AC/DC Power Supplies

SL20.303

Power Supply, 480W, 380-400VAC 3PH, 48-56VDC, 10-9A

Puls

UHP-500-4.2

AC-DC Slim Single output enclosed power supply with PFC; Output 4.2VDC at 80A

MEAN WELL

GSC25B-1050

AC-DC Single output desktop LED power supply (CC) with PFC; Output 24Vdc at 1.05A; 2 pole AC IEC320-C8 input connector; GSC25B-1050 is succeeded by PLM-25-1050.

MEAN WELL

CS10.243

PULS CS10.243 is a DIN rail mounting power supply unit with an aluminium housing designed for a single-phase network. It operates within an ambient air temperature range of 0 to +70°C and has a net width of 60mm. The unit consumes 3.71A with a 120Vac input and 4.32A with a 100Vac input for a full 24Vdc output, featuring a peak inrush current of 108A at 120Vac input and 90A at 100Vac input. It offers an efficiency of 0.913 at 120Vac input and 0.91 at 100Vac input. The dimensions are W60mm x H124mm x D117mm. It includes a 250ms start-up delay for 100-120Vac input, with a rise time of 35ms under nominal input at constant full current load with 0mF load capacitance and 75ms with 10mF load capacitance. The power supply unit is equipped with protection functions including output overvoltage protection, NTC for input inrush current limiting, and overload/short-circuit protection. It supports series/parallel operation for redundancy and is resistant to back-feeding loads up to 35V. Power dissipation/losses are 22.9W at 120Vac input with full output load, and the output stage capacitance is 7000µF. Electrical durability ranges from 27,000 to 281,000 hours depending on conditions. Ripple is maintained at 50mVpp across a 20Hz to 20MHz range. This AC/DC power supply unit, part of the C-Line series, features a 20% power reserve, DC-OK relay contact output, and screw-clamp connections. It accepts a supply voltage of 90Vac-132Vac (47-63Hz) with a turn-ON voltage of 82Vac and a shutdown voltage of 78Vac in steady-state. The rated current is 12A at 24Vdc for ambient temperatures less than 45°C and 10A at 24Vdc for less than 60°C, with an adjustable output voltage of 24Vdc-28Vdc. The hold time is 46ms at 120Vac input.

Puls

PPS-125-27

AC-DC Single output Open frame power supply with PFC; Output 27Vdc at 4.6A; PPS-125-27 is succeeded by EPS-120-27.

MEAN WELL

ASP-150-12

AC-DC Single output Open frame power supply; Output 12Vdc at 11A; ASP-150-12 is succeeded by EPP-150-12.

MEAN WELL

HRP-600-24

AC-DC Single output enclosed power supply; Output 24Vdc at 27A; fan cooling

MEAN WELL

SE-100-12

AC-DC Enclosed power supply; Output 12Vdc at 8.5A; PFC; SE-100-12 is succeeded by LRS-100-12.

MEAN WELL

PSP-500-24

AC-DC Single output Enclosed power supply; Output 24Vdc at 20.8A; PSP-500-24 is succeeded by PSP-600-24.

MEAN WELL

MPS-65-13.5

AC-DC Single output Medical Open frame power supply; Output 13.5Vdc at 4.7A; 2xMOPP; MPS-65-13.5 is succeeded by RPS-65-12.

MEAN WELL

CP20.241-S2

PULS CP20.241-S2 is a power supply unit designed for DIN rail mounting, featuring an aluminium housing. It has a net width of 48 mm and operates within an ambient air temperature range of -25 to +70°C. The unit exhibits a current consumption of 11A peak max. inrush at 230Vac input and 7A peak max. inrush at 120Vac input. Its efficiency rates are 0.956 at 230Vac input, 0.942 at 120Vac input, and 0.936 at 100Vac input. The dimensions of the CP20.241-S2 are W48mm x H124mm x D127mm. It includes a 450ms start-up delay for 100-230Vac input, with rise times of 145ms and 160ms under specified conditions. The unit is equipped with protection functions including output overvoltage protection and overload/short-circuit protection, and supports series or parallel operation for increased output voltages or power. It is resistant to back-feeding loads up to 35V. Power dissipation/losses are 22.1 W at full output load with 230Vac input and 29.6 W with 120Vac input. The output stage capacitance is 8500 µF. Electrical durability spans from 31,000 to 488,000 hours under various conditions. Ripple is maintained at 50mVpp across a 20Hz to 20MHz range. This AC/DC power supply unit, part of the CP-series, is designed with a 20% power reserve and includes a DC-OK relay contact output. It features push-in spring connections for ease of installation. The supply voltage ranges from 88Vdc to 180Vdc for DC and 85Vac to 264Vac for AC, with a rated current of 20A at 24Vdc. It is suitable for single-phase (1AC) or DC networks, offering a rated power of 480W. The output voltage is adjustable between 24Vdc and 28Vdc, with a 500mV turn-ON overshoot and a hold time of 32ms at 120/230Vac input.

Puls

722757

722757 LUTZE - Switch Mode Power Supply DRAN120-24AL, Single-phase

Lutze

HEP-600-42

AC-DC Single output industrial power supply with PFC; Output 42Vdc at 14.3A; Input-output by terminal block; Withstand up to 10G Vibration

MEAN WELL

USP-225-3.3

AC-DC Single output power supply; Output 3.3Vdc at 40A; U-bracket low profile format 38mm; USP-225-3.3 is succeeded by UHP-200-3.3.

MEAN WELL

RPT-7503

AC-DC Triple output Medical Open frame power supply; Output 3.3Vdc at 7A +5Vdc at 8A +12Vdc at 1.5A; 2xMOPP

MEAN WELL

RPS-30-24

AC-DC Single output medical Open frame power supply; Output 24VDC at 1.25A; 2xMOPP

MEAN WELL

GSC18E-1400

AC-DC Single output wall mount LED power supply (CC) with PFC; Output 13Vdc at 1.4A; 2 pole AC Euro plug; GSC18E-1400 is succeeded by IDLC-25-1050.

MEAN WELL

HEP-1000-100WCPM

AC-DC Single output industrial power supply with PFC; Output 100Vdc at 10A; Input-output by waterproof wires; IP67; DC OK signal; Charger with PMBus

MEAN WELL

HEP-600-12

AC-DC Single output industrial power supply with PFC; Output 12Vdc at 40.0A; Input-output by terminal block; Withstand up to 10G Vibration

MEAN WELL

LPS-100-7.5

AC-DC Single output Open frame power supply; Output 7.5Vdc at 13.3A

MEAN WELL
