Variable Frequency Drives (VFD)

M600-07600290A10101AB100

NIDEC M600-07600290A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M600 series designed with a built-in brake transistor and a single Safe Torque Off (STO) feature, utilizing air cooling. It has dimensions of frame size 7, measuring H20" x W10.63" x D11.02" (H508mm x W270mm x D280mm). This model supports RS-485 Modbus RTU communication protocol and operates with a rated current of 36A under normal duty and 29A under heavy-duty conditions. It is designed for a supply voltage of 500Vac-690Vac (600Vac) and can function within an ambient air temperature range of -20°C to +40°C. The device offers an IP20 NEMA 1 degree of protection and is compatible with a 3-phase input (3P) network, supporting a supply input frequency of 45-66 Hz and an output frequency of 0-550 Hz. It features 2 x analog outputs (-10...+10Vdc; single-ended; source; 10-bit conversion resolution), 3 x digital inputs (0-24Vdc), 3 x digital outputs (100mA / 0-24Vdc; source), 1 x digital output (2A / 240Vac; relay contact type), and multiple analog inputs with 11-bit conversion resolution. The rated active power is 30kW under normal duty and 22kW under heavy-duty, equivalent to 40HP and 30HP respectively.

Nidec

C300-06400470A10101AB100

NIDEC C300-06400470A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the C300 series designed with dual Safe Torque Off (STO) and air cooling. It operates on a supply voltage of 380Vac-480Vac, including 400Vac and 415Vac, within a frame size of 6 measuring H15.39" x W8.27" x D8.94" (H291mm x W210mm x D227mm). This model offers an IP20 NEMA 1 degree of protection and supports a rated current of 63A under normal duty and 47A under heavy-duty conditions. It utilizes the Modbus RTU communication protocol over a 3-phase input network with a supply input frequency range of 45-66 Hz and an output frequency range of 0-550 Hz. The ambient air temperature for operation spans from -20°C to +60°C. It features 1 analog output (10Vdc; source; single-ended), 5 digital inputs (0-24Vdc; PNP/NPN) plus 1 additional digital input (0-24Vdc), and 2 digital outputs (one 50mA / 0-24Vdc; source; PWM and one 2A / 240Vac; source; relay contact type). Additionally, it includes 2 analog inputs (one 0-20mA / 4-20mA / 0-10Vdc; single-ended; 11-bit conversion resolution and one 0-10Vdc; single-ended; 11-bit conversion resolution). The rated active power is 30kW for normal duty and 22kW for heavy-duty, corresponding to a rated power of 40HP and 30HP, respectively.

Nidec

I5DAE155D10V00000S

Lenze I5DAE155D10V00000S is a variable speed/frequency drive (VSD/VFD) or inverter within the Power units sub-range designed for control cabinet or surface/wall mounting. This part does not feature a communication interface but is equipped with protection functions including overvoltage category, leakage current, earth fault resistance, and overtemperature of motor. It operates with a rated current of 3.2A for heavy-duty applications at a supply voltage of 230Vac / 240Vac. The degree of protection provided is IP20, suitable for single-phase (1P) or three-phase (3P / 3AC) networks. It delivers a rated active power of 0.55kW and a rated power of 3/4HP for heavy-duty applications at 230-240Vac.

Lenze

M701-09201760E10101AB100

NIDEC M701-09201760E10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M701 series designed with a built-in brake transistor, single Safe Torque Off (STO), and requires an external choke with air cooling for operation. It features dimensions of frame size 9E, measuring H39.7" x W12.21" x D11.42" (H1010mm x W310mm x D290mm). This model supports RS-485 Modbus RTU communication protocol and operates with a rated current of 216A under normal duty and 176A under heavy-duty conditions. It is designed for a supply voltage of 200Vac-240Vac (220Vac / 230Vac) and can function within an ambient air temperature range of -20°C to +40°C. The device offers an IP20 NEMA 1 UL open degree of protection and is suitable for a 3-phase input network with a supply input frequency of 45-66 Hz and an output frequency range of 0-599 Hz. It includes 2 analog outputs (0-20mA / 4-20mA / -10...+10Vdc; source; 10-bit conversion resolution), 6 digital inputs (0-24Vdc), 4 digital outputs (0-24Vdc; source and 2A / 240Vac; source; relay contact type), and 3 analog inputs (0-20mA / 4-20mA / -10...+10Vdc; with different conversion resolutions). The rated active power is 55kW under normal duty and 45kW under heavy-duty, equivalent to 75HP and 60HP respectively.

