Variable Frequency Drives (VFD)

CFW110010T2O55DSZ

DRIVE CFW110010T2O55DSZ

WEG

ATV71HU22M3Z

Schneider Electric ATV71HU22M3Z is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 71 series designed for controlling motor speed by varying the supply frequency. It features sensorless flux vector control, ENA system vector control with or without speed feedback, and can deliver 220% of the nominal motor torque for 2 seconds and 170% for 60 seconds. This model comes with a built-in EMC filter, a non-detachable display, and a built-in heatsink. It operates on a supply voltage of 170-264Vac, accommodating 200Vac, 220Vac, 230Vac, and 240Vac nominal values. The unit measures H260mm x W155mm x D187mm, offers IP20, IP21, and UL type 1 degrees of protection, and supports wall mounting. It is rated for a current of 11A at 230Vac for 3-phase and 8A for single-phase operations at 4kHz, with maximum currents of 13.2A (single-phase) and 18.1A (3-phase) for 2 seconds, and 12A (single-phase) and 16.5A (3-phase) for 60 seconds. Communication is facilitated via Modbus and CANopen protocols, and it is compatible with both single-phase and 3-phase networks, outputting frequencies from 0.1 to 599 Hz. The drive includes 1 analog output, 5+1 programmable digital inputs, 3 digital outputs, and 2 analog inputs. It consumes up to 18.2A in single-phase and 15A in 3-phase operations at 200Vac, with rated active power of 2.2kW for 3-phase and 1.5kW for single-phase, equivalent to 3HP and 2HP respectively.

Schneider Electric

ESV183N04TXF

ESV183N04TXF Lenze Variable Frequency Drive (VFD) - The SMV 25.0 hp (18.5 kW) drive features a 400 / 480 VAC 3Ø input in a fan cooled NEMA 4X (IP65) indoor/outdoor enclosure. The SMVector NEMA 4X (IP65) offers exemplary performance even in harsh environments. These decentralized drives are suitable for wall mounting and are available in two enclosure materials suitable for either indoor or outdoor use. This drive is also available with an integral disconnect switch and integrated line filter id

Lenze

UMI-0450CU-B5

UMI-0450CU-B5 Unitronics - Use UMI-0450CU-B7

Unitronics

I55AE175F1AV1100MS

Lenze I55AE175F1AV1100MS is a Variable Speed/Frequency Drive (VSD/VFD) from the Drives sub-range, designed for compact inverter applications including DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and a PID controller. It features a built-in RFI filter, safe torque off (STO) safety standard, I.O. conformal coating, and dimensions of H180mm x W60mm x D130mm. This model supports Ethernet/IP communication protocol and offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It operates with a rated current of 2.4A at 400Vac and 2.1A at 480Vac, with a supply voltage of 400Vac / 480Vac. Suitable for control cabinet or surface/wall mounting, it operates efficiently within an ambient air temperature range, with a maximum of 45°C at a switching frequency of 2kHz or 4kHz, and 40°C at 8kHz or 16kHz. The device has an IP20 degree of protection, is designed for a 3-phase network (3P / 3AC), with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 analog output, multiple digital inputs with versatile functionality, 2 analog inputs, and 1 digital output. The rated active power is 0.75kW, and the rated power is 1HP for heavy-duty applications at 400-480Vac.

Lenze

CFW110010T4ON1Z-PGS

DRIVE CFW110010T4ON1Z-PGS

WEG

ATV71HD55N4383

Schneider Electric ATV71HD55N4383 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 71 series designed for synchronous motor control. It features a U/F ratio with options for 2 points or 5 points, sensorless flux vector control, ENA System, and vector control with or without speed feedback. This model can deliver 220% of the nominal motor torque for 2 seconds and 170% of the nominal motor torque for 60 seconds. It includes a built-in DC choke, EMC filter, and heatsink. The supply voltage ranges from 323-528Vac, accommodating 380Vac, 400Vac, 480Vac, and 500Vac nominal values. Dimensions are H630mm x W320mm x D290mm, with a degree of protection rated at IP20, IP21, and UL type 1. The rated current is 116A at 380Vac and 2.5kHz, 96A at 460Vac and 2.5kHz, with a maximum current of 191A for 2 seconds and 174A for 60 seconds. It supports wall mounting and uses Modbus and CANopen communication protocols. Designed for a 3-phase network with an output frequency range of 0.1-500 Hz, it includes 1 analog output (0-10Vdc / 0-20mA), 5 digital inputs (24Vdc; sink/source), an additional programmable digital input, and a PWR safety input. There are also 1 digital output (C/O SPDT relay contact) and 2 digital outputs (NO relay contacts), alongside 2 analog inputs for comprehensive connectivity. The current consumption is 120A at 380Vac and 101A at 480Vac, with a rated active power of 55kW and a rated power of 75HP.

