Pneumatic Fittings

4097

quick connector CK-3/8-PK-13 Male thread with sealing ring, metal version. Nominal size: 11,7 mm, Type of seal on screw-in stud: Sealing ring, Assembly position: Any, Maritime classification: see certificate, Operating medium: (* Compressed air in accorda

Festo

153292

push-in fitting, self-sealing QSK-M5-6 male thread with external hexagon. Size: Standard, Nominal size: 1,7 mm, Approved tubing type: (* PAN-, * PAN-MF-, * PAN-R-, * PAN-V0-, * PEN-, * PFAN-, * PLN-, * PTFEN-, * PUN-, * PUN-CM-, * PUN-DUO-, * PUN-H-, * PU

Festo

35984

barbed L-fitting LCNH-M5-PK-4 Rotatable, with extended housing, for plastic tubing PAN, PUN, PP, PU, PR, with sealing ring. Nominal size: 2,9 mm, Type of seal on screw-in stud: Sealing ring, Operating pressure complete temperature range: -0,95 - 10 bar, O

Festo

132867

cartridge QSPLLKG20-3/8-U With push-in connector, long L-form Size: Standard, Nominal size: 5,7 mm, Assembly position: Any, Container size: 10, Design structure: Push/pull principle

Festo

153376

push-in bulkhead connector QSMS-4 Size: Mini, Nominal size: 2,2 mm, Assembly position: Any, Container size: 10, Design structure: Push/pull principle

Festo

130671

push-in T-connector CRQST-10 Size: Standard, Nominal size: 6,1 mm, Assembly position: Any, Design: T-shaped, Container size: 1

Festo

133126

push-in Y-connector NPQP-Y-Q10-Q8-FD-P10 Size: Standard, Nominal size: 4,7 mm, Container size: 10, Design structure: Push/pull principle, Temperature dependent operating pressure: -0,95 - 10 bar

Festo

9421

bulkhead quick connector SCK-PK-4 Metal version. Nominal size: 3,4 mm, Assembly position: Any, Pneumatic connection, port 1: for barbed connector internal diameter 4 mm with nut, Materials note: (* Free of copper and PTFE, * Conforms to RoHS), Material h

Festo

2155

quick coupling plug KS4-3/8-A For self-closing quick coupling connectors. Nominal size: 7,85 mm, Operating pressure complete temperature range: -0,95 - 12 bar, Standard nominal flow rate: 1274 l/min, Operating medium: Compressed air in accordance with ISO

Festo

153344

push-in L-connector QSML-4 Size: Mini, Nominal size: 2,5 mm, Assembly position: Any, Container size: 10, Design structure: Push/pull principle

Festo

160520

push-in L-fitting QSL-V0-1/2-10 360° orientable, male thread with external hexagon. Size: Standard, Nominal size: 8,3 mm, Material fire test: (* UL94 V-0 (housing), * UL94 V-0 (releasing ring)), Type of seal on screw-in stud: coating, Design structure: Pu

Festo

153343

push-in L-connector QSML-3 Size: Mini, Nominal size: 1,7 mm, Assembly position: Any, Container size: 10, Design structure: Push/pull principle

Festo

133092

push-in connector NPQP-D-Q6-E-FD-P10 Size: Standard, Nominal size: 4 mm, Container size: 10, Design structure: Push/pull principle, Temperature dependent operating pressure: -0,95 - 10 bar

Festo

160506

push-in fitting QS-V0-3/8-8 male thread with external hexagon. Size: Standard, Nominal size: 7 mm, Material fire test: (* UL94 V-0 (housing), * UL94 V-0 (releasing ring)), Type of seal on screw-in stud: coating, Design structure: Push/pull principle

Festo

160504

push-in fitting QS-V0-1/4-10 male thread with external hexagon. Size: Standard, Nominal size: 8,5 mm, Material fire test: (* UL94 V-0 (housing), * UL94 V-0 (releasing ring)), Type of seal on screw-in stud: coating, Design structure: Push/pull principle

Festo

153425

push-in fitting, self-sealing QSK-1/4-10 male thread with external hexagon. Size: Standard, Nominal size: 4,8 mm, Approved tubing type: (* PAN-, * PAN-MF-, * PAN-R-, * PAN-V0-, * PEN-, * PFAN-, * PLN-, * PTFEN-, * PUN-, * PUN-CM-, * PUN-DUO-, * PUN-H-, *

Festo

177705

push-in fitting CQ-3/8-12H For high flow rates. Nominal size: 8,65 mm, Type of seal on screw-in stud: Sealing ring, Assembly position: Any, Container size: 1, Design structure: Push/pull principle

Festo

177687

push-in T-connector CQT-12 For high flow rates. Nominal size: 8,65 mm, Assembly position: Any, Container size: 1, Design structure: Push/pull principle, Operating pressure complete temperature range: -0,95 - 7 bar

Festo

153358

push-in T-fitting QSMTL-M3-3 360° orientable, male thread with external hexagon. Size: Mini, Nominal size: 0,9 mm, Type of seal on screw-in stud: Sealing ring, Assembly position: Any, Container size: 10

Festo

133067

push-in L-fitting NPQP-LQ-R14-Q10-FD-P10 Size: Standard, Nominal size: 5,8 mm, Container size: 10, Design structure: Push/pull principle, Temperature dependent operating pressure: -0,95 - 10 bar

Festo