Nidec

HVW701B028T2N01-I-X

WEG HVW701B028T2N01-I-X - STANDARD PANEL HVW701B028T2N01-I-X, HVAC Enclosed Drives (HVW)

WEG

F600-04200180A10101AB103

NIDEC F600-04200180A10101AB103 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for variable speed control of AC motors. It operates within an ambient air temperature range of -20°C to +40°C and offers a degree of protection rated at IP20. This model features a frame size 4 with dimensions of H15.4" x W4.9" x D7.9" (H391mm x W124mm x D200mm). It includes 1 analog output (0-10Vdc), 2 digital outputs (240Vac; relay contact type), 1 analog input (4-20mA / 0-10Vdc; single-ended), and 3 digital inputs (24Vdc) plus an additional 3 digital inputs (0-24Vdc; configurable) for flexible connectivity. The F600 series drive is equipped with a built-in brake transistor, internal line choke, and air cooling design. It requires a supply voltage of 200Vac-240Vac (220Vac / 230Vac) with a network frequency of 60 Hz and supports Modbus RTU communication protocol. The rated current for normal duty is 18A, with a rated active power of 4kW and rated power of 5HP for normal duty operations. It is designed for a 3-phase input (3P) network.

Nidec

CFW700A10P0S2DB20

DRIVE CFW700A10P0S2DB20

WEG

F600-08500860A10101AB103

NIDEC F600-08500860A10101AB103 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for 3-phase input with a supply voltage range of 500Vac-575Vac and a network frequency of 60 Hz. It features a built-in brake transistor, an internal line choke, and air cooling for efficient operation. The device offers a rated current of 86A and supports a rated active power of 55kW or 75HP under normal duty conditions. It is equipped with 1 analog input (4-20mA / 0-10Vdc; single-ended), 1 analog output (0-10Vdc), 3 digital inputs (24Vdc), and 2 digital outputs (240Vac; relay contact type), all housed within an IP20 degree of protection frame sized at 31.6" x 12.2" x 11.4" (H803mm x W310mm x D290mm). The F600 series drive utilizes the Modbus RTU communication protocol for connectivity and is designed to operate within an ambient air temperature range of -20°C to +40°C.

Nidec

I55AE345F10V11012S

Lenze I55AE345F10V11012S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed and frequency control, compact inverter functionality, DC-injection braking, brake management, S-ramps for smooth acceleration and deceleration, flying restart circuit, and PID controller operations. It features a built-in RFI filter, standard I.O., and conformal coating, with dimensions of H450mm x W250mm x D230mm. This model supports Ethernet POWERLINK communication protocol and includes protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It operates with a rated current of 107A (light-duty; 400Vac), 92.4A (light-duty; 480Vac), 89A (heavy-duty; 400Vac), and 77A (heavy-duty; 480Vac), and a supply voltage of 400Vac / 480Vac. Suitable for control cabinet or surface/wall mounting, it can function in ambient air temperatures up to 45°C (at a switching frequency of 2kHz or 4kHz) and 40°C (at a switching frequency of 8kHz or 16kHz), with an IP20 degree of protection. The network type is 3-phase (3P / 3AC), with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 x analog output, 5 x digital inputs (with options for frequency or encoder input), 1 x digital output, and 2 x analog inputs (with options for voltage or current input). The rated active power is 55kW (light-duty; 400-480Vac) and 45kW (heavy-duty; 400-480Vac), with a rated power of 75HP (light-duty; 400-480Vac) and 60HP (heavy-duty; 400-480Vac).

