Variable Frequency Drives (VFD)

CFW110142T4ON1DBZ

DRIVE CFW110142T4ON1DBZ

WEG

HVW701E180T2N12-I-B

WEG HVW701E180T2N12-I-B - STANDARD PANEL HVW701E180T2N12-I-B, HVAC Enclosed Drives (HVW)

WEG

HS70-03400045A10101AB100

NIDEC HS70-03400045A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the HS70 series designed for variable speed/frequency control with rated frequency outputs of 0-3000Hz in open loop and 0-1250Hz in closed loop applications. It features a built-in brake transistor and a single Safe Torque Off (STO) function, suitable for high-speed applications, and utilizes air cooling for temperature management. The device has dimensions of frame size 3, measuring H15" x W3.3" x D7.9" (H382mm x W83mm x D200mm), and supports Ethernet communication protocol. It operates with a rated current of 6.2A under normal duty and 4.5A under heavy-duty conditions, requiring a supply voltage of 380Vac-480Vac (400Vac / 415Vac). The ambient air temperature for operation ranges from -20°C to +40°C, and it has an IP20 NEMA 1 UL open degree of protection. This VSD/VFD is designed for a 3-phase input network with a supply input frequency of 45-66 Hz and an output frequency up to 3000 Hz. It includes 2 x analog outputs, 3 x digital inputs, 3 x digital outputs, and 3 x analog inputs with varying conversion resolutions. The rated active power is 2.2kW under normal duty and 1.5kW under heavy-duty, corresponding to 3HP and 2HP, respectively.

Nidec

M000-FOLLOWER011100A0100

Nidec M000-FOLLOWER011100A0100

Nidec

HVW701B017T4N01-X-A

WEG HVW701B017T4N01-X-A - STANDARD PANEL HVW701B017T4N01-X-A, HVAC Enclosed Drives (HVW)

WEG

M701-09601310E10101AB100

NIDEC M701-09601310E10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M701 series designed with a built-in brake transistor, single Safe Torque Off (STO), and requires an external choke with air cooling for operation. It features dimensions of frame size 9E, measuring H39.7" x W12.21" x D11.42" (H1010mm x W310mm x D290mm). This model supports RS-485 Modbus RTU communication protocol and operates with a rated current of 155A under normal duty and 131A under heavy-duty conditions. It is designed for a supply voltage of 500Vac-690Vac (600Vac) and can function in ambient air temperatures ranging from -20°C to +40°C. The device offers an IP20 NEMA 1 UL open degree of protection and is compatible with a 3-phase input (3P) network, with a supply input frequency of 45-66 Hz and an output frequency range of 0-599 Hz. It includes 2 analog outputs (0-20mA / 4-20mA / -10...+10Vdc; source; 10-bit conversion resolution), 6 digital inputs (0-24Vdc), 4 digital outputs (0-24Vdc; source and 2A / 240Vac; source; relay contact type), and 3 analog inputs (0-20mA / 4-20mA / -10...+10Vdc; with different conversion resolutions and input types). The rated active power is 132kW under normal duty and 110kW under heavy-duty, with corresponding rated powers of 175HP and 150HP, respectively.

Nidec

CFW080120THN4A1Z

WEG CFW080120THN4A1Z - INVERTER USCFW080120T5060EON4A1Z, CFW08 / CFW500 Washdown Drives

WEG

CFW500C10P0T5DB20

DRIVE CFW500C10P0T5DB20

WEG

I55AE137A1AV01002S

Lenze I55AE137A1AV01002S is a variable speed/frequency drive (VSD/VFD) from the Drives sub-range, designed for compact inverter applications including DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and a PID controller. It adheres to the safe torque off (STO) safety standard and features an I.O. conformal coating. The dimensions are H180mm x W60mm x D130mm, and it uses the CANopen communication protocol. Protection functions include overvoltage category, leakage current, earth fault resistance, and overtemperature of the motor. The rated current is 2.4A for heavy-duty applications at 120Vac, with a supply voltage of 120Vac. It is suitable for control cabinet or surface/wall mounting, with an operational ambient air temperature range based on switching frequency: max. 45°C at 2kHz or 4kHz and max. 40°C at 8kHz or 16kHz. The degree of protection is IP20, designed for a single-phase network with a network frequency of 45-65 Hz input and 0-599 Hz output. It includes 1 analog output (0-10Vdc; 0-20mA or 4-20mA), 5 digital inputs (PNP/NPN logic), 1 digital output (max. 100mA), and 2 analog inputs (-10...+10Vdc; 0-20mA or 4-20mA). The rated active power is 0.37kW, and the rated power is 1/2HP for heavy-duty applications at 120Vac.

