AC/DC Power Supplies

CT5.121

PULS CT5.121 is a power supply unit designed for DIN rail mounting with an aluminium housing. It operates within an ambient air temperature range of -25 to +70°C and has a net width of 40mm. The unit consumes 0.56A with a 480Vac input and 0.64A with a 400Vac input for a full 12Vdc output, with a peak inrush current of 10A for both input voltages. It features an efficiency of 0.858 at 480Vac input and 0.854 at 400Vac input. The dimensions are W40mm x H124mm x D117mm. It includes a 75ms start-up delay and a rise time of 50ms under nominal input with a constant full current load and 0mF load capacitance, extending to 85ms with 8mF load capacitance. The unit is equipped with protection functions including output overvoltage protection and an active input inrush current limiter, supporting overload/short-circuit conditions with a continuous current of max. 15A. It allows for series/parallel operation to increase output power, with a back-feeding load resistance up to 25V. Power dissipation losses are 15.9W and 16.4W for 480Vac and 400Vac inputs, respectively, under full output load. The output stage capacitance is 5200µF. Electrical durability ranges from 51,000 to 430,000 hours, depending on operating conditions. Ripple is maintained at 100mVpp across a 20Hz to 20MHz range. This AC/DC power supply unit, part of the CT-series, features a DC-OK relay contact output and screw-clamp connections. It supports a wide supply voltage range of 323Vac to 576Vac, with various shutdown voltages based on load conditions. The rated current is 8A at 12Vdc within a -25 to +60°C range, adjusting with temperature and output voltage. The rated power is 96W, with an adjustable output voltage of 12Vdc to 15Vdc and minimal turn-on overshoot. Hold time is specified at 63ms and 43ms for 480Vac and 400Vac inputs, respectively.

Puls

SL20.115

Power Supply, 480W, 100-120 / 200-240VAC 1PH, 24-28VDC, 20-18A

Puls

SL20.113

Power Supply, 480W, 100-120 / 200-240VAC 1PH, 48-56VDC, 10-8.6A

Puls

SL20.112

Power Supply, 480W, 100-120 / 200-240VAC 1PH, 36-43VDC, 13.3-11.2A

Puls

SL20.111

Power Supply, 480W, 100-120 / 200-240VAC 1PH, 24-28VDC, 20-18A with PFC

Puls

CT10.481

PULS CT10.481 is a power supply unit designed for DIN rail mounting, featuring an aluminium housing. It operates within an ambient air temperature range of -25 to +70°C and has a net width of 62mm. The unit consumes 0.6A with a 3 x 480Vac input and 0.7A with a 3 x 400Vac input, both at full 48Vdc output, with a peak inrush current of 10A. It boasts an efficiency of 0.929 for 3x480Vac input and 0.928 for 3x400Vac input. The dimensions are W62mm x H124mm x D117mm. It includes a 90ms start-up delay, a 55ms rise time at nominal input with a constant full current load and 0mF load capacitance, and a 140ms rise time with 5mF load capacitance. The unit features output overvoltage protection, an active input inrush current limiter, and supports series/parallel operation for increased output power. It is resistant to back-feeding loads up to 63V. Power dissipation/losses are 18.3W for 3x480Vac input and 18.6W for 3x400Vac input at full output load. The output stage capacitance is 2400µF. Electrical durability ranges from 78,000 to 704,000 hours depending on the operating conditions. The ripple is 100mVpp (20Hz...20MHz; 50Ω). This AC/DC power supply unit/converter offers a 20% power reserve and includes a DC-OK relay contact output. It features screw-clamp connections and supports a supply voltage of 323Vac-576Vac (wide range; 3-phase input) with a rated current of 6A at 48Vdc from -25 to +45°C and 3.75A at 48Vdc from -25 to +70°C. The output voltage is adjustable between 48Vdc and 56Vdc, with a hold time of 54ms at 3x480Vac input and 34ms at 3x400Vac input.

Puls

CS10.241-S1

PULS CS10.241-S1 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It operates within an ambient air temperature range of -25 to +70°C and supports various current consumptions based on input voltage: 2.23A at 230Vac, 3.73A at 120Vac, and 4.34A at 100Vac, all for full 24Vdc output, with a peak inrush current of 10A across all input voltages. The unit boasts an efficiency of up to 0.916 at 230Vac input. Its dimensions are 60mm in width, 124mm in height, and 117mm in depth. The CS10.241-S1 features a start-up delay of 850ms and rise times of 35ms to 75ms depending on load capacitance. It includes protection functions such as output overvoltage protection and an active input inrush current limiter, alongside capabilities for series or parallel operation for redundancy. The power dissipation at full output load is 22W for 230Vac input and 23.7W for 120Vac input. The output stage capacitance is 7000µF, and electrical durability ranges from 34,000 to 334,000 hours depending on operating conditions. The ripple is maintained at 50mVpp. This AC/DC power supply unit, part of the C-Line series, is designed with a 20% power reserve and features a DC-OK relay contact output and spring-clamp connections. It accepts a supply voltage of 85Vac-132Vac / 184Vac-264Vac with auto-selection and has a rated current of up to 12A at 24Vdc in environments below 45°C. The output voltage is adjustable between 24Vdc and 28Vdc, with minimal turn-on overshoot, and the hold time is 47ms at 230Vac input.

