Variable Frequency Drives (VFD)

CFW700B24P0T4DB20

DRIVE CFW700B24P0T4DB20

WEG

HVW701A007T2N01-I-X

WEG HVW701A007T2N01-I-X - STANDARD PANEL HVW701A007T2N01-I-X, HVAC Enclosed Drives (HVW)

WEG

S100-01213-0B0000

Nidec S100-01213-0B0000

Nidec

CFW700C38P0T4DBN1

WEG CFW700C38P0T4DBN1 - DRIVE CFW700C38P0T4DBN1, CFW500/700 Drives

WEG

EDP11S031GN1201000

STANDARD PANEL EDP11S031GN1201000

WEG

GA80U2012ABM

GA80U2012ABM Yaskawa - Variable frequency drive (VFD), 3 phase, 240 VAC, 12 A, IP20, General Purpose GA800 Series

Yaskawa

I55AE175D1AV0100KS

Lenze I55AE175D1AV0100KS is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed control, compact inverter DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and PID controller functionalities. It adheres to the safe torque off (STO) safety standard and features an I.O. conformal coating. The dimensions are H180mm x W60mm x D130mm. It supports EtherCAT communication protocol and includes protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. The rated current is 4.2A for heavy-duty applications at 230-240Vac, with a supply voltage of 230Vac / 240Vac. It is designed for control cabinet or surface/wall mounting, operates within an ambient air temperature of up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at a switching frequency of 8kHz or 16kHz, with an IP20 degree of protection. It can be used in single-phase or 3-phase networks, with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). The drive features 1 x analog output (0-10Vdc; 0-20mA or 4-20mA), 5 x digital inputs (PNP/NPN logic), 1 x digital output (max. 100mA), and 2 x analog inputs (-10...+10Vdc; 0-20mA or 4-20mA). It has a rated active power of 0.75kW and a rated power of 1HP for heavy-duty applications at 230-240Vac.

Lenze

EDP11S477GN3R10000

STANDARD PANEL EDP11S477GN3R10000

WEG

CFW110370T4OYHXZ

WEG CFW110370T4OYHXZ - INVERTER EUCFW110370T4OYHXZ, CFW11 Drives

WEG

ATV312HU30M3412

Schneider Electric ATV312HU30M3412 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 312 solar series, designed for solar energy-driven pumping applications. It features sensorless flux vector control and an energy-saving ratio of 170-200% of the nominal motor torque. This model comes with a built-in heatsink, operates on a supply voltage of 190-252Vac (200Vac / 220Vac / 230Vac / 240Vac nom.), and has dimensions of H184mm x W142mm x D152mm. It offers an IP20 degree of protection, a rated current of 13.7A at 200Vac with a 4kHz frequency, and a maximum current of 20.6A for 60 seconds. The ATV312HU30M3412 supports wall mounting and uses Modbus and CANopen communication protocols. It is designed for a 3-phase network with an output frequency range of 0-500 Hz. The device includes 1 analog output (0-10Vdc), 1 analog output (0-20mA), 6 digital inputs (24Vdc; sink/source), 1 digital output (C/O SPDT relay contact), 1 digital output (NO relay contact), 1 analog input (0-10Vdc), 1 analog input (0-20mA / 4-20mA), and 1 analog input (-10...+10Vdc). It has a current consumption of 19.1A at 200Vac and 16.6A at 240Vac, with a rated active power of 3kW and power dissipation/losses of 146 W.

Schneider Electric

ACS355-03U-08A8-4

Drive, AC, 5HP, 480V, 8.8A, CT, OP 480Vin 3PH W/DB Transistor No Keypad 7.9"Hx2.8"Wx6.3"D ACS355

ABB Control

HVW701E180DN01200001

WEG HVW701E180DN01200001 - STANDARD PANEL HVW701E180DN01200001, HVAC Enclosed Drives (HVW)

WEG

I55AE345F1AV11001S

Lenze I55AE345F1AV11001S is a variable speed/frequency drive (VSD/VFD) or inverter within the Drives sub-range, designed for compact inverter applications including DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and a PID controller. It features a built-in RFI filter, safe torque off (STO) safety application, I.O. conformal coating, and has dimensions of H450mm x W250mm x D230mm. This model does not include a communication interface but offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It supports a rated current of 107A (light-duty; 400Vac), 92.4A (light-duty; 480Vac), 89A (heavy-duty; 400Vac), and 77A (heavy-duty; 480Vac), with a supply voltage of 400Vac / 480Vac. Suitable for control cabinet or surface/wall mounting, it operates within an ambient air temperature of up to 45°C (at a switching frequency of 2kHz or 4kHz) and up to 40°C (at a switching frequency of 8kHz or 16kHz), with a degree of protection of IP20. The network type is 3-phase (3P / 3AC), with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 2 x analog outputs, 7 x digital inputs with flexible functionality, 2 x digital outputs, and 2 x analog inputs, supporting a rated active power of 55kW (light-duty; 400-480Vac) and 45kW (heavy-duty; 400-480Vac), equivalent to 75HP (light-duty) and 60HP (heavy-duty).