Lenze

I55AE330F10V11012S

Lenze I55AE330F10V11012S is a Variable Speed/Frequency Drive (VSD/VFD) from the Drives sub-range, designed for variable speed and frequency control with additional features including compact inverter DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and a PID controller. It incorporates a built-in RFI filter, standard I.O. conformal coating, and has dimensions of H450mm x W250mm x D230mm. This model supports Ethernet POWERLINK communication protocol and offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It operates with a rated current of 73.2A (light-duty; 400Vac), 62.4A (light-duty; 480Vac), 61A (heavy-duty; 400Vac), and 52A (heavy-duty; 480Vac), and a supply voltage of 400Vac / 480Vac. Suitable for control cabinet or surface/wall mounting, it can function within an ambient air temperature range of up to 45°C (at a switching frequency of 2kHz or 4kHz) and up to 40°C (at a switching frequency of 8kHz or 16kHz), with a degree of protection of IP20. The network type is 3-phase (3P / 3AC) with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It features 1 x analog output, multiple digital inputs with optional uses, 2 x analog inputs with optional uses, and is rated for an active power of 37kW (light-duty; 400-480Vac) and 30kW (heavy-duty; 400-480Vac), translating to a power rating of 50HP (light-duty; 400-480Vac) and 40HP (heavy-duty; 400-480Vac).

Lenze

CFW700B28P0T2DBN1

WEG CFW700B28P0T2DBN1 - DRIVE CFW700B28P0T2DBN1, CFW500/700 Drives

WEG

I55AE345F10V1100KS

Lenze I55AE345F10V1100KS is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed and frequency control, compact inverter functionality, DC-injection braking, brake management, S-ramps for smooth acceleration and deceleration, flying restart circuit, and PID controller operations. It features a built-in RFI filter, standard I.O., and conformal coating. The dimensions are H450mm x W250mm x D230mm. It supports EtherCAT communication protocol and includes protection functions for overvoltage category, leakage current, earth fault resistance, and overtemperature of the motor. The rated current is 107A for light-duty at 400Vac, 92.4A for light-duty at 480Vac, 89A for heavy-duty at 400Vac, and 77A for heavy-duty at 480Vac. The supply voltage is 400Vac / 480Vac, with mounting options for control cabinet or surface/wall mounting. The ambient air temperature for operation is up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at a switching frequency of 8kHz or 16kHz. It has an IP20 degree of protection, operates on a 3-phase network (3P / 3AC), with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). The device includes 1 x analog output (0-10Vdc; 0-20mA or 4-20mA), 5 x digital inputs (PNP/NPN logic), 1 x digital output (max. 100mA), and 2 x analog inputs (-10...+10Vdc; 0-20mA or 4-20mA). The rated active power is 55kW for light-duty and 45kW for heavy-duty, with a rated power of 75HP for light-duty and 60HP for heavy-duty, both at 400-480Vac.

Lenze

S100-02S51-0B0000

Nidec S100-02S51-0B0000

Nidec

ATV61HU40S6X

Schneider Electric ATV61HU40S6X is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 61 series designed with a built-in heatsink. It operates on a supply voltage of 425-660Vac, including nominal voltages of 440Vac, 480Vac, 500Vac, and 600Vac. This model features dimensions of H295mm x W210mm x D213mm and offers an IP20 UL type 1 degree of protection. It has a rated current of 7.5A at 500Vac and 4kHz, 6.1A at 575Vac and 4kHz, with a maximum current of 9A for 60 seconds. The ATV61HU40S6X supports wall mounting and uses Modbus and CANopen communication protocols. It is designed for a 3-phase network with an output frequency range of 0.1-599 Hz. The unit includes 1 analog output (0-10Vdc / 0-20mA), 5 digital inputs (24Vdc; sink/source) that are programmable, plus an additional programmable digital input and a PWR safety input. It also features 1 digital output with a changeover SPDT relay contact and another with a normally open relay contact. The analog inputs consist of one accepting -10...+10Vdc and another for 0-10Vdc / 0-20mA signals. The current consumption is rated at 12.5A for 500Vac and 10.9A for 600Vac, with a rated active power of 4kW and a rated power of 5HP.

Schneider Electric

ACS380-040S-04A0-4

ACS380-040S-04A0-4 PN: 1.5 kW, IN: 4.0 A

ABB Control

I5DAE330F10V10000S

Lenze I5DAE330F10V10000S is a variable speed/frequency drive (VSD/VFD) or inverter within the Power units sub-range, designed with a built-in RFI filter. This model does not include a communication interface. It features protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. The rated current varies with the operational mode and supply voltage: 73.2A for light-duty at 400Vac, 62.4A for light-duty at 480Vac, 61A for heavy-duty at 400Vac, and 52A for heavy-duty at 480Vac. It operates on a supply voltage of either 400Vac or 480Vac and is suitable for mounting in a control cabinet or on a surface/wall, with an IP20 degree of protection. This inverter is designed for a 3-phase network (3P / 3AC), with a rated active power of 30kW and rated power of 40HP for heavy-duty applications at 400-480Vac.

