Variable Frequency Drives (VFD)

F600-06200500A10101AB653

NIDEC F600-06200500A10101AB653 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for 3-phase input with a supply voltage range of 200Vac-240Vac, specifically 220Vac or 230Vac, and operates on a 60 Hz network frequency. It features a built-in brake transistor, an internal line choke, and utilizes air cooling for its operation. The device is capable of handling a rated current of 50A under normal duty, translating to a rated active power of 11kW or 15HP. It is equipped with 1 analog input (4-20mA / 0-10Vdc; single-ended), 1 analog output (0-10Vdc), 3 digital inputs (24Vdc), 3 additional digital inputs (0-24Vdc; configurable), and 2 digital outputs (240Vac; relay contact type). This model, part of the F600 series, is designed with an IP65 degree of protection and has dimensions of frame size 6, measuring H15.4" x W8.3" x D8.9" (H391mm x W210mm x D227mm). Communication is facilitated via Modbus RTU protocol, ensuring compatibility with various industrial setups.

Nidec

I55AE175D1AV0100LS

Lenze I55AE175D1AV0100LS is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for compact inverter applications with DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and a PID controller. It adheres to the safe torque off (STO) safety standard and features an I.O. conformal coating. The dimensions are H180mm x W60mm x D130mm. It supports PROFINET communication protocol and includes protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. The rated current is 4.2A for heavy-duty applications at 230-240Vac, with a supply voltage of 230Vac / 240Vac. It is suitable for control cabinet or surface/wall mounting, operates within an ambient air temperature range of up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at a switching frequency of 8kHz or 16kHz, with an IP20 degree of protection. It can be used in both single-phase and three-phase networks, with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). The device includes 1 x analog output, 5 x digital inputs with flexible functionality, 1 x digital output, and 2 x analog inputs, supporting both voltage and current input/output configurations. It has a rated active power of 0.75kW and a rated power of 1HP for heavy-duty applications at 230-240Vac.

Lenze

UMI-0055CU-B5

UMI-0055CU-B5 Unitronics - Limited Availability. If Not Available Use UMI-0055CU-B7

Unitronics

I55AE125B10V1100WS

Lenze I55AE125B10V1100WS is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for compact inverter applications with DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and a PID controller. It features a built-in RFI filter, standard I.O., and conformal coating. The dimensions are H155mm x W60mm x D130mm. It supports Modbus TCP communication protocol and includes protection functions for overvoltage category, leakage current, earth fault resistance, and overtemperature of the motor. The rated current is 1.7A for heavy-duty applications at 230-240Vac, with a supply voltage of 230Vac / 240Vac. It is suitable for control cabinet or surface/wall mounting, operates within an ambient air temperature of 45°C at a switching frequency of 2kHz or 4kHz, and 40°C at a switching frequency of 8kHz or 16kHz, with a degree of protection of IP20. It is designed for a single-phase / 1P network with an input frequency of 45-65 Hz and an output frequency of 0-599 Hz. The device includes 1 x analog output (0-10Vdc; 0-20mA or 4-20mA), 5 x digital inputs (PNP/NPN logic), 1 x digital output (max. 100mA), and 2 x analog inputs (-10...+10Vdc; 0-20mA or 4-20mA). The rated active power is 0.25kW, and the rated power is 1/3HP for heavy-duty applications at 230-240Vac.

Lenze

HVW701E211T2N12-I-A

WEG HVW701E211T2N12-I-A - STANDARD PANEL HVW701E211T2N12-I-A, HVAC Enclosed Drives (HVW)

WEG

SP1404-HF

NIDEC SP1404-HF is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for high frequency applications up to 3000Hz max in an open-loop configuration with a single Safe Torque Off (STO) and air cooling. It features a frame size 1 with dimensions of H15.2" x W3.93" x D8.62" (H386mm x W100mm x D219mm), and operates on a supply voltage of 380Vac-480Vac (400Vac / 415Vac). The rated current is 6.9A under normal duty and 5.8A under heavy-duty conditions. This wall-mounted unit is designed to operate within an ambient air temperature range of 0°C to +40°C and has a degree of protection rated at IP20 NEMA 1. It supports Modbus RTU RS-485 communication protocol and operates on a network frequency of 48-65 Hz (supply input) with an output frequency range of 0-3000 Hz. The SP1404-HF includes 3 digital outputs (0-24Vdc; source), 1 digital output (2A / 240Vac; source; relay contact type), 3 digital inputs (0-24Vdc), and 3 additional digital inputs (0-24Vdc). Analog interface options include 1 analog input (-9.8Vdc...9.8Vdc; differential) with 16-bit conversion resolution and 2 analog inputs (0-20mA / 4-20mA / -9.8Vdc...9.8Vdc; single-ended) with 10-bit conversion resolution, alongside 2 analog outputs (0-20mA / 4-20mA / -10Vdc...10Vdc; single-ended; source) with 10-bit conversion resolution. The rated active power is 3kW for normal duty and 2.2kW for heavy-duty, corresponding to 5HP and 3HP respectively.

