Variable Frequency Drives (VFD)

M701-10402700E10101AN100

NIDEC M701-10402700E10101AN100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M701 series designed for variable speed control with a single Safe Torque Off (STO) and requires an external choke and air cooling. It has dimensions of frame size 10E, measuring H39.7" x W12.21" x D11.42" (H1010mm x W310mm x D290mm). This model supports RS-485 Modbus RTU communication protocol and operates with a rated current of 320A under normal duty and 270A under heavy-duty conditions. It is designed for a supply voltage of 380Vac-480Vac (400Vac / 415Vac) and can function within an ambient air temperature range of -20°C to +40°C. The degree of protection offered is IP20 NEMA 1 UL open, suitable for 3-phase input (3P) networks with a supply input frequency of 45-66 Hz and an output frequency range of 0-599 Hz. It features 2 analog outputs (0-20mA / 4-20mA / -10...+10Vdc; source; 10-bit conversion resolution), 6 digital inputs (0-24Vdc), 4 digital outputs (0-24Vdc; source and 2A / 240Vac; source; relay contact type), and 3 analog inputs (1 x differential and 2 x single-ended; 0-20mA / 4-20mA / -10...+10Vdc; 11-bit conversion resolution). The rated active power is 160kW for normal duty and 132kW for heavy-duty, with a rated power of 250HP under normal duty and 200HP under heavy-duty conditions.

Nidec

CFW500A02P6S2NB20

DRIVE CFW500A02P6S2NB20

WEG

SP0402-HF

NIDEC SP0402-HF is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for high frequency applications up to 3000Hz max in an open-loop configuration with a single Safe Torque Off (STO) and air cooling. It features a compact frame size of 0, measuring H12.677" x W2.441" x D8.898" (H322mm x W62mm x D226mm), and supports a supply voltage range of 380Vac-480Vac (400Vac / 415Vac) with a rated current of 1.7A for heavy-duty operations. This wall-mounted unit operates efficiently within an ambient air temperature range of 0°C to +40°C and offers a degree of protection rated at IP20 NEMA 1. Communication is facilitated through a Modbus RTU RS-485 protocol, and it accommodates a network frequency from 48-65 Hz (Supply input) with an output range of 0-3000 Hz. The SP0402-HF includes 3 x digital outputs (0-24Vdc; source), 1 x digital output (2A / 240Vac; source; relay contact type), 3 x digital inputs (0-24Vdc), and analog inputs comprising 1 x (-9.8Vdc...9.8Vdc; differential) and 2 x (0-20mA / 4-20mA / -9.8Vdc...9.8Vdc; single-ended) with a 10-bit conversion resolution. Analog outputs include 2 x (0-20mA / 4-20mA / -10Vdc...10Vdc; single-ended; source) with a 10-bit conversion resolution. It is designed for a 3-phase input network and delivers a rated active power of 0.55kW and a rated power of 3/4HP for both normal and heavy-duty applications.

Nidec

M702-09402000A10101AB100

NIDEC M702-09402000A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M702 series designed with a built-in brake transistor and dual Safe Torque Off (STO) for air cooling. It features dimensions of frame size 9A, measuring H41.3" x W12.21" x D11.42" (H1049mm x W310mm x D290mm). This model supports multiple communication protocols including Ethernet, Ethernet/IP, Modbus TCP, and PROFINET RT. It operates with a rated current of 221A under normal duty and 200A under heavy-duty conditions, and it is designed for a supply voltage of 380Vac-480Vac (specifically 400Vac / 415Vac). The ambient air temperature range for operation is -20°C to +40°C, and it comes with an IP20, NEMA 1, UL open degree of protection. The M702 is suitable for a 3-phase input network with a supply input frequency of 45-66 Hz and an output frequency range of 0-599 Hz. It includes 2 x digital inputs (0-24Vdc, with terminal 8 configurable as a motor protection thermistor) and 3 x digital outputs (2 x 100mA / 0-24Vdc source and 1 x 2A / 240Vac source, relay contact type). The rated active power is 110kW under normal duty and 90kW under heavy-duty, with a rated power of 150HP for both conditions.

Nidec

I55AE337F1AV11003S

Lenze I55AE337F1AV11003S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed and frequency control, compact inverter applications, DC-injection braking, brake management, smooth acceleration and deceleration with S-ramps, flying restart circuit, and PID controller functionality. It features a built-in RFI filter, safe torque off (STO) safety standard, I.O. conformal coating, and dimensions of H450mm x W250mm x D230mm. This model supports Modbus RTU communication protocol and offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It operates with a rated current of 91.2A (light-duty; 400Vac), 78A (light-duty; 480Vac), 76A (heavy-duty; 400Vac), and 65A (heavy-duty; 480Vac), and a supply voltage of 400Vac / 480Vac. Suitable for control cabinet or surface/wall mounting, it operates within an ambient air temperature range of up to 45°C (at a switching frequency of 2kHz or 4kHz) and up to 40°C (at a switching frequency of 8kHz or 16kHz), with an IP20 degree of protection. The network type is 3-phase (3P / 3AC), with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 x analog output, multiple digital inputs with optional uses, 1 x digital output, 2 x analog inputs with optional uses, and is rated for 45kW (light-duty; 400-480Vac) and 37kW (heavy-duty; 400-480Vac) active power, equivalent to 60HP (light-duty) and 50HP (heavy-duty).

