Variable Frequency Drives (VFD)

EDP11S024DN1210000

STANDARD PANEL EDP11S024DN1210000

WEG

M000-10402700TU0100AB100

NIDEC M000-10402700TU0100AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter, part of the M000 series, designed with a built-in brake transistor, AC to DC twin rectifier, and air cooling. It features a frame size of 10T with dimensions of H39.7" x W12.2" x D11.4" (H1010mm x W310mm x D290mm). This model has a rated current of 270A for heavy-duty applications and operates on a supply voltage of 380Vac-480Vac (400Vac / 415Vac), with a network frequency of 50 Hz. It offers a degree of protection of IP20 NEMA 1. The rated active power ranges from 90kW to 250kW, and the rated power is between 125HP and 400HP for heavy-duty operations.

Nidec

ESV183N06TXF

ESV183N06TXF Lenze Variable Frequency Drive (VFD) - The SMV 25.0 hp (18.5 kW) drive features a 480 / 600 VAC 3Ø input in a fan cooled NEMA 4X (IP65) indoor/outdoor enclosure. The SMVector NEMA 4X (IP65) offers exemplary performance even in harsh environments. These decentralized drives are suitable for wall mounting and are available in two enclosure materials suitable for either indoor or outdoor use. This drive is also available with an integral disconnect switch and integrated line filter ide

Lenze

CFW110477T4SZ-PGM

DRIVE CFW110477T4SZ-PGM

WEG

H300-06500170A10101AB103

NIDEC H300-06500170A10101AB103 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the H300 series designed with a built-in brake transistor, internal line choke, and air cooling. It features dimensions of frame size 6, measuring H15.4" x W8.3" x D8.9" (H391mm x W210mm x D227mm). This model supports Modbus RTU communication protocol and operates with a rated current of 17A under normal duty conditions. It is designed for a supply voltage range of 500Vac-575Vac and can function within an ambient air temperature range of -20°C to +40°C. The device offers an IP20, NEMA 1, UL type 1 degree of protection and is suitable for a 3-phase input network with a supply input frequency of 60 Hz. It includes 2 x analog outputs, 3 x digital inputs (24Vdc), 3 x digital inputs (24Vdc / configurable), 1 x digital input (0-24Vdc), and 2 x digital outputs (relay contact type), along with 1 x analog input (4-20mA) and 1 x analog input (0-10Vdc). The rated active power is 11kW under normal duty, equivalent to 15HP.

Nidec

I55AE211F1AV1100WS

Lenze I55AE211F1AV1100WS is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed and frequency control, compact inverter DC-injection braking, brake management, S-ramps for smooth acceleration and deceleration, flying restart circuit, and PID controller functionality. It features a built-in RFI filter, safe torque off (STO) safety standard, I.O. conformal coating, and dimensions of H250mm x W60mm x D130mm. This model supports Modbus TCP communication protocol and offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It operates with a rated current of 3.2A at 400Vac and 3A at 480Vac, with a supply voltage of 400Vac / 480Vac. Suitable for control cabinet or surface/wall mounting, it operates efficiently within an ambient air temperature range, with a maximum of 45°C at a switching frequency of 2kHz or 4kHz, and 40°C at 8kHz or 16kHz. The device has an IP20 degree of protection, is designed for a 3-phase network (3P / 3AC), with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 x analog output (0-10Vdc; 0-20mA or 4-20mA), multiple digital inputs with PNP/NPN logic, 1 x digital output (max. 100mA), and 2 x analog inputs (-10...+10Vdc; 0-20mA or 4-20mA). The rated active power is 1.1kW, and the rated power is 1-1/2HP for heavy-duty applications at 400-480Vac.

Lenze

I51AE175F10V11001S

Lenze I51AE175F10V11001S is a Variable Speed/Frequency Drive (VSD/VFD) also known as a compact inverter, designed for variable speed control and equipped with DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, a flying restart circuit, and a PID controller. It features a built-in RFI filter, basic I/O, and conformal coating. The dimensions are H180mm x W60mm x D130mm. It supports CANopen and Modbus RTU communication protocols. Protection functions include overvoltage category, leakage current, earth fault resistance, and overtemperature of motor. The rated current is 2.4A for heavy-duty applications at 400Vac and 2.1A at 480Vac, with a supply voltage of 400Vac / 480Vac. It is designed for control cabinet or surface/wall mounting. The ambient air temperature for operation is max. 45°C at a switching frequency of 2kHz or 4kHz, and max. 40°C at 8kHz or 16kHz, with a degree of protection of IP20. It operates on a 3-phase network (3P / 3AC) with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 x analog output (0-10Vdc; 0-20mA or 4-20mA), 5 x digital inputs (PNP/NPN logic), 1 x digital output (max. 100mA), and 2 x analog inputs (0-10Vdc; 0-20mA or 4-20mA). The rated active power is 0.75kW and rated power is 1HP for heavy-duty applications at 400-480Vac.

