Pneumatic Fittings

153246

multiple distributor QSLV6-3/8-8 6-fold, 360° orientable. Size: Standard, Nominal size: 4,1 mm, Type of seal on screw-in stud: coating, Assembly position: Any, Design structure: Push/pull principle

Festo

153239

multiple distributor QSLV4-3/8-12 4-fold, 360° orientable. Size: Standard, Nominal size: 6 mm, Type of seal on screw-in stud: coating, Assembly position: Any, Design structure: Push/pull principle

Festo

35990

barbed L-fitting LCNH-3/8-PK-6 Rotatable, with extended housing, for plastic tubing PAN, PUN, PP, PU, PR, with sealing ring. Nominal size: 4,9 mm, Type of seal on screw-in stud: Sealing ring, Operating pressure complete temperature range: -0,95 - 10 bar,

Festo

9398

adapter AD-G1/2-1/2NPT-I Female thread one one side, male thread on the other. Nominal size: 14,3 mm, Operating pressure complete temperature range: -0,95 - 10 bar, Corrosion resistance classification CRC: 1 - Low corrosion stress, Ambient temperature: -1

Festo

130641

push-in bulkhead connector QSSK-12 Size: Standard, Nominal size: 6,3 mm, Approved tubing type: (* PAN-, * PAN-MF-, * PAN-R-, * PAN-V0-, * PEN-, * PFAN-, * PLN-, * PTFEN-, * PUN-, * PUN-CM-, * PUN-DUO-, * PUN-H-, * PUN-H-DUO-, * PUN-S-, * PUN-S-DUO-, * PUN

Festo

133058

push-in L-fitting NPQP-L-R38-Q10-FD-P10 Size: Standard, Nominal size: 5,7 mm, Container size: 10, Design structure: Push/pull principle, Temperature dependent operating pressure: -0,95 - 10 bar

Festo

130666

push-in L-connector CRQSL-12 Size: Standard, Nominal size: 7,8 mm, Assembly position: Any, Design: L-shape, Container size: 1

Festo

4490

quick T-connector TCK-3/8-PK-9 Swivelling with 2 sealing rings. Nominal size: 8 mm, Type of seal on screw-in stud: Sealing ring, Assembly position: Any, Pneumatic connection, port 1: Male thread G3/8, Pneumatic connection, port 2: for barbed connector i

Festo

153441

push-in connector, self-sealing QSK-8 Size: Standard, Nominal size: 4,4 mm, Approved tubing type: (* PAN-, * PAN-MF-, * PAN-R-, * PAN-V0-, * PEN-, * PFAN-, * PLN-, * PTFEN-, * PUN-, * PUN-CM-, * PUN-DUO-, * PUN-H-, * PUN-H-DUO-, * PUN-S-, * PUN-S-DUO-, *

Festo

153109

push-in T-fitting QST-1/8-8 360° orientable, male thread with external hexagon. Size: Standard, Nominal size: 6 mm, Type of seal on screw-in stud: coating, Assembly position: Any, Container size: 10

Festo

133076

push-in T-fitting NPQP-T-R14-Q8-FD-P10 Size: Standard, Nominal size: 4,7 mm, Container size: 10, Design structure: Push/pull principle, Temperature dependent operating pressure: -0,95 - 10 bar

Festo

153093

push-in L-fitting QSLV-3/8-10 360° orientable, male thread with external hexagon. Size: Standard, Nominal size: 8 mm, Type of seal on screw-in stud: coating, Assembly position: Any, Container size: 10

Festo

153060

push-in L-connector QSL-12H with push-in sleeve. Size: Standard, Nominal size: 6,8 mm, Assembly position: Any, Container size: 10, Design structure: Push/pull principle

Festo

133035

push-in connector QSM-3H-2 with push-in sleeve. Size: Mini, Nominal size: 1,1 mm, Type of seal on screw-in stud: Sealing ring, Assembly position: Any, Container size: 10

Festo

4597

ring piece LK-1/8-PK-3 With 2 sealing rings. Maritime classification: see certificate, Pneumatic connection, port 2: for barbed connector internal diameter 3 mm with nut, Materials note: Conforms to RoHS

Festo

9397

adapter AD-G3/8-3/8NPT-I Female thread one one side, male thread on the other. Nominal size: 11,5 mm, Operating pressure complete temperature range: -0,95 - 10 bar, Corrosion resistance classification CRC: 1 - Low corrosion stress, Ambient temperature: -1

Festo

132951

cartridge QSPLLKG18-10 With push-in connector, long L-form Size: Standard, Nominal size: 6,4 mm, Type of seal on screw-in stud: O-ring, Assembly position: Any, Container size: 10

Festo

153325

push-in connector QSM-6 Size: Mini, Nominal size: 3,7 mm, Assembly position: Any, Container size: 10, Design structure: Push/pull principle

Festo

153342

push-in L-fitting, long QSMLL-1/8-6 360° orientable, male thread with external hexagon. Size: Mini, Nominal size: 3,1 mm, Type of seal on screw-in stud: coating, Assembly position: Any, Container size: 10

Festo

132940

cartridge QSPLKG14-1/4-U Size: Mini, Nominal size: 3,5 mm, Assembly position: Any, Container size: 10, Design structure: Push/pull principle

Festo