Schneider Electric

EDP11S142GN1210000

STANDARD PANEL EDP11S142GN1210000

WEG

I55AE275F1AV1100WS

Lenze I55AE275F1AV1100WS is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed/frequency control, compact inverter DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and PID controller functionality. It features a built-in RFI filter, safe torque off (STO) safety standard, I.O. conformal coating, and supports Modbus TCP communication protocol. The device offers protection functions against overvoltage category, leakage current, earth fault resistance, and overtemperature of the motor. It operates with a rated current of 23A (light-duty; 400Vac), 18.3A (light-duty; 480Vac), 16.5A (heavy-duty; 400Vac), and 14A (heavy-duty; 480Vac), and a supply voltage of 400Vac / 480Vac. Suitable for control cabinet or surface/wall mounting, it operates within an ambient air temperature of up to 45°C (at a switching frequency of 2kHz or 4kHz) and up to 40°C (at a switching frequency of 8kHz or 16kHz), with a degree of protection of IP20. The network type is 3-phase (3P / 3AC), with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 x analog output, 5 x digital inputs with optional uses for two of them, 2 x analog inputs with optional voltage or current input, and 1 x digital output. The rated active power is 11kW (light-duty; 400-480Vac) and 7.5kW (heavy-duty; 400-480Vac), with a rated power of 15HP (light-duty; 400-480Vac) and 10HP (heavy-duty; 400-480Vac).

Lenze

I55AE155D1AV01004S

Lenze I55AE155D1AV01004S is a variable speed/frequency drive (VSD/VFD) or inverter within the Drives sub-range, designed for compact inverter applications with features including DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and a PID controller. It adheres to the safe torque off (STO) safety standard and includes an I.O. conformal coating. The dimensions are H180mm x W60mm x D130mm. It supports the PROFIBUS communication protocol and offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. The rated current is 3.2A for heavy-duty applications at 230-240Vac, with a supply voltage of 230Vac / 240Vac. It is suitable for control cabinet or surface/wall mounting, operates within an ambient air temperature range of up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at a switching frequency of 8kHz or 16kHz, with a degree of protection of IP20. It can be used in both single-phase and three-phase networks, with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). The drive includes 1 analog output, 5 digital inputs with flexible functionality, 1 digital output, and 2 analog inputs, supporting both voltage and current input/output configurations. It has a rated active power of 0.55kW and a rated power of 3/4HP for heavy-duty applications at 230-240Vac.

Lenze

ATV61HC13Y

Schneider Electric ATV61HC13Y is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 61 series designed for three-phase networks with a supply voltage range of 425-759Vac, including nominal voltages of 480Vac, 500Vac, 600Vac, and 690Vac. It features variable speed/frequency drive capabilities with U/F ratio adjustments (2 points / 5 points / energy saving), sensorless flux vector control, and vector control without speed feedback, capable of delivering 120% of the nominal motor torque. The design incorporates a built-in EMC filter (class C3), a built-in heatsink, and a coated version for enhanced chemical resistance. The ATV61HC13Y offers an IP20 UL type 1 degree of protection, with dimensions of H1190mm x W340mm x D377mm. It supports a rated current of 165A at 500Vac and 2.5kHz, 144A at 575Vac and 2.5kHz, 150A at 690Vac and 2.5kHz, and can handle a maximum current of 198A for 60 seconds. Wall mounting is the prescribed mounting mode. Communication is facilitated through Modbus and CANopen protocols. It features 1 analog output (0-10Vdc / 0-20mA), 5 digital inputs (24Vdc; sink/source), an additional programmable digital input, and a PWR safety input, alongside 2 digital outputs. The device also includes 2 analog inputs for comprehensive control and feedback. The network frequency output ranges from 0.1-500 Hz. The rated active power is 132kW at 690Vac and 110kW at 500Vac, with a rated power of 150HP.

Schneider Electric

I55AE125D10V0100LS

Lenze I55AE125D10V0100LS is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed and frequency control, compact inverter functionality, DC-injection braking, brake management, S-ramps for smooth acceleration and deceleration, flying restart circuit, and PID controller operations. It features a standard I.O. with conformal coating, dimensions of H155mm x W60mm x D130mm, and supports PROFINET communication protocol. The drive offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It has a rated current of 1.7A for heavy-duty applications at 230-240Vac, with a supply voltage of 230Vac / 240Vac. Suitable for control cabinet or surface/wall mounting, it operates within an ambient air temperature range of up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at 8kHz or 16kHz, with an IP20 degree of protection. The network compatibility includes single-phase or 3-phase connections, with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It features 1 analog output, 5 digital inputs with flexible functionality, 1 digital output, and 2 analog inputs, supporting both voltage and current input/output configurations. The rated active power is 0.25kW, and the rated power is 1/3HP for heavy-duty applications at 230-240Vac.