Lenze

I55AE318F1AV1100WS

Lenze I55AE318F1AV1100WS is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed and frequency control, compact inverter functionality, DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and PID controller operations. It features a built-in RFI filter, safe torque off (STO) safety standard, I.O. conformal coating, and dimensions of H347mm x W204.5mm x D222mm. This model supports Modbus TCP communication protocol and offers protection functions against overvoltage category, leakage current, earth fault resistance, and overtemperature of the motor. It has a rated current of 48A (light-duty; 400Vac), 40.8A (light-duty; 480Vac), 40A (heavy-duty; 400Vac), and 34A (heavy-duty; 480Vac), with a supply voltage of 400Vac / 480Vac. Suitable for control cabinet or surface/wall mounting, it operates within an ambient air temperature range, with a maximum of 45°C at a switching frequency of 2kHz or 4kHz, and 40°C at 8kHz or 16kHz. The degree of protection is IP20, designed for a 3-phase network (3P / 3AC), with network frequency input of 45-65 Hz and output of 0-599 Hz. It includes 1 x analog output (0-10Vdc; 0-20mA or 4-20mA), multiple digital inputs with flexible functionality, 1 x digital output (max. 100mA), and 2 x analog inputs (-10...+10Vdc; 0-20mA or 4-20mA) with optional usage. The rated active power is 22kW (light-duty; 400-480Vac) and 18.5kW (heavy-duty; 400-480Vac), with rated power of 30HP (light-duty; 400-480Vac) and 25HP (heavy-duty; 400-480Vac).

Lenze

I5DAE222B10V10000S

Lenze I5DAE222B10V10000S is a Variable Speed/Frequency Drive (VSD/VFD) or Inverter within the Power units sub-range, designed for controlling motor speed with precision. It features a built-in RFI filter and operates without a communication interface. This model is equipped with protection functions against overvoltage, leakage current, earth fault resistance, and motor overtemperature. It supports a rated current of 9.6A for heavy-duty applications at a supply voltage of 230Vac or 240Vac. The I5DAE222B10V10000S is suitable for mounting in a control cabinet or on a surface/wall, offering an IP20 degree of protection. It is designed for single-phase networks and delivers a rated active power of 2.2kW or 3HP for heavy-duty operations at 230-240Vac.

Lenze

ATV312HU75N4412

Schneider Electric ATV312HU75N4412 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 312 solar series designed for solar energy-driven pumping applications. It features sensorless flux vector control and an energy-saving ratio of 170-200% of the nominal motor torque. This model comes with a built-in EMC filter and a built-in heatsink. It operates on a supply voltage of 361-525Vac (380Vac / 400Vac / 480Vac / 500Vac nom.) and has dimensions of H232mm x W180mm x D172mm. The ATV312HU75N4412 offers an IP20 degree of protection, a rated current of 17A (380Vac; 4kHz) with a maximum current of 25.5A for 60 seconds, and supports wall mounting. Communication is facilitated through Modbus and CANopen protocols, and it is designed for a 3-phase (3P) network with an output frequency range of 0-500 Hz. The unit provides 1 x analog output (0-10Vdc), 1 x analog output (0-20mA), 6 x digital inputs (24Vdc; sink/source) (LI1-LI6), 1 x digital output (C/O SPDT relay contact) (R1), 1 x digital output (NO relay contact) (R2), and 3 x analog inputs for versatile connectivity. Current consumption is rated at 27.7A (380Vac; Isc = 22kA) and 21A (500Vac), with a rated active power of 7.5kW (10HP) and power dissipation/losses of 269 W.