Lenze

ESV552N06TMC

ESV552N06TMC Lenze Variable Frequency Drive (VFD) - The SMV 7.5 hp (5.5 kW) drive features a 480 / 600 VAC 3Ø input with input disconnect in a convection cooled NEMA 4X (IP65) indoor enclosure. The SMVector NEMA 4X (IP65) offers exemplary performance even in harsh environments. These decentralized drives are suitable for wall mounting and are available in two enclosure materials suitable for either indoor or outdoor use. This drive is also available with an integral disconnect switch and integra

Lenze

GA80UT208AWM

GA80UT208AWM Yaskawa - Variable frequency drive (VFD), 12 Pulse, 480 VAC, 208 A, Flange (Type 12 Backside), General Purpose GA800 Series

Yaskawa

3G3RX2-A4150

RX2 Series High-Performance Inverter

Omron

I55AE337F10V11000S

Lenze I55AE337F10V11000S is a variable speed/frequency drive (VSD/VFD) or inverter within the Drives sub-range, designed for compact inverter applications with features including DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and a PID controller. It has a built-in RFI filter, standard I.O., and conformal coating. The dimensions are H450mm x W250mm x D230mm. This model does not include a communication interface but offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It supports rated currents of 91.2A (light-duty; 400Vac), 78A (light-duty; 480Vac), 76A (heavy-duty; 400Vac), and 65A (heavy-duty; 480Vac), with a supply voltage of 400Vac / 480Vac. It is suitable for control cabinet or surface/wall mounting, operates within an ambient air temperature of up to 45°C (at a switching frequency of 2kHz or 4kHz) and up to 40°C (at a switching frequency of 8kHz or 16kHz), and has an IP20 degree of protection. The network type is 3-phase (3P / 3AC) with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 analog output, 5 digital inputs with flexible functionality, 1 digital output, and 2 analog inputs. The rated active power is 45kW (light-duty; 400-480Vac) and 37kW (heavy-duty; 400-480Vac), with rated power of 60HP (light-duty; 400-480Vac) and 50HP (heavy-duty; 400-480Vac).

Lenze

GA80UT720AAM

GA80UT720AAM Yaskawa - Variable frequency drive (VFD), 12 Pulse, 480 VAC, 720 A, IP00, General Purpose GA800 Series

Yaskawa

M000-09201760AU0100AB100

NIDEC M000-09201760AU0100AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter, part of the M000 series, designed with a built-in brake transistor, internal line choke, and air cooling. It features a frame size of 9A with dimensions of H41.3" x W12.2" x D11.4" (H1049mm x W310mm x D290mm). The rated current for heavy-duty applications is 176A, and it operates on a supply voltage of 200Vac-240Vac (220Vac / 230Vac) with a network frequency supply input of 50 Hz. This model offers a degree of protection of IP20 NEMA 1 and supports rated active power ranging from 90kW to 110kW (125HP to 150HP) for heavy-duty operations.

Nidec

UMI-0015BU-B1

UMI-0015BU-B1 Unitronics - Use UMI-0015BE-B1

Unitronics

EDP11S003GN3R01000

STANDARD PANEL EDP11S003GN3R01000

WEG

M000-10202830EU0100AB100

NIDEC M000-10202830EU0100AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter, part of the M000 series, designed with a built-in brake transistor and requires an external choke and air cooling for operation. It features a frame size of 10E, with dimensions of H39.7" x W12.2" x D11.4" (H1010mm x W310mm x D290mm), and is rated for a heavy-duty current of 283A. This model operates on a supply voltage of 200Vac-240Vac (220Vac / 230Vac), with a network frequency supply input of 50 Hz. It offers a degree of protection of IP20 NEMA 1. The rated active power ranges from 90kW to 250kW for heavy-duty applications, equivalent to 125HP to 400HP.