Nidec

ACS35503U12A54J400

MACHINERY DRIVE, 7.5 HP, 12.5 A, 480 VAC, Voltage Range: 380-480V, UL TYPE OPEN (IP20), Cabinet-mounted, Advanced Panel, 3-Phase Input, 3-Phase Output, Frame: R3

ABB Control

HVW701B024T4N01-J-B

WEG HVW701B024T4N01-J-B - STANDARD PANEL HVW701B024T4N01-J-B, HVAC Enclosed Drives (HVW)

WEG

HVW701D086T2N12-J-X

WEG HVW701D086T2N12-J-X - STANDARD PANEL HVW701D086T2N12-J-X, HVAC Enclosed Drives (HVW)

WEG

I51AE155B10V11000S

Lenze I51AE155B10V11000S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for compact applications, featuring DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, a flying restart circuit, and a PID controller. It includes a built-in RFI filter, basic I.O., and conformal coating. The dimensions are H180mm x W60mm x D130mm. This model does not have a communication interface but offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It has a rated current of 3.2A for heavy-duty applications at 230-240Vac, with a supply voltage of 230Vac / 240Vac. Suitable for control cabinet or surface/wall mounting, it operates within an ambient air temperature range of up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at 8kHz or 16kHz, with an IP20 degree of protection. It supports a single-phase network with an input frequency of 45-65 Hz and an output frequency of 0-599 Hz. The inverter includes 1 analog output, 5 digital inputs with flexible functionality, 1 digital output, and 2 analog inputs, supporting both voltage and current signals. It has a rated active power of 0.55kW and a rated power of 3/4HP for heavy-duty applications at 230-240Vac.

Lenze

CFW500B04P3T5DB66

DRIVE CFW500B04P3T5DB66

WEG

I55AE175D10V01000S

Lenze I55AE175D10V01000S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed and frequency control with additional features including DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and a PID controller. It has a standard I.O. conformal coating design, with dimensions of H180mm x W60mm x D130mm. This model does not include a communication interface but offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It operates at a rated current of 4.2A for heavy-duty applications at 230-240Vac, and is suitable for control cabinet or surface/wall mounting. The ambient air temperature for operation varies with the switching frequency, allowing a maximum of 45°C at 2kHz or 4kHz and 40°C at 8kHz or 16kHz, with a degree of protection rated at IP20. It supports both single-phase and three-phase networks, with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). The device includes 1 analog output, 5 digital inputs with options for frequency or encoder input, 1 digital output, and 2 analog inputs, all supporting various configurations. It has a rated active power of 0.75kW and a rated power of 1HP for heavy-duty applications at 230-240Vac.

Lenze

HS72-07200750A10101AB100

NIDEC HS72-07200750A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the HS72 series designed for variable speed/frequency control with rated frequency outputs of 0-3000Hz in open loop and 0-1250Hz in closed loop applications. It features a built-in brake transistor and dual Safe Torque Off (STO) functionality suitable for high-speed applications, alongside air cooling for thermal management. The dimensions are frame size 7, measuring H21.9" x W10.6" x D11" (H557mm x W270mm x D280mm). This model supports Ethernet communication protocol and operates with a rated current of 94A under normal duty and 75A under heavy-duty conditions. It requires a supply voltage of 200Vac-240Vac (220Vac / 230Vac) and is designed to function within an ambient air temperature range of -20°C to +40°C. The degree of protection is IP20 NEMA 1 UL open, and it is equipped for a 3-phase input network with a supply input frequency of 45-66 Hz and an output frequency up to 3000 Hz. The drive includes 2 x digital inputs (0-24Vdc), with terminal 8 configurable as a motor protection thermistor, and 2 x digital outputs (100mA / 0-24Vdc; source) plus 1 x digital output (2A / 240Vac; source; relay contact type). It has a rated active power of 22kW under normal duty and 18.5kW under heavy-duty, corresponding to 30HP and 25HP respectively.