Lenze

I55AE215D10V0100LS

Lenze I55AE215D10V0100LS is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed and frequency control, compact inverter functionality, DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and PID controller operations. It features a standard I.O. with conformal coating, dimensions of H250mm x W60mm x D130mm, and utilizes the PROFINET communication protocol. The drive offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It has a rated current of 7A for heavy-duty applications at 230-240Vac, with a supply voltage of 230Vac / 240Vac. Suitable for control cabinet or surface/wall mounting, it operates within an ambient air temperature range of up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at a switching frequency of 8kHz or 16kHz, with an IP20 degree of protection. The drive supports both single-phase and three-phase networks, with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 x analog output, 5 x digital inputs with flexible functionality, 1 x digital output, and 2 x analog inputs, supporting both voltage and current input/output configurations. The rated active power is 1.5kW, and the rated power is 2HP for heavy-duty applications at 230-240Vac.

Lenze

M400-09402240A10101AB100

NIDEC M400-09402240A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M400 series designed with a built-in brake transistor and dual Safe Torque Off (STO) for air cooling. It has dimensions of frame size 9A, measuring H43.6" x W12.2" x D11.4" (H1107mm x W310mm x D290mm). This model supports multiple communication protocols including CANopen, DeviceNet, Ethernet/IP, Modbus RTU, Modbus TCP, PROFINET RT, and PROFIBUS DP. It operates with a rated current of 255A under normal duty and 211A under heavy-duty conditions. The supply voltage required is 380Vac-480Vac (400Vac / 415Vac), and it is designed to function within an ambient air temperature range of -20°C to +55°C. The degree of protection is IP20 NEMA 1, and it is suitable for a 3-phase input network with a frequency of 45-66 Hz (supply input) and an output frequency range of 0-550 Hz. The device includes 2 analog outputs (0-20mA / 4-20mA / 0-10Vdc/ 0-24Vdc; single-ended; source; can also function as digital outputs), 5 digital inputs plus 1 additional digital input and 2 more digital inputs (all 0-24Vdc), and 2 digital outputs (200mA / 0-24Vdc; PWM; source) plus 1 digital output (2A / 240Vac; source; relay contact type). It also features 1 analog input (0-20mA / 4-20mA / -10...+10Vdc; single-ended; 11-bit conversion resolution) and another analog input (0-20mA / 4-20mA / 0-10Vdc; single-ended; 11-bit; can also be used as a digital input). The rated active power is 132kW under normal duty and 110kW under heavy-duty, with rated power of 200HP (Normal duty) and 150HP (Heavy-duty).

Nidec

H300-03400045A10101AB103

NIDEC H300-03400045A10101AB103 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the H300 series designed with a built-in brake transistor, internal line choke, and air cooling. It features dimensions of frame size 3, measuring H15" x W3.3" x D7.9" (H382mm x W83mm x D200mm), and operates on a 3-phase input network with a supply voltage of 380Vac-480Vac (400Vac / 415Vac). This model supports Modbus RTU communication protocol and is capable of operating within an ambient air temperature range of -20°C to +40°C. It offers a degree of protection rated at IP20 NEMA 1 UL type 1. The drive has a rated current of 4.5A under normal duty, with a network frequency of 60 Hz. It includes 2 analog outputs, 3 digital inputs (24Vdc), 3 configurable digital inputs (24Vdc), 1 digital input (0-24Vdc), and 2 digital outputs (relay contact type), alongside 1 analog input (4-20mA) and 1 analog input (0-10Vdc). The rated active power is 1.5kW, and the rated power is 2HP under normal duty conditions.

Nidec

I55AE155B1AV11003S

Lenze I55AE155B1AV11003S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed and frequency control, compact inverter applications, DC-injection braking, brake management, smooth acceleration and deceleration with S-ramps, and includes a flying restart circuit and PID controller. It features a built-in RFI filter, safe torque off (STO) safety standard, I.O. conformal coating, and dimensions of H180mm x W60mm x D130mm. This model supports Modbus RTU communication protocol and offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It has a rated current of 3.2A for heavy-duty applications at 230-240Vac, with a supply voltage of 230Vac / 240Vac. Suitable for control cabinet or surface/wall mounting, it operates within an ambient air temperature range of up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at 8kHz or 16kHz, with an IP20 degree of protection. The network is single-phase / 1P with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 analog output, 5 digital inputs with flexible functionality, 1 digital output, and 2 analog inputs, supporting a rated active power of 0.55kW and a rated power of 3/4HP for heavy-duty applications at 230-240Vac.

Lenze

ESV112N02TXB

ESV112N02TXB Lenze Variable Frequency Drive (VFD) - The SMV 1.5 hp (1.1 kW) drive features a 208 / 240 VAC 3Ø input in a convection cooled NEMA 1 (IP31) indoor enclosure. The SMVector NEMA 1 (IP31) is a compact and cost effective drive for a wide range of AC motor applications demanding dynamic speed and torque control. The SMVector NEMA 1 (IP31) is available in power ranges from 0.33...60.0 hp (0.25 kW...45.0 kW) and global voltages from 120 VAC...600 VAC.

Lenze

ESV222N04TXE

ESV222N04TXE Lenze Variable Frequency Drive (VFD) - The SMV 3.0 hp (2.2 kW) drive features a 400 / 480 VAC 3Ø input in a convection cooled NEMA 4X (IP65) indoor/outdoor enclosure. The SMVector NEMA 4X (IP65) offers exemplary performance even in harsh environments. These decentralized drives are suitable for wall mounting and are available in two enclosure materials suitable for either indoor or outdoor use. This drive is also available with an integral disconnect switch and integrated line filt

Lenze

GA80U4477AWM

GA80U4477AWM Yaskawa - Variable frequency drive (VFD), 3 phase, 480 VAC, 477 A, Flange (Type 12 Backside), General Purpose GA800 Series

Yaskawa