Lenze

C200-05500069A10101AB100

NIDEC C200-05500069A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the C200 series designed with air cooling. It operates on a supply voltage of 500Vac-575Vac and has dimensions of frame size 5 H15.39" x W5.63" x D7.87" (H391mm x W143mm x D200mm). This model offers a degree of protection of IP20 NEMA 1 and supports a rated current of 10A for Normal duty and 6.9A for Heavy-duty. It utilizes the Modbus RTU communication protocol over a 3-phase input network with a supply input frequency of 45-66 Hz and an output frequency range of 0-550 Hz. The ambient air temperature for operation is between -20°C and +60°C. It features 1 analog output (10Vdc; source; single-ended), 5 digital inputs (0-24Vdc; PNP/NPN) plus 1 additional digital input (0-24Vdc), and 2 digital outputs (one 50mA / 0-24Vdc; source; PWM and one 2A / 240Vac; source; relay contact type). Additionally, it includes 2 analog inputs (one 0-20mA / 4-20mA / 0-10Vdc; single-ended; 11-bit conversion resolution and one 0-10Vdc; single-ended; 11-bit conversion resolution). The rated active power is 5.5kW for Normal duty and 4kW for Heavy-duty, with a rated power of 7.5HP / 7-1/2HP for Normal duty and 5HP for Heavy-duty.

Nidec

ATV61HU75S6X

Schneider Electric ATV61HU75S6X is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 61 series designed with a built-in heatsink. It operates on a supply voltage of 425-660Vac, including nominal voltages of 440Vac, 480Vac, 500Vac, and 600Vac. This model features a degree of protection of IP20 UL type 1 and supports wall mounting. It is equipped with a range of functions including U/F ratio adjustment (2 points / 5 points / energy saving), sensorless flux vector control, and vector control without speed feedback, capable of delivering 120% of the nominal motor torque. The drive has a rated current of 13.5A at 500Vac and 4kHz, 11A at 575Vac and 4kHz, with a maximum current of 16.2A for 60 seconds. Communication is facilitated through Modbus and CANopen protocols, and it is designed for a 3-phase network with an output frequency range of 0.1-599 Hz. The ATV61HU75S6X includes 1 analog output (0-10Vdc / 0-20mA), 5 digital inputs (24Vdc; sink/source) plus 1 programmable digital input and 1 PWR safety input, along with 2 digital outputs. It also features 2 analog inputs for comprehensive control. The dimensions are H295mm x W210mm x D213mm, with a current consumption of 21.4A at 500Vac and 18.4A at 600Vac. It is rated for an active power of 7.5kW and a power capacity of 10HP.

Schneider Electric

M701-09601040E10101AB100

NIDEC M701-09601040E10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M701 series designed with a built-in brake transistor, single Safe Torque Off (STO), and requires an external choke with air cooling for operation. It features dimensions of frame size 9E, measuring H39.7" x W12.21" x D11.42" (H1010mm x W310mm x D290mm). This model supports RS-485 Modbus RTU communication protocol and operates with a rated current of 125A under normal duty and 104A under heavy-duty conditions. It is designed for a supply voltage of 500Vac-690Vac (600Vac) and can operate in ambient air temperatures ranging from -20°C to +40°C. The degree of protection is IP20 NEMA 1 UL open, suitable for 3-phase input (3P) networks with a supply input frequency of 45-66 Hz and an output frequency range of 0-599 Hz. It includes 2 x analog outputs (0-20mA / 4-20mA / -10...+10Vdc; source; 10-bit conversion resolution), 6 x digital inputs (0-24Vdc), and 4 x digital outputs (including one 2A / 240Vac; source; relay contact type). Additionally, it has 3 x analog inputs with varying specifications, including one differential and two single-ended inputs, all with an 11-bit conversion resolution. The rated active power is 110kW for normal duty and 90kW for heavy-duty, corresponding to 150HP and 125HP, respectively.

Nidec

VLB30004A480

VLB30004A480 Lovato - Variable speed drive, VLB3... type, three-phase supply 400-480VAC 50/60Hz. EMC suppressor built-in, Cat. C1, 0.4kW

Lovato Electric