Nidec

ATV71HU22M3S337

Schneider Electric ATV71HU22M3S337 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 71 series, designed for variable speed and frequency control with a U/F ratio of 2 points / 5 points. It features sensorless flux vector control, ENA System, and vector control with or without speed feedback. This model can deliver 220% of the nominal motor torque for 2 seconds and 170% of the nominal motor torque for 60 seconds. It includes a built-in EMC filter, built-in heatsink, and is a coated version for enhanced durability. The supply voltage ranges from 170-264Vac, accommodating 200Vac, 220Vac, 230Vac, and 240Vac nominal values. Dimensions are H260mm x W155mm x D187mm, with a conformal coating for chemical resistance. It has an IP20 UL type 1 degree of protection and supports wall mounting. The rated current specifications are 11A for 230Vac at 4kHz in a 3-phase configuration, 8A for 230Vac at 4kHz in a single-phase configuration, with maximum currents of 13.2A (single-phase for 2s), 18.1A (3-phase for 2s), 12A (single-phase for 60s), and 16.5A (3-phase for 60s). Communication is facilitated via Modbus and CANopen protocols, suitable for single-phase (1P) and 3-phase (3P) networks with an output frequency range of 0.1-599 Hz. It features 1 analog output (0-10Vdc / 0-20mA), 5 digital inputs (24Vdc; sink/source), an additional programmable digital input, and a PWR safety input, alongside 1 digital output (C/O SPDT relay contact) and 2 digital outputs (NO relay contacts). Analog inputs include 1 x (-10...+10Vdc) and 1 x (0-10Vdc / 0-20mA). Current consumption is detailed for various configurations, with rated active power of 2.2kW for 3-phase and 1.5kW for single-phase, corresponding to 3HP and 2HP respectively.

Schneider Electric

UMI-0015EU-B7

UMI-0015EU-B7 Unitronics - Unitronics VFD - B7 Series, 380-480V, 3 Phase, 1.5kW, 2HP, STO included

Unitronics

CFW500A10P0T4DB66G2

DRIVE CFW500A10P0T4DB66G2

WEG

HVW701B024GN01200000

WEG HVW701B024GN01200000 - STANDARD PANEL HVW701B024GN01200000, HVAC Enclosed Drives (HVW)

WEG

ESV552N04TXC

ESV552N04TXC Lenze Variable Frequency Drive (VFD) - The SMV 7.5 hp (5.5 kW) drive features a 400 / 480 VAC 3Ø input in a convection cooled NEMA 4X (IP65) indoor enclosure. The SMVector NEMA 4X (IP65) offers exemplary performance even in harsh environments. These decentralized drives are suitable for wall mounting and are available in two enclosure materials suitable for either indoor or outdoor use. This drive is also available with an integral disconnect switch and integrated line filter ideal

Lenze

ESV402N02TXE

ESV402N02TXE Lenze Variable Frequency Drive (VFD) - The SMV 5.0 hp (4.0 kW) drive features a 208 / 240 VAC 3Ø input in a convection cooled NEMA 4X (IP65) indoor/outdoor enclosure. The SMVector NEMA 4X (IP65) offers exemplary performance even in harsh environments. These decentralized drives are suitable for wall mounting and are available in two enclosure materials suitable for either indoor or outdoor use. This drive is also available with an integral disconnect switch and integrated line filte

Lenze

M400-02200056A10101AB100

NIDEC M400-02200056A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M400 series designed with a built-in brake transistor and dual Safe Torque Off (STO) for air cooling. It features dimensions of frame size 2, measuring H8.1" x W3.1" x D5.9" (H205mm x W78mm x D150mm). This model supports multiple communication protocols including CANopen, DeviceNet, Ethernet/IP, Modbus RTU, Modbus TCP, PROFINET RT, and PROFIBUS DP. It operates with a rated current of 5.6A for both normal and heavy-duty applications and requires a supply voltage of 200Vac-240Vac (220Vac / 230Vac). The ambient air temperature for operation ranges from -20°C to +60°C, and it is designed with an IP20 NEMA 1 degree of protection. It accommodates both single-phase input (2P) and 3-phase input (3P) with a network frequency of 45-66 Hz (supply input) and 0-550 Hz (output). The device includes 2 analog outputs, 8 digital inputs, and 3 digital outputs, alongside 2 analog inputs with an 11-bit conversion resolution. It has a rated active power of 1.1kW and a rated power of 1.5HP / 1-1/2HP for both normal and heavy-duty operations.

Nidec
