310mm x D290mm), and supports RS-485 Modbus RTU communication protocol. The drive operates with a rated current of 360A under normal duty and 300A under heavy-duty conditions, and it is designed for a supply voltage of 200Vac-240Vac (220Vac / 230Vac). It can function in ambient air temperatures ranging from -20°C to +40°C and has a degree of protection of IP20 NEMA 1. This model is suitable for a 3-phase input network with a supply input frequency of 45-66 Hz and an output frequency range of 0-550 Hz. It includes 2 x analog outputs, 3 x digital inputs, 3 x digital outputs plus 1 x relay contact type digital output, and multiple analog inputs with varying specifications. The rated active power is 110kW for normal duty and 90kW for heavy-duty, corresponding to 150HP and 125HP, respectively.

Nidec

CFW701E0150T5NBN1C3

DRIVE CFW701E0150T5NBN1C3

WEG

F600-03400104A10101AB103

NIDEC F600-03400104A10101AB103 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for 3-phase input with a supply voltage range of 380Vac-480Vac, specifically 400Vac / 415Vac, and operates on a 60 Hz network frequency. It features a rated current of 10.4A and rated active power of 4kW, equivalent to 5HP under normal duty conditions. The device is equipped with 1 analog input (4-20mA / 0-10Vdc; single-ended), 1 analog output (0-10Vdc), 3 digital inputs (24Vdc and 0-24Vdc; configurable), and 2 digital outputs (240Vac; relay contact type). It supports Modbus RTU communication protocol. The F600 series inverter, with a built-in brake transistor, internal line choke, and air cooling, is designed for operation in ambient air temperatures ranging from -20°C to +40°C. It has an IP20 degree of protection and dimensions of frame size 3, measuring H15" x W3.3" x D7.9" (H382mm x W83mm x D200mm).

Nidec

I55AE211A1AV01001S

Lenze i55AE211A1AV01001S is a variable speed/frequency drive (VSD/VFD) and compact inverter designed for a variety of applications including DC-injection braking, brake management for brake control, and features S-ramps for smooth acceleration and deceleration. It includes a flying restart circuit and a PID controller. This model is equipped with a safe torque off (STO) safety application and I.O. conformal coating. It has dimensions of H250mm x W60mm x D130mm. Despite having no communication interface, it offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. The rated current is 6A for heavy-duty applications at 120Vac, and it operates on a supply voltage of 120Vac. It is designed for control cabinet or surface/wall mounting. The ambient air temperature for operation varies with the switching frequency, allowing a maximum of 45°C at 2kHz or 4kHz and 40°C at 8kHz or 16kHz. It has an IP20 degree of protection and is suitable for single-phase networks with an input frequency of 45-65 Hz and an output frequency of 0-599 Hz. The device includes 2 analog outputs (0-10Vdc; 0-20mA or 4-20mA), 7 digital inputs (with options for frequency or encoder input), and 2 digital outputs (max. 100mA). Additionally, it has 2 analog inputs (-10...+10Vdc; 0-20mA or 4-20mA) that can be optionally used as voltage or current inputs. The rated active power is 1.1kW, and the rated power is 1-1/2HP for heavy-duty applications at 120Vac.

Lenze

3G3RX2-A2185

RX2 Series High-Performance Inverter

Omron

UMI-0300CU-B7

UMI-0300CU-B7 Unitronics - Unitronics VFD - B7 Series, 200-240V, 3 Phase, 30kW, 40HP, STO included

Unitronics

HVW701A010GN01200001

WEG HVW701A010GN01200001 - STANDARD PANEL HVW701A010GN01200001, HVAC Enclosed Drives (HVW)