Schneider Electric

CFW700C45P0T4DBN1

WEG CFW700C45P0T4DBN1 - DRIVE CFW700C45P0T4DBN1, CFW500/700 Drives

WEG

HVW701A007T2N01-X-X

WEG HVW701A007T2N01-X-X - STANDARD PANEL HVW701A007T2N01-X-X, HVAC Enclosed Drives (HVW)

WEG

SL230S

Lenze SL230S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed with a built-in line filter. It features dimensions of H146mm x W95mm x D140mm and operates on a supply voltage of 200Vac-240Vac (208Vac / 220Vac / 230Vac) with a rated current of 11A at 208Vac and 9.6A at 230Vac. This part is suitable for control cabinet or surface/wall mounting and can operate within an ambient air temperature range of 0-40°C. It does not include a communication interface but supports a network frequency of 48-62 Hz (input) and 0-240 Hz (output). The SL230S offers 1 x digital output (normally open relay; contacts rated 3A at 250Vac), 1 x digital output (current-sourcing; rated 50mA at 12Vdc), and 4 x digital inputs (active-high) (terminal 1; 13A; 13B; 13E). It is designed for a single-phase / 1P network and provides a rated active power of 2.2kW (208Vac-240Vac) and a rated power of 3HP (208Vac-240Vac).

Lenze

M600-03200080A10101AB100

NIDEC M600-03200080A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M600 series designed with a built-in brake transistor and a single Safe Torque Off (STO) feature, utilizing air cooling. It has dimensions of frame size 3, measuring H14.37" x W3.27" x D7.87" (H365mm x W83mm x D200mm). This model supports RS-485 Modbus RTU communication protocol and operates with a rated current of 11A under normal duty and 8A under heavy-duty conditions. It requires a supply voltage of 200Vac-240Vac (220Vac / 230Vac) and is designed to function within an ambient air temperature range of -20°C to +40°C. The device offers an IP20 NEMA 1 degree of protection and is compatible with a 3-phase input network, supporting a supply input frequency of 45-66 Hz and an output frequency range of 0-550 Hz. It features 2 x analog outputs, 3 x digital inputs, 3 x digital outputs, and multiple analog inputs with varying specifications, including differential and single-ended configurations with 11-bit conversion resolution. The rated active power is 2.2kW under normal duty and 1.5kW under heavy-duty, corresponding to a rated power of 3HP and 2HP, respectively.

Nidec

C300-09202190E10101AB100

NIDEC C300-09202190E10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the C300 series, designed with dual Safe Torque Off (STO) and an external line reactor for air cooling. It operates on a supply voltage of 200Vac-240Vac (220Vac / 230Vac) and has dimensions of frame size 9E H42.09" x W12.21" x D11.42" (H1069mm x W310mm x D290mm). This model offers a degree of protection of IP20 NEMA 1 and supports a rated current of 266A for Normal duty and 219A for Heavy-duty operations. It utilizes the Modbus RTU communication protocol over a 3-phase input network with a supply input frequency of 45-66 Hz and an output frequency range of 0-550 Hz. The ambient air temperature for operation ranges from -20°C to +60°C. It features 1 analog output (10Vdc; source; single-ended), 5 digital inputs (0-24Vdc; PNP/NPN) plus 1 additional digital input (0-24Vdc), and 2 digital outputs (one 50mA / 0-24Vdc; source; PWM and one 2A / 240Vac; source; relay contact type). Additionally, it includes 2 analog inputs (one 0-20mA / 4-20mA / 0-10Vdc; single-ended; 11-bit conversion resolution and one 0-10Vdc; single-ended; 11-bit conversion resolution). The rated active power is 75kW for Normal duty and 55kW for Heavy-duty, with a rated power of 100HP for Normal duty and 75HP for Heavy-duty.

Nidec

HVW701A013T4N01-J-B

WEG HVW701A013T4N01-J-B - STANDARD PANEL HVW701A013T4N01-J-B, HVAC Enclosed Drives (HVW)

WEG

ESV153N06TXD

ESV153N06TXD Lenze Variable Frequency Drive (VFD) - The SMV 20.0 hp (15.0 kW) drive features a 480 / 600 VAC 3Ø input in a fan cooled NEMA 4X (IP65) indoor enclosure. The SMVector NEMA 4X (IP65) offers exemplary performance even in harsh environments. These decentralized drives are suitable for wall mounting and are available in two enclosure materials suitable for either indoor or outdoor use. This drive is also available with an integral disconnect switch and integrated line filter ideal for E

Lenze

CFW110053T6ON1NBYZ

DRIVE CFW110053T6ON1NBYZ

WEG
