Variable Frequency Drives (VFD)

HVW701A010T2N01-I-B

WEG HVW701A010T2N01-I-B - STANDARD PANEL HVW701A010T2N01-I-B, HVAC Enclosed Drives (HVW)

WEG

M1510B

Lenze M1510B is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for general purpose applications. It features dimensions of H191mm x W119mm x D92mm and supports Modbus communication protocol. This device is equipped with thermal overload protection and solid state motor overload protection to safeguard against operational hazards. It operates with a rated current of 1.6A at supply voltages of 480Vac / 590Vac and is suitable for mounting in control cabinets or on surfaces/walls. The M1510B can function within an ambient air temperature range of -10 to +50 °C and is rated with a degree of protection of NEMA 1. It is designed for a 3-phase network (3P / 3AC) with an input frequency of 48-62 Hz and an output frequency of 0-120 Hz. The device includes 1 analog output proportional to speed (frequency), 1 analog output proportional to load, 4 digital inputs for control, 2 digital outputs (NPN; sinking), and 2 analog inputs for external signals (0-10Vdc and 4-20mA). It has a rated active power of 0.75kW and a rated power of 1HP at 480Vac / 590Vac.

Lenze

I55AE155B10V11001S

Lenze I55AE155B10V11001S is a variable speed/frequency drive (VSD/VFD) or inverter within the Drives sub-range, designed for compact inverter applications including DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and a PID controller. It features a built-in RFI filter, application I.O., and conformal coating, with dimensions of H180mm x W60mm x D130mm. This model does not include a communication interface but offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It has a rated current of 3.2A for heavy-duty applications at 230-240Vac, with a supply voltage of 230Vac / 240Vac. The mounting mode is suitable for control cabinet or surface/wall mounting. The ambient air temperature for operation varies with the switching frequency, allowing a maximum of 45°C at 2kHz or 4kHz and 40°C at 8kHz or 16kHz. It has an IP20 degree of protection, is designed for a single-phase / 1P network with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). The device includes 2 x analog outputs (0-10Vdc; 0-20mA or 4-20mA), 7 x digital inputs (PNP/NPN logic), 2 x digital outputs (max. 100mA), and 2 x analog inputs (-10...+10Vdc; 0-20mA or 4-20mA). It has a rated active power of 0.55kW and a rated power of 3/4HP for heavy-duty applications at 230-240Vac.

Lenze

CFW110289T6OYZ

DRIVE CFW110289T6OYZ

WEG

I55AE345F1AV11012S

Lenze I55AE345F1AV11012S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed/frequency control, compact inverter DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and PID controller functionality. It features a built-in RFI filter, safe torque off (STO) safety standard, I.O. conformal coating, and dimensions of H450mm x W250mm x D230mm. This model supports Ethernet POWERLINK communication protocol and offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It operates with a rated current of 107A (light-duty; 400Vac), 92.4A (light-duty; 480Vac), 89A (heavy-duty; 400Vac), and 77A (heavy-duty; 480Vac), and a supply voltage of 400Vac / 480Vac. Suitable for control cabinet or surface/wall mounting, it can operate in ambient air temperatures up to 45°C (at a switching frequency of 2kHz or 4kHz) and 40°C (at a switching frequency of 8kHz or 16kHz), with a degree of protection of IP20. It is designed for a 3-phase network (3P / 3AC) with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). The drive includes 1 x analog output, multiple digital inputs with optional uses, 1 x digital output, 2 x analog inputs with optional uses, and has a rated active power of 55kW (light-duty; 400-480Vac) and 45kW (heavy-duty; 400-480Vac), equivalent to 75HP (light-duty; 400-480Vac) and 60HP (heavy-duty; 400-480Vac).