Lenze

F600-05200300A10101AB653

NIDEC F600-05200300A10101AB653 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for 3-phase input with a supply voltage range of 200Vac-240Vac, specifically 220Vac or 230Vac, and a network frequency of 60 Hz. It features a built-in brake transistor, an internal line choke, and air cooling for its design. The device offers a degree of protection of IP65 and has dimensions of frame size 5, measuring H15.4" x W5.6" x D7.6" (H391mm x W143mm x D200mm). It is equipped with 1 analog input (4-20mA / 0-10Vdc; single-ended), 1 analog output (0-10Vdc), 3 digital inputs (24Vdc and 0-24Vdc; configurable), and 2 digital outputs (240Vac; relay contact type). The rated current for normal duty is 30A, with a rated active power of 7.5kW and a rated power of 10HP for normal duty. This model supports Modbus RTU communication protocol and operates within an ambient air temperature range of -20°C to +40°C.

Nidec

ATV71HU15S6X

Schneider Electric ATV71HU15S6X is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 71 series. It features sensorless flux vector control, ENA system vector control with or without speed feedback, and can deliver 220% of the nominal motor torque for 2 seconds and 170% of the nominal motor torque for 60 seconds. This model comes with a built-in heatsink, operates on a supply voltage of 425-660Vac (with nominal voltages of 440Vac, 480Vac, 500Vac, and 600Vac), and offers a degree of protection rated at IP20, IP21, and UL type 1. Its dimensions are H295mm x W210mm x D213mm. The rated current is 3.2A at 500Vac (4kHz), 2.7A at 575Vac (4kHz), with a maximum current of 5.3A for 2 seconds and 4.8A for 60 seconds. It supports wall mounting and uses Modbus and CANopen communication protocols. Designed for a 3-phase network with an output frequency range of 0.1-599 Hz, it includes 1 analog output (0-10Vdc / 0-20mA), 5 digital inputs (24Vdc; sink/source) plus 1 digital input programmable as discrete or PTC input and 1 PWR safety input, along with 1 digital output (C/O SPDT relay contact) and 2 digital outputs (NO relay contacts). It also features 1 analog input (-10...+10Vdc) and 1 analog input (0-10Vdc / 0-20mA). The current consumption is 5.6A at 500Vac and 4.9A at 600Vac, with a rated active power of 1.5kW and rated power of 2HP.

Schneider Electric

I55AE175F10V11003S

Lenze I55AE175F10V11003S is a variable speed/frequency drive (VSD/VFD) and compact inverter designed for a wide range of automation applications. It features DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, a flying restart circuit, and a PID controller. The design includes a built-in RFI filter, standard I.O., and conformal coating, with dimensions of H180mm x W60mm x D130mm. It supports Modbus RTU communication protocol and offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. The rated current is 2.4A for heavy-duty applications at 400Vac and 2.1A at 480Vac, with a supply voltage of 400Vac / 480Vac. It is suitable for control cabinet or surface/wall mounting, operates within an ambient air temperature range of up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at 8kHz or 16kHz, with a degree of protection of IP20. The network type is 3-phase (3P / 3AC), with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 analog output, 5 digital inputs with flexible functionality, 1 digital output, and 2 analog inputs, all supporting various configurations. The rated active power is 0.75kW, and the rated power is 1HP for heavy-duty applications at 400-480Vac.

Lenze

I55AE275F1AV1100LS

Lenze I55AE275F1AV1100LS is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed/frequency control, compact inverter DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and PID controller functionality. It features a built-in RFI filter, safe torque off (STO) safety standard, I.O. conformal coating, and supports PROFINET communication protocol. The device offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It operates with a rated current of 23A (light-duty; 400Vac), 18.3A (light-duty; 480Vac), 16.5A (heavy-duty; 400Vac), and 14A (heavy-duty; 480Vac), and a supply voltage of 400Vac / 480Vac. Suitable for control cabinet or surface/wall mounting, it operates within an ambient air temperature of up to 45°C (at a switching frequency of 2kHz or 4kHz) and up to 40°C (at a switching frequency of 8kHz or 16kHz), with a degree of protection of IP20. The network type is 3-phase (3P / 3AC), with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 x analog output, 5 x digital inputs with optional uses for two of them, 1 x digital output, and 2 x analog inputs with optional voltage or current input functionality. The rated active power is 11kW (light-duty; 400-480Vac) and 7.5kW (heavy-duty; 400-480Vac), with a rated power of 15HP (light-duty; 400-480Vac) and 10HP (heavy-duty; 400-480Vac).