WEG

S100-03413-0B0000

Nidec S100-03413-0B0000

Nidec

CFW700B33P5T2DBN1

WEG CFW700B33P5T2DBN1 - DRIVE CFW700B33P5T2DBN1, CFW500/700 Drives

WEG

I51AE275F10V11000S

Lenze I51AE275F10V11000S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for variable speed and frequency control with additional features including DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, a flying restart circuit, and a PID controller. It is equipped with a built-in RFI filter, basic I.O., and conformal coating. This model does not include a communication interface. It offers protection functions against overvoltage, leakage current, earth fault, and motor overtemperature. The rated current is 16.5A for heavy-duty operations at 400Vac and 14A at 480Vac, with a supply voltage of 400Vac / 480Vac. It is designed for control cabinet or surface/wall mounting and operates within an ambient air temperature range of up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at 8kHz or 16kHz. The degree of protection is IP20, suitable for 3-phase networks with an input frequency of 45-65 Hz and an output frequency of 0-599 Hz. It features 1 analog output, 5 digital inputs with flexible functionality, and 2 analog inputs, supporting both voltage and current signals. The rated active power is 11kW for light-duty and 7.5kW for heavy-duty operations, corresponding to 15HP and 10HP respectively, across a voltage range of 400-480Vac.

Lenze

CFW110105T4ON1DBZ

DRIVE CFW110105T4ON1DBZ

WEG

M600-10601500E10101AN100

NIDEC M600-10601500E10101AN100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M600 series designed with a single Safe Torque Off (STO) and requires an external choke for air cooling. It features dimensions of frame size 10E, measuring H39.7" x W12.21" x D11.42" (H1010mm x W310mm x D290mm). This model supports RS-485 Modbus RTU communication protocol and operates with a rated current of 172A under normal duty and 150A under heavy-duty conditions. It is designed for a supply voltage of 500Vac-690Vac (600Vac) and can function within an ambient air temperature range of -20°C to +40°C. The device offers an IP20 NEMA 1 degree of protection and is compatible with a 3-phase input (3P) network, supporting a supply input frequency of 45-66 Hz and an output frequency of 0-550 Hz. It includes 2 x analog outputs, 3 x digital inputs, 3 x digital outputs, and multiple analog inputs with varying specifications. The rated active power is 160kW for normal duty and 132kW for heavy-duty, corresponding to 200HP and 175HP, respectively.

Nidec

CFW501A09P6T2NB20C3

DRIVE CFW501A09P6T2NB20C3

WEG

SF420

Lenze SF420 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for precise control of motor speed and frequency. It features dimensions of H146mm x W73mm x D146mm and can operate with a supply voltage of either 400Vac or 480Vac, delivering a rated current of 3.9A at 400Vac and 3.4A at 460Vac. This unit is suitable for cabinet or DIN rail mounting and operates efficiently within an ambient air temperature range of 0 to +50 °C, with a derating of 2.5% per °C above +50°C. It supports RS-485 communication protocol and accommodates a network frequency of 48-62 Hz on input and 0-240 Hz on output. The SF420 includes 2 digital outputs (open-collector outputs; 50mA at 30Vdc) for terminals TB-14 and TB-15, and is compatible with a 3-phase network. It also features 1 analog input (0-10Vdc) at terminal TB5, 1 analog input (4-20mA) at terminal TB25, and 2 analog outputs (0-10Vdc or 2Vdc-10Vdc and 0-10Vdc or 2-10Vdc) at terminals TB-30 and TB-31, respectively, which are proportional to output frequency or load. The rated active power is 1.5kW for a supply voltage of 400-480Vac, with a corresponding rated power of 2HP for the same voltage range.