Lenze

I55AE211A1AV0100MS

Lenze I55AE211A1AV0100MS is a Variable Speed/Frequency Drive (VSD/VFD) from the Drives sub-range, designed for compact inverter applications with features including DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and a PID controller. It adheres to the safe torque off (STO) safety standard and includes an I.O. conformal coating. The dimensions are H250mm x W60mm x D130mm. It supports Ethernet/IP communication protocol and offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. The rated current is 6A for heavy-duty applications at 120Vac, with a supply voltage of 120Vac. It is suitable for control cabinet or surface/wall mounting, operates within an ambient air temperature range of up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at a switching frequency of 8kHz or 16kHz, with an IP20 degree of protection. It is designed for a single-phase network with an input frequency of 45-65 Hz and an output frequency of 0-599 Hz. The drive includes 1 analog output, 5 digital inputs with flexible functionality, 1 digital output, and 2 analog inputs, supporting a variety of signal types. It has a rated active power of 1.1kW and a rated power of 1-1/2HP for heavy-duty applications at 120Vac.

Lenze

I55AE390F10V11012S

Lenze I55AE390F10V11012S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed and frequency control, compact inverter DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and PID controller functionality. It features a built-in RFI filter, standard I.O. conformal coating, and dimensions of H685mm x W258mm x D304mm. This model supports Ethernet POWERLINK communication protocol and offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It operates with a rated current of 216A (light-duty; 400Vac), 187A (light-duty; 480Vac), 180A (heavy-duty; 400Vac), and 156A (heavy-duty; 480Vac), and a supply voltage of 400Vac / 480Vac. Suitable for control cabinet or surface/wall mounting, it can operate in ambient air temperatures up to 45°C (at a switching frequency of 2kHz or 4kHz) and 40°C (at a switching frequency of 8kHz or 16kHz), with a protection degree of IP20. The network type is 3-phase (3P / 3AC), with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 x analog output, 5 x digital inputs with flexible functionality, 1 x digital output, and 2 x analog inputs, supporting both voltage and current input/output configurations. The rated active power is 110kW (light-duty; 400-480Vac) and 90kW (heavy-duty; 400-480Vac), with a rated power of 150HP (light-duty; 400-480Vac) and 125HP (heavy-duty; 400-480Vac).

Lenze

3G3MX2-A2015-ECHN

Omron 3G3MX2-A2015-ECHN - Drive,spare from OEE

Omron

HS70-05400300A10101AB100

NIDEC HS70-05400300A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the HS70 series designed for high-speed applications with a built-in brake transistor and a single Safe Torque Off (STO) feature. It operates with a rated frequency output of 0-3000Hz in open loop and 0-1250Hz in closed loop, supported by air cooling. The dimensions are frame size 5, measuring H15.4" x W5.6" x D7.6" (H391mm x W143mm x D200mm). It utilizes Ethernet for communication and is rated for a current of 31A under normal duty and 30A under heavy-duty conditions. The supply voltage required is 380Vac-480Vac (specifically 400Vac / 415Vac), and it can operate in ambient air temperatures ranging from -20°C to +40°C. The degree of protection is IP20 NEMA 1 UL open. This device is designed for a 3-phase input network with a supply input frequency of 45-66 Hz and an output frequency up to 3000 Hz. It features 2 x analog outputs, 3 x digital inputs, 3 x digital outputs, and 3 x analog inputs with varying resolutions and types for comprehensive control and feedback. The rated active power is 15kW, and the rated power is 20HP for both normal and heavy-duty operations.

Nidec

I55AE175D10V01004S

Lenze I55AE175D10V01004S is a variable speed/frequency drive (VSD/VFD) and inverter within the Drives sub-range, designed for compact inverter DC-injection braking, brake management for brake control, and includes S-ramps for smooth acceleration and deceleration. It features a flying restart circuit and a PID controller. The design adheres to standard I.O. with conformal coating, measuring dimensions of H180mm x W60mm x D130mm. It supports PROFIBUS communication protocol and offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. The rated current is 4.2A for heavy-duty applications at 230-240Vac, with a supply voltage of 230Vac / 240Vac. It is suitable for control cabinet or surface/wall mounting, operates within an ambient air temperature of 45°C at a switching frequency of 2kHz or 4kHz, and 40°C at a switching frequency of 8kHz or 16kHz, with a degree of protection of IP20. It can be used in single-phase or 3-phase networks, with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). The device includes 1 analog output, 5 digital inputs with options for frequency or encoder input, 1 digital output, and 2 analog inputs that can be optionally used as voltage or current inputs. It has a rated active power of 0.75kW and a rated power of 1HP for heavy-duty applications at 230-240Vac.