Lenze

M12100E

Lenze M12100E is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed with a water-tight and dust-tight corrosion-resistant stainless steel housing. It utilizes the Modbus communication protocol and is equipped with thermal overload protection and solid state motor overload protection. The device supports a rated current of 32A at 200Vac and 28A at 230Vac, with a supply voltage range of 200Vac-240Vac, accommodating 208Vac, 220Vac, and 230Vac. It is suitable for control cabinet or surface/wall mounting and operates within an ambient air temperature range of -10 to +40 °C. The M12100E offers a degree of protection rated at NEMA 4X and is designed for a 3-phase network, with an input frequency of 48-62 Hz and an output frequency of 0-120 Hz. It features 1 analog output proportional to speed (frequency), 1 analog output proportional to load, 4 digital inputs, 1 digital input for start, 1 digital input for stop, and 2 digital outputs (NPN; sinking). Additionally, it includes 1 analog input (0-10Vdc) and 1 analog input (4-20mA). The rated active power is 7.5kW, and the rated power is 10HP, both at 200-240Vac.

Lenze

SP0405-HF

NIDEC SP0405-HF is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for high frequency applications up to 3000Hz max. in an open-loop configuration with a single Safe Torque Off (STO) and air cooling. It features a frame size 0 with dimensions of H12.677" x W2.441" x D8.898" (H322mm x W62mm x D226mm), and operates on a supply voltage of 380Vac-480Vac (400Vac / 415Vac) with a rated current of 4.2A for heavy-duty applications. This wall-mounted unit is designed to operate within an ambient air temperature range of 0°C to +40°C and offers a degree of protection of IP20 NEMA 1. It supports Modbus RTU RS-485 communication protocol and operates on a network frequency of 48-65 Hz (supply input) with an output frequency range of 0-3000 Hz. The SP0405-HF includes 3 x digital outputs (0-24Vdc; source), 1 x digital output (2A / 240Vac; source; relay contact type), 3 x digital inputs (0-24Vdc), and 3 additional digital inputs (0-24Vdc), along with 1 x analog input (-9.8Vdc...9.8Vdc; differential) and 2 x analog inputs (0-20mA / 4-20mA / -9.8Vdc...9.8Vdc; single-ended) with a 10-bit conversion resolution. It also features 2 x analog outputs (0-20mA / 4-20mA / -10Vdc...10Vdc; single-ended; source) with a 10-bit conversion resolution. The rated active power is 1.5kW for both normal and heavy-duty operations, with a rated power of 2HP for both duty types.

Nidec

M1510C

Lenze M1510C is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for water-tight and dust-tight applications. It utilizes Modbus for communication and offers protection functions including thermal overload protection and solid state motor overload protection. This unit has a rated current of 1.6A at 460Vac / 575Vac, with a supply voltage of 480Vac / 590Vac. It is suitable for control cabinet or surface/wall mounting and operates within an ambient air temperature range of -10 to +40 °C. The M1510C features a NEMA 4 degree of protection, is compatible with a 3-phase (3P / 3AC) network, and supports a network frequency of 48-62 Hz (input) and 0-120 Hz (output). It provides 1 x analog output proportional to speed (frequency), 1 x analog output proportional to load, 4 x digital inputs, 1 x digital input for START, 1 x digital input for STOP, and 2 x digital outputs (NPN; sinking). Additionally, it includes 1 x analog input (0-10Vdc) and 1 x analog input (4-20mA). The rated active power is 0.75kW, and the rated power is 1HP at 480Vac / 590Vac.

Lenze

I55AE137D1AV0100WS

Lenze I55AE137D1AV0100WS is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed and frequency control, compact inverter DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and PID controller functionalities. It adheres to the safe torque off (STO) safety standard and features an I.O. conformal coating. The dimensions are H155mm x W60mm x D130mm. It supports Modbus TCP communication protocol and includes protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. The rated current is 2.4A for heavy-duty applications at 230-240Vac, with a supply voltage of 230Vac / 240Vac. It is suitable for control cabinet or surface/wall mounting, operates within an ambient air temperature of 45°C at a switching frequency of 2kHz or 4kHz and 40°C at a switching frequency of 8kHz or 16kHz, and has an IP20 degree of protection. The network can be single-phase or 3-phase, with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It features 1 x analog output (0-10Vdc; 0-20mA or 4-20mA), 5 x digital inputs (PNP/NPN logic), 1 x digital output (max. 100mA), and 2 x analog inputs (-10...+10Vdc; 0-20mA or 4-20mA). The rated active power is 0.37kW, and the rated power is 1/2HP for heavy-duty applications at 230-240Vac.