Lenze

HS30-02400013A10101AB100

NIDEC HS30-02400013A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) from the HS30 series designed for high-speed applications with a rated frequency output of 0-3000Hz in open loop. It features a built-in brake transistor and dual Safe Torque Off (STO) functionality, utilizing air cooling for temperature management. The device has dimensions of frame size 2, measuring H8.1" x W3.1" x D5.9" (H205mm x W78mm x D150mm). It supports multiple communication protocols including CANopen, DeviceNet, Ethernet/IP, Modbus RTU, Modbus TCP, PROFINET RT, and PROFIBUS DP. The rated current is 1.3A for both normal and heavy-duty operations, with a supply voltage range of 380Vac-480Vac (specifically 400Vac / 415Vac). It operates within an ambient air temperature range of -20°C to +55°C and offers a degree of protection rated at IP20 and NEMA 1. The network is designed for a 3-phase input (3P) with a supply input frequency of 45-66 Hz and an output frequency of 0-3000 Hz. The device includes 1 analog output (10Vdc; source; single-ended), 5 digital inputs (0-24Vdc) plus 1 additional digital input (0-24Vdc), and 2 digital outputs (one 100mA / 0-24Vdc; PWM; source and one 2A / 240Vac; source; relay contact type). It also features 2 analog inputs (one 0-20mA / 4-20mA / 0-10Vdc; single-ended; 11-bit conversion resolution and one 0-10Vdc; single-ended; 11-bit; can be used as a digital input). The rated active power is 0.37kW and the rated power is 1/2HP for both normal and heavy-duty applications.

Nidec

HVW701E211T4N12-I-C

WEG HVW701E211T4N12-I-C - STANDARD PANEL HVW701E211T4N12-I-C, HVAC Enclosed Drives (HVW)

WEG

I55AE137F10V11001S

Lenze I55AE137F10V11001S is a Variable Speed/Frequency Drive (VSD/VFD) from the Drives sub-range, designed for compact inverter applications including DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and a PID controller. It features a built-in RFI filter, application I.O., and conformal coating, with dimensions of H155mm x W60mm x D130mm. This model does not include a communication interface but offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It has a rated current of 1.3A for heavy-duty applications at 400-480Vac, with a supply voltage of 400Vac / 480Vac. The mounting mode is suitable for control cabinet or surface/wall mounting. The ambient air temperature for operation varies with the switching frequency, allowing a maximum of 45°C at 2kHz or 4kHz and 40°C at 8kHz or 16kHz, with a protection degree of IP20. It operates on a 3-phase network (3P / 3AC) with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). The drive includes 2 analog outputs (0-10Vdc; 0-20mA or 4-20mA), 7 digital inputs (PNP/NPN logic), 2 digital outputs (max. 100mA), and 2 analog inputs (-10...+10Vdc; 0-20mA or 4-20mA), with a rated active power of 0.37kW and rated power of 1/2HP for heavy-duty applications at 400-480Vac.

Lenze

C300-06500350A10101AB100

NIDEC C300-06500350A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) from the C300 series designed with dual Safe Torque Off (STO) and air cooling. It operates on a supply voltage of 500Vac-575Vac, with dimensions of frame size 6 H15.39" x W8.27" x D8.94" (H291mm x W210mm x D227mm), and offers a degree of protection of IP20 NEMA 1. The rated current is 43A under normal duty and 35A under heavy-duty conditions. It supports Modbus RTU communication protocol over a 3-phase input network, with a network frequency of 45-66 Hz (supply input) and an output frequency range of 0-550 Hz. The ambient air temperature for operation ranges from -20°C to +60°C. It features 1 x analog output (10Vdc; source; single-ended), 5 x digital inputs (0-24Vdc; PNP/NPN) plus 1 additional digital input (0-24Vdc), and 2 digital outputs (one 50mA / 0-24Vdc; source; PWM and one 2A / 240Vac; source; relay contact type). Additionally, it includes 2 analog inputs (one 0-20mA / 4-20mA / 0-10Vdc; single-ended; 11-bit conversion resolution and one 0-10Vdc; single-ended; 11-bit conversion resolution). The rated active power is 30kW under normal duty and 22kW under heavy-duty, equivalent to 40HP and 30HP respectively.

Nidec

EDP11S211GN12-PGS

WEG EDP11S211GN12-PGS - STANDARD PANEL EDP11S211GN12-PGS, Enclosed Drive Packages (EDP)

WEG