Lenze

EDP11S877GN1201000

STANDARD PANEL EDP11S877GN1201000

WEG

UMI-0110EU-B5

UMI-0110EU-B5 Unitronics - Use UMI-0110EE-B1 or UMI-0110EU-B7

Unitronics

GA80U4044AWM

GA80U4044AWM Yaskawa - Variable frequency drive (VFD), 3 phase, 480 VAC, 44 A, Flange (Type 12 Backside), General Purpose GA800 Series

Yaskawa

M000-09501040EU0101AB100

NIDEC M000-09501040EU0101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M000 series designed with a built-in brake transistor, requiring an external choke and air cooling for operation. It features a frame size of 9E with dimensions of H39.7" x W12.2" x D11.4" (H1010mm x W310mm x D290mm). This model has a rated current of 104A for heavy-duty applications and operates on a supply voltage of 500Vac-575Vac with a network frequency of 60 Hz. It offers a degree of protection of IP20 NEMA 1 and supports rated active power ranging from 90kW to 250kW (125HP to 400HP) for heavy-duty tasks.

Nidec

I55AE230F1AV11003S

Lenze I55AE230F1AV11003S is a variable speed/frequency drive (VSD/VFD) or inverter within the Drives sub-range, designed for compact inverter applications including DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and a PID controller. It features a built-in RFI filter, safe torque off (STO) safety standard, I.O. conformal coating, and supports Modbus RTU communication protocol. The drive offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It operates with a rated current of 8.8A for light-duty at 400Vac, 7.6A for light-duty at 480Vac, 7.3A for heavy-duty at 400Vac, and 6.3A for heavy-duty at 480Vac. The supply voltage is 400Vac / 480Vac, suitable for control cabinet or surface/wall mounting. The ambient air temperature for operation is up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at a switching frequency of 8kHz or 16kHz, with a degree of protection of IP20. It is designed for a 3-phase network (3P / 3AC) with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). The drive includes 1 analog output (0-10Vdc; 0-20mA or 4-20mA), 5 digital inputs (PNP/NPN logic), 1 digital output (max. 100mA), and 2 analog inputs (-10...+10Vdc; 0-20mA or 4-20mA). It has a rated active power of 4kW for light-duty and 3kW for heavy-duty at 400-480Vac, corresponding to 5HP and 4HP, respectively.

Lenze

EDP11S005GN3R11000

STANDARD PANEL EDP11S005GN3R11000

WEG

F600-07600460A10101AB103

NIDEC F600-07600460A10101AB103 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for 3-phase input with a supply voltage range of 500Vac-690Vac, specifically at 600Vac, and operates efficiently at a network frequency of 60 Hz. It features a built-in brake transistor, an internal line choke, and utilizes air cooling for temperature management. The device is capable of delivering a rated current of 46A and supports a rated active power of 37kW or 50HP under normal duty conditions. It is equipped with 1 analog input (4-20mA / 0-10Vdc; single-ended), 1 analog output (0-10Vdc), 3 digital inputs (24Vdc), and an additional 3 digital inputs (0-24Vdc; configurable), alongside 2 digital outputs (240Vac; relay contact type). This model, part of the F600 series, ensures connectivity through the Modbus RTU communication protocol and is designed with an IP20 degree of protection. Its physical dimensions are frame size 7, measuring H21.9" x W10.6" x D11" (H557mm x W270mm x D280mm), and it is specified to operate within an ambient air temperature range of -20°C to +40°C.

Nidec

GA80U2018ABM

GA80U2018ABM Yaskawa - Variable frequency drive (VFD), 3 phase, 240 VAC, 18 A, IP20, General Purpose GA800 Series

Yaskawa

ESV752N06TXF

ESV752N06TXF Lenze Variable Frequency Drive (VFD) - The SMV 10.0 hp (7.5 kW) drive features a 480 / 600 VAC 3Ø input in a fan cooled NEMA 4X (IP65) indoor/outdoor enclosure. The SMVector NEMA 4X (IP65) offers exemplary performance even in harsh environments. These decentralized drives are suitable for wall mounting and are available in two enclosure materials suitable for either indoor or outdoor use. This drive is also available with an integral disconnect switch and integrated line filter idea

