Pneumatic Fittings

153439

push-in connector, self-sealing QSK-4 Size: Standard, Nominal size: 1,6 mm, Approved tubing type: (* PAN-, * PAN-MF-, * PAN-R-, * PAN-V0-, * PEN-, * PFAN-, * PLN-, * PTFEN-, * PUN-, * PUN-CM-, * PUN-DUO-, * PUN-H-, * PUN-H-DUO-, * PUN-S-, * PUN-S-DUO-, *

Festo

132924

cartridge QSPLKG10-1/4-U Size: Mini, Nominal size: 3,3 mm, Assembly position: Any, Container size: 10, Design structure: Push/pull principle

Festo

9624

adapter AD-1/8NPT-G1/8-I Female thread one one side, male thread on the other. Nominal size: 5,95 mm, Operating pressure complete temperature range: -0,95 - 10 bar, Corrosion resistance classification CRC: 1 - Low corrosion stress, Ambient temperature: -1

Festo

153237

multiple distributor QSLV4-1/4-10 4-fold, 360° orientable. Size: Standard, Nominal size: 5 mm, Type of seal on screw-in stud: coating, Assembly position: Any, Design structure: Push/pull principle

Festo

35983

barbed L-fitting LCNH-M5-PK-3 Rotatable, with extended housing, for plastic tubing PAN, PUN, PP, PU, PR, with sealing ring. Nominal size: 2 mm, Type of seal on screw-in stud: Sealing ring, Operating pressure complete temperature range: -0,95 - 10 bar, Ope

Festo

153173

push-in Y-fitting QSYL-1/8-6 360° orientable, male thread with external hexagon. Size: Standard, Nominal size: 4,2 mm, Type of seal on screw-in stud: coating, Assembly position: Any, Container size: 1

Festo

35985

barbed L-fitting LCNH-1/8-PK-3 Rotatable, with extended housing, for plastic tubing PAN, PUN, PP, PU, PR, with sealing ring. Nominal size: 2 mm, Type of seal on screw-in stud: Sealing ring, Operating pressure complete temperature range: -0,95 - 10 bar, Op

Festo

9390

bulkhead quick connector SCK-PK-9-KU Polymeric design. Nominal size: 8 mm, Assembly position: Any, Operating pressure complete temperature range: 0 - 10 bar, Ambient temperature: -10 - 60 °C, Pneumatic connection, port 1: for barbed connector internal di

Festo

4478

ring piece LK-1/4-PK-4 With 2 sealing rings. Maritime classification: see certificate, Pneumatic connection, port 2: for barbed connector internal diameter 4 mm with nut, Materials note: Conforms to RoHS

Festo

2154

quick coupling plug KS4-1/4-A For self-closing quick coupling connectors. Nominal size: 7,85 mm, Operating pressure complete temperature range: -0,95 - 12 bar, Standard nominal flow rate: 1260 l/min, Operating medium: Compressed air in accordance with ISO

Festo

3605

barbed hose fitting N-1/8-P-6 With sealing ring. Nominal size: 4,5 mm, Type of seal on screw-in stud: Sealing ring, Operating pressure complete temperature range: -0,95 - 16 bar, Operating medium: Compressed air in accordance with ISO8573-1:2010 [7:-:-],

Festo

2024

barbed hose fitting C-3/8-P-6 Nominal size: 4,5 mm, Operating medium: Compressed air in accordance with ISO8573-1:2010 [7:-:-], Note on operating and pilot medium: Lubricated operation possible (subsequently required for further operation), Pneumatic conn

Festo

153430

self-sealing push-in L-fitting QSKL-1/8-6 360° orientable, male thread with external hexagon. Size: Standard, Nominal size: 3 mm, Approved tubing type: (* PAN-, * PAN-MF-, * PAN-R-, * PAN-V0-, * PEN-, * PFAN-, * PLN-, * PTFEN-, * PUN-, * PUN-CM-, * PUN-DU

Festo

153443

push-in connector, self-sealing QSK-12 Size: Standard, Nominal size: 6,2 mm, Approved tubing type: (* PAN-, * PAN-MF-, * PAN-R-, * PAN-V0-, * PEN-, * PFAN-, * PLN-, * PTFEN-, * PUN-, * PUN-CM-, * PUN-DUO-, * PUN-H-, * PUN-H-DUO-, * PUN-S-, * PUN-S-DUO-, *

Festo

19527

barbed T-connector FCN-3-PK-2-B For plastic tubing PAN, PUN, PL, PP, PU. Nominal size: 1,3 mm, Operating pressure complete temperature range: -0,95 - 10 bar, Operating medium: Compressed air in accordance with ISO8573-1:2010 [7:-:-], Note on operating and

Festo

130612

push-in Y-connector QSY-12-8 reducing. Size: Standard, Nominal size: 4,5 mm, Assembly position: Any, Container size: 10, Design structure: Push/pull principle

Festo

133108

push-in L-connector NPQP-L-Q10-E-FD-P10 Size: Standard, Nominal size: 6,2 mm, Container size: 10, Design structure: Push/pull principle, Temperature dependent operating pressure: -0,95 - 10 bar

Festo

12258

barbed L-fitting LCN-M5-PK-4 Swivelling, with sealing ring. Nominal size: 2,9 mm, Type of seal on screw-in stud: Sealing ring, Operating pressure complete temperature range: -0,95 - 10 bar, Operating medium: Compressed air in accordance with ISO8573-1:201

Festo

153357

push-in T-fitting QSMT-1/8-6 360° orientable, male thread with external hexagon. Size: Mini, Nominal size: 3,3 mm, Type of seal on screw-in stud: coating, Assembly position: Any, Container size: 10

Festo

133051

push-in L-fitting NPQP-L-R18-Q4-FD-P10 Size: Standard, Nominal size: 2,1 mm, Container size: 10, Design structure: Push/pull principle, Temperature dependent operating pressure: -0,95 - 10 bar

Festo