Lenze

HS71-03200066A10101AB100

NIDEC HS71-03200066A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the HS71 series designed for variable speed/frequency control with rated frequency outputs of 0-3000Hz in open loop and 0-1250Hz in closed loop applications. It features a built-in brake transistor and a single Safe Torque Off (STO) function, suitable for high-speed applications, and utilizes air cooling for temperature management. The device has dimensions of frame size 3, measuring H15" x W3.3" x D7.9" (H382mm x W83mm x D200mm). It supports RS-485 communication protocol and operates with a rated current of 8A under normal duty and 6.6A under heavy-duty conditions. The supply voltage required is AC 200Vac-240Vac (220Vac / 230Vac), and it can operate in ambient air temperatures ranging from -20°C to +40°C. This model has an IP20 NEMA 1 UL open degree of protection, accepts a 3-phase input (3P) with a network frequency of 45-66 Hz on the supply input and can output 0-3000 Hz. It offers 2 x analog outputs (0-20mA / 4-20mA / -10...+10Vdc; source; 10-bit conversion resolution), 3 x digital inputs and outputs (0-24Vdc; source), 1 x digital output (2A / 240Vac; source; relay contact type), and analog inputs including 1 x differential (0-20mA / 4-20mA / -10...+10Vdc; 11-bit conversion resolution) and 2 x single-ended (0-20mA / 4-20mA / -10...+10Vdc; 11-bit conversion resolution). The rated active power is 1.5kW under normal duty and 1.1kW under heavy-duty, with a rated power of 2HP (normal duty) and 1.5HP / 1-1/2HP (heavy-duty).

Nidec

C300-07600290A10101AB100

NIDEC C300-07600290A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the C300 series designed with dual Safe Torque Off (STO) and air cooling. It operates on a supply voltage of 500Vac-690Vac (600Vac) and has dimensions of frame size 7 H21.93" x W10.63" x D11.02" (H557mm x W270mm x D280mm), with a degree of protection rated at IP20 NEMA 1. The rated current is 36A for Normal duty and 29A for Heavy-duty operations. It supports Modbus RTU communication protocol over a 3-phase input network with a supply input frequency of 45-66 Hz and an output frequency range of 0-550 Hz. The ambient air temperature for operation ranges from -20°C to +60°C. It features 1 x analog output (10Vdc; source; single-ended), 5 x digital inputs (0-24Vdc; PNP/NPN) plus 1 x digital input (0-24Vdc), and 1 x digital output (50mA / 0-24Vdc; source; PWM) plus 1 x digital output (2A / 240Vac; source; relay contact type). Additionally, it includes 1 x analog input (0-20mA / 4-20mA / 0-10Vdc; single-ended; 11-bit conversion resolution) and 1 x analog input (0-10Vdc; single-ended; 11-bit conversion resolution). The rated active power is 30kW for Normal duty and 22kW for Heavy-duty, with rated power of 40HP for Normal duty and 30HP for Heavy-duty.

Nidec

ATV71H075N4383

Schneider Electric ATV71H075N4383 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 71 series designed for synchronous motor control with a built-in DC choke, EMC filter, and heatsink. It operates on a supply voltage of 323-528Vac, accommodating 380Vac, 400Vac, 480Vac, and 500Vac nominal values. This model features a compact design with dimensions of H230mm x W130mm x D175mm and offers a degree of protection rated at IP20, IP21, and UL type 1. It supports a rated current of 2.3A at 380Vac (4kHz), 2.1A at 460Vac (4kHz), with a maximum current of 3.8A for 2 seconds and 3.5A for 60 seconds. The ATV71H075N4383 facilitates wall mounting and communicates via Modbus and CANopen protocols. It is designed for a 3-phase network with an output frequency range of 0.1-599 Hz. The unit includes 1 analog output (0-10Vdc / 0-20mA), 5 digital inputs (24Vdc; sink/source) plus 1 additional digital input programmable as discrete or PTC input and another for PWR safety, along with 1 digital output (C/O SPDT relay contact) and 2 digital outputs (NO relay contacts). It also features 1 analog input (-10...+10Vdc) and 1 analog input (0-10Vdc / 0-20mA). The current consumption is rated at 3.7A for 380Vac and 3A for 480Vac, with a rated active power of 750W / 0.75kW and a rated power of 1HP.

Schneider Electric