Lenze

I55AE137A10V0100WS

Lenze I55AE137A10V0100WS is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed/frequency control, compact inverter DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and PID controller functionalities. It features a standard I.O. with conformal coating, dimensions of H180mm x W60mm x D130mm, and supports Modbus TCP communication protocol. The drive offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It has a rated current of 2.4A for heavy-duty applications at 120Vac, with a supply voltage of 120Vac. Suitable for control cabinet or surface/wall mounting, it operates within an ambient air temperature range of up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at 8kHz or 16kHz, with an IP20 degree of protection. The network type is single-phase / 1P, with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 analog output (0-10Vdc; 0-20mA or 4-20mA), 5 digital inputs (PNP/NPN logic), 1 digital output (max. 100mA), and 2 analog inputs (-10...+10Vdc; 0-20mA or 4-20mA). The rated active power is 0.37kW, and the rated power is 1/2HP for heavy-duty applications at 120Vac.

Lenze

HVW701C045T2N01-I-C

WEG HVW701C045T2N01-I-C - STANDARD PANEL HVW701C045T2N01-I-C, HVAC Enclosed Drives (HVW)

WEG

M600-07600540A10101AB100

NIDEC M600-07600540A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M600 series designed with a built-in brake transistor and a single Safe Torque Off (STO) feature, utilizing air cooling. It has dimensions of frame size 7, measuring H20" x W10.63" x D11.02" (H508mm x W270mm x D280mm). This model supports RS-485 Modbus RTU communication protocol and operates with a rated current of 73A under normal duty and 54A under heavy-duty conditions. It is designed for a supply voltage of 500Vac-690Vac (600Vac) and can function in ambient air temperatures ranging from -20°C to +40°C. The device offers an IP20 NEMA 1 degree of protection and is compatible with a 3-phase input (3P) network, with a supply input frequency of 45-66 Hz and an output frequency range of 0-550 Hz. It features 2 x analog outputs (-10...+10Vdc; single-ended; source; 10-bit conversion resolution), 3 x digital inputs (0-24Vdc), 3 x digital outputs (100mA / 0-24Vdc; source), 1 x digital output (2A / 240Vac; relay contact type), and multiple analog inputs with varying specifications. The rated active power is 55kW under normal duty and 45kW under heavy-duty, corresponding to a rated power of 75HP and 60HP, respectively.

Nidec

C200-06400470A10101AB100

NIDEC C200-06400470A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the C200 series, designed with air cooling. It operates on a supply voltage of 380Vac-480Vac (400Vac / 415Vac) and has dimensions of frame size 6 H15.39" x W8.27" x D8.94" (H291mm x W210mm x D227mm). This model offers a degree of protection of IP20 NEMA 1 and supports a rated current of 63A for Normal duty and 47A for Heavy-duty applications. It utilizes Modbus RTU for communication and is designed for a 3-phase input network with a supply input frequency of 45-66 Hz and an output frequency range of 0-550 Hz. The ambient air temperature for operation ranges from -20°C to +60°C. It features 1 x analog output (10Vdc; source; single-ended), 5 x digital inputs (0-24Vdc; PNP/NPN) plus 1 additional digital input (0-24Vdc), and 2 digital outputs (one 50mA / 0-24Vdc; source; PWM and one 2A / 240Vac; source; relay contact type). Additionally, it includes 2 analog inputs (one 0-20mA / 4-20mA / 0-10Vdc; single-ended; 11-bit conversion resolution and one 0-10Vdc; single-ended; 11-bit conversion resolution). The rated active power is 30kW for Normal duty and 22kW for Heavy-duty, with a rated power of 40HP for Normal duty and 30HP for Heavy-duty.

Nidec

EDP11S515GN3R10000

STANDARD PANEL EDP11S515GN3R10000

WEG

VFD015C43A-21

Variable Frequency Drive, 3 phase, 460 VAC Input, 2 HP, frame A, wall mount, IP20, NEMA 1

Delta