Lenze

ATV71HU75N4S337

Schneider Electric ATV71HU75N4S337 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 71 series designed for variable speed and frequency control. It features sensorless flux vector control, ENA System Vector control with or without speed feedback, and can deliver 220% of the nominal motor torque for 2 seconds and 170% for 60 seconds. This model comes with a built-in DC choke, EMC filter, and a heatsink, all in a coated version for enhanced chemical resistance. It operates on a supply voltage of 323-528Vac (380Vac / 400Vac / 480Vac / 500Vac nominal) and has dimensions of H295mm x W175mm x D187mm. The ATV71HU75N4S337 offers an IP20 UL type 1 degree of protection and supports a rated current of 17.6A at 380Vac (4kHz), 14A at 460Vac (4kHz), with a maximum current of 29A for 2 seconds and 26.4A for 60 seconds. It is designed for wall mounting and uses Modbus and CANopen communication protocols. This 3-phase network device outputs frequencies ranging from 0.1-599 Hz and includes 1 analog output (0-10Vdc / 0-20mA), 5 digital inputs (24Vdc; sink/source), plus additional inputs and outputs for comprehensive control. The rated active power is 7.5kW, with a rated power of 10HP.

Schneider Electric

M000-11502540TU0100AB100

NIDEC M000-11502540TU0100AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter, part of the M000 series, designed with a built-in brake transistor, AC to DC twin rectifier, and air cooling. It features a frame size of 11T with dimensions of H46.9" x W12.2" x D12.3" (H1190mm x W310mm x D312mm). This model has a rated current of 254A for heavy-duty applications, operates on a supply voltage of 500Vac-575Vac, and offers a degree of protection of IP20 NEMA 1. It is designed to work with a network frequency of 50 Hz and supports a rated active power range of 90kW-250kW (125HP-400HP) for heavy-duty operations.

Nidec

M600-06200440A10101AB100

NIDEC M600-06200440A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M600 series designed with a built-in brake transistor and a single Safe Torque Off (STO) feature, utilizing air cooling. It has dimensions of frame size 6, measuring H14.37" x W8.27" x D8.94" (H365mm x W210mm x D227mm). This model supports RS-485 Modbus RTU communication protocol and operates with a rated current of 58A under normal duty and 44A under heavy-duty conditions. It requires a supply voltage of 200Vac-240Vac (220Vac / 230Vac) and is designed to function within an ambient air temperature range of -20°C to +40°C. The device offers an IP20 NEMA 1 degree of protection and is compatible with a 3-phase input network, supporting a supply input frequency of 45-66 Hz and an output frequency range of 0-550 Hz. It features 2 x analog outputs, 3 x digital inputs, 3 x digital outputs, and multiple analog inputs with varying specifications, including differential and single-ended configurations with 11-bit conversion resolution. The rated active power is 15kW under normal duty and 11kW under heavy-duty, corresponding to 20HP and 15HP, respectively.

Nidec

I55AE390F1AV11000S

Lenze I55AE390F1AV11000S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed/frequency control, compact inverter DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and PID controller functionality. It features a built-in RFI filter, safe torque off (STO) safety standard, I.O. conformal coating, and dimensions of H685mm x W258mm x D304mm. This model does not include a communication interface but offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It supports a rated current of 216A (light-duty; 400Vac), 187A (light-duty; 480Vac), 180A (heavy-duty; 400Vac), and 156A (heavy-duty; 480Vac), with a supply voltage of 400Vac / 480Vac. Suitable for control cabinet or surface/wall mounting, it operates within an ambient air temperature of up to 45°C (at a switching frequency of 2kHz or 4kHz) and up to 40°C (at a switching frequency of 8kHz or 16kHz), with a degree of protection of IP20. The network type is 3-phase (3P / 3AC), with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 x analog output, 5 x digital inputs with optional uses, 1 x digital output, and 2 x analog inputs with optional uses. The rated active power is 110kW (light-duty; 400-480Vac) and 90kW (heavy-duty; 400-480Vac), with a rated power of 150HP (light-duty; 400-480Vac) and 125HP (heavy-duty; 400-480Vac).

Lenze

SF4150

Lenze SF4150 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for precise control of motor speed and frequency. It features dimensions of H248mm x W170mm x D203mm and supports a supply voltage of either 400Vac or 480Vac, with rated currents of 24A at 400Vac and 21A at 460Vac. This unit can be mounted in a cabinet or on a DIN rail and operates within an ambient air temperature range of 0 to +50 °C, with a derating of 2.5% per °C above +50°C. It utilizes an RS-485 communication protocol and operates with a network frequency of 48-62 Hz on input and 0-240 Hz on output. The SF4150 includes 2 digital outputs (open-collector outputs; 50mA at 30Vdc) and offers both analog inputs (1 x 0-10Vdc and 1 x 4-20mA) and analog outputs (1 x 0-10Vdc or 2Vdc-10Vdc and 1 x 0-10Vdc or 2-10Vdc), suitable for various control applications. It is designed for a 3-phase network (3P / 3AC) and delivers a rated active power of 11kW (400-480Vac) and a rated power of 15HP (400-480Vac).

Lenze