Nidec

C300-06500230A10101AB100

NIDEC C300-06500230A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the C300 series designed with dual Safe Torque Off (STO) and air cooling. It operates on a supply voltage of 500Vac-575Vac, with dimensions of frame size 6 H15.39" x W8.27" x D8.94" (H291mm x W210mm x D227mm), and offers a degree of protection of IP20 NEMA 1. The rated current is 27A under normal duty and 23A under heavy-duty conditions. It supports Modbus RTU communication protocol over a 3-phase input network, with a network frequency of 45-66 Hz (supply input) and an output frequency range of 0-550 Hz. The ambient air temperature for operation ranges from -20°C to +60°C. It features 1 x analog output (10Vdc; source; single-ended), 5 x digital inputs (0-24Vdc; PNP/NPN) plus 1 additional digital input (0-24Vdc), and 2 digital outputs (one 50mA / 0-24Vdc; source; PWM and one 2A / 240Vac; source; relay contact type). Additionally, it includes 2 analog inputs (one 0-20mA / 4-20mA / 0-10Vdc; single-ended; 11-bit conversion resolution and one 0-10Vdc; single-ended; 11-bit conversion resolution). The rated active power is 18.5kW under normal duty and 15kW under heavy-duty, with a rated power of 25HP (normal duty) and 20HP (heavy-duty).

Nidec

CFW110045T2O55DSZ

DRIVE CFW110045T2O55DSZ

WEG

M400-09402000E10101AB100

NIDEC M400-09402000E10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M400 series designed with a built-in brake transistor, dual Safe Torque Off (STO), and requires an external choke with air cooling for operation. It has dimensions of frame size 9E, measuring H39.8" x W12.2" x D11.4" (H1010mm x W310mm x D290mm). This model supports multiple communication protocols including CANopen, DeviceNet, Ethernet/IP, Modbus RTU, Modbus TCP, PROFINET RT, and PROFIBUS DP. It operates with a rated current of 221A under normal duty and 180A under heavy-duty conditions. The supply voltage required is 380Vac-480Vac (400Vac / 415Vac), and it can function within an ambient air temperature range of -20°C to +55°C. The degree of protection is IP20 NEMA 1, and it is designed for a 3-phase input network with a supply input frequency of 45-66 Hz and an output frequency range of 0-550 Hz. The device includes 2 analog outputs, 8 digital inputs, and 3 digital outputs, alongside 2 analog inputs, supporting various signal types. The rated active power is 110kW for normal duty and 90kW for heavy-duty, with a rated power of 150HP for both conditions.

Nidec

I55AE315F1AV1100MS

Lenze I55AE315F1AV1100MS is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed/frequency control, compact inverter DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and PID controller functionality. It features a built-in RFI filter, safe torque off (STO) safety standard, I.O. conformal coating, and dimensions of H347mm x W204.5mm x D222mm. This model supports Ethernet/IP communication protocol and offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It operates with a rated current of 38.4A (light-duty; 400Vac), 32.4A (light-duty; 480Vac), 32A (heavy-duty; 400Vac), and 27A (heavy-duty; 480Vac), and a supply voltage of 400Vac / 480Vac. Suitable for control cabinet or surface/wall mounting, it operates within an ambient air temperature range of up to 45°C (at a switching frequency of 2kHz or 4kHz) and up to 40°C (at a switching frequency of 8kHz or 16kHz), with a degree of protection of IP20. The network type is 3-phase (3P / 3AC), with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 x analog output, multiple digital inputs with optional uses, 2 x analog inputs with optional uses, and 1 x digital output. The rated active power is 18.5kW (light-duty; 400-480Vac) and 15kW (heavy-duty; 400-480Vac), with a rated power of 25HP (light-duty; 400-480Vac) and 20HP (heavy-duty; 400-480Vac).

Lenze

ATV71HD22N4S337

Schneider Electric ATV71HD22N4S337 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 71 series, designed for variable speed and frequency control with a U/F ratio of 2 points or 5 points. It features sensorless flux vector control, ENA System, and vector control with or without speed feedback. This model can deliver 220% of the nominal motor torque for 2 seconds and 170% of the nominal motor torque for 60 seconds. It includes a built-in DC choke, EMC filter, and a heatsink, with a coated version for enhanced chemical resistance. The supply voltage ranges from 323-528Vac, accommodating 380Vac, 400Vac, 480Vac, and 500Vac nominal values. Its dimensions are H420mm x W240mm x D236mm, and it offers an IP20 UL type 1 degree of protection. The rated current is 48A at 380Vac (4kHz), 40A at 460Vac (4kHz), with a maximum current of 79.2A for 2 seconds and 72A for 60 seconds. For installation, it supports wall mounting and communicates via Modbus and CANopen protocols. It operates on a 3-phase network with an output frequency range of 0.1-599 Hz. The device includes 1 analog output (0-10Vdc / 0-20mA), 5 digital inputs (24Vdc; sink/source), an additional programmable digital input, and a PWR safety input, along with 3 digital outputs. It also features 2 analog inputs for comprehensive control. The current consumption is 50A at 380Vac and 42A at 480Vac, with a rated active power of 22kW and a rated power of 30HP.

Schneider Electric

VFD015C4EA-21

Variable Frequency Drive, 3 phase, 460 VAC build-in EMI Input, 2 HP, frame A, wall mount, IP20, NEMA 1

Delta