Puls

SL20.110

Power Supply, 480W, 100-120 / 200-240VAC 1PH, 24-28VDC, 20-18A

Puls

SL20.101

Power Supply, 480W, 200-240VAC 1PH, 24-28VDC, 20-18A with PFC

Puls

PIM90.245

Banner Engineering PIM90.245 is a fiber optic sensor designed for through-beam system applications, featuring an opposed mode probe tip for individual fiber in-line sensing. This sensor is part of the Plastic fiber series and is characterized by a cylindrical (threaded) probe tip with a diameter of 1.5mm at the end and a 1mm fiber core. It is constructed with a stainless steel sensing end and a plastic fiber with a polyethylene (PE) fiber sheath, ensuring durability and compatibility with various industrial environments. The PIM90.245 has a length of 6ft / 2m and is capable of operating in ambient air temperatures up to +70°C, making it suitable for a wide range of applications requiring precise fiber optic sensing.

Puls

SL20.100

Power Supply, 480W, 200-240VAC 1PH, 24-28VDC, 20-18A

Puls

SL2.103

Power Supply, 40W, 100-120 / 200-240VAC 1PH, 12-15VDC., 3-2.7A

Puls

PIM90.241

PULS PIM90.241 is a power supply unit designed for AC/DC conversion with a DIN rail mounting option. It operates within an ambient air temperature range of -10 to +60°C, with linear derating up to +70°C. This unit features a DC-OK relay contact output and provides a rated current of 3.8A at 24Vdc within the -10 to +60°C range, and 2.8A at 24Vdc at +70°C. It utilizes screw-clamp connections for secure installation and supports a supply voltage range of 90Vac to 264Vac across various nominal values (100Vac to 240Vac) at 47-63Hz, with an input overvoltage tolerance of 264-300Vac for up to 500ms, a turn-ON voltage of 55Vac, and a shutdown voltage of 47Vac. The PIM-series unit measures W36mm x H90mm x D91mm, has an IP20 degree of protection, and is housed in a polycarbonate (PC) material. It is designed for single-phase (1AC) networks, with a net width of 36mm. The rated power is 90W at temperatures between -10 and +60°C, and 67.2W at +70°C, with output voltage adjustable between 24Vdc and 28Vdc. Protection features include output overvoltage protection and overload/short-circuit protection. The unit is not suitable for series or parallel operation and can handle back-feeding loads up to 35V without malfunctioning. It achieves an efficiency of 0.938 at 230Vac input and 0.921 at 120Vac input, with a current consumption of 0.95A at 230Vac input at full output. The start-up delay is 50ms for 100-230Vac input, with a hold time of 119ms at 230Vac input. Power dissipation is 6W at 230Vac input with a full output load. Electrical durability is rated at up to 815000 hours at 25°C with 1.9A load and 1AC 230Vac input. The output stage capacitance is 1600µF, and the ripple is maintained at 100mVpp across a 20Hz to 20MHz range with a 50Ω load.

Puls

PIM60.245

PULS PIM60.245 is a power supply unit that functions as an AC/DC PSU/converter with DIN rail mounting. It operates within an ambient air temperature range of -10 to +60°C with linear derating up to +70°C. The design includes a NEC Class 2 DC-OK relay contact output. It provides a rated current of 5A at 12Vdc from -10 to +60°C and 3.8A at 12Vdc at +70°C, utilizing screw-clamp connections. The supply voltage (AC) ranges from 90Vac to 264Vac for various nominal voltages and frequencies, with specific input overvoltage and turn-on/shutdown voltages detailed. Part of the PIM-series, it measures W36mm x H90mm x D91mm and has an IP20 degree of protection with a polycarbonate (PC) housing. Designed for single-phase networks, it offers a rated power of 60W at -10 to +60°C and 45.6W at +70°C, with an adjustable DC output voltage of 12Vdc to 15Vdc. Protection functions include output overvoltage and overload/short-circuit current protection, with specific resistance and current values provided. The unit is resistant to back-feeding loads up to 16V. Efficiency rates are noted for 230Vac and 120Vac inputs, alongside current consumption details for various input voltages and inrush current peaks. Time delay for start-up and rise, hold time, power dissipation/losses, and electrical durability at different conditions and temperatures are specified. Ripple and capacitance values are also provided, highlighting the unit's electrical characteristics.

Puls

SL2.100

Power Supply, 60W, 100-120 / 200-240VAC 1PH, 24VDC, 2.5A

Puls

PIM60.125

PULS PIM60.125 is a power supply unit that functions as an AC/DC PSU/converter with DIN rail mounting. It operates within an ambient air temperature range of -10 to +60°C with linear derating up to +70°C. This unit features a NEC Class 2 DC-OK relay contact output and provides a rated current of 2.5A at 24Vdc within -10 to +60°C and 1.9A at 24Vdc at +70°C. It offers push-in spring connections for ease of installation. The supply voltage (AC) ranges from 90Vac to 264Vac across various nominal voltages and frequencies, with specific input overvoltage and shutdown voltage parameters. The PIM-series unit measures W36mm x H90mm x D91mm, has an IP20 degree of protection, and is housed in a polycarbonate (PC) material. Designed for single-phase (1AC) networks, it has a net width of 36 mm and delivers a rated power of 60W at -10 to +60°C, which derates linearly to 45.6W at +70°C. The output voltage (DC) is adjustable between 24Vdc and 28Vdc, with specific protection functions against overvoltage and overload/short-circuit conditions. It does not support series or parallel operation and is resistant to back-feeding loads. The efficiency rates are 0.918 and 0.907 for 230Vac and 120Vac inputs, respectively. Current consumption varies with input voltage, and the unit exhibits specific start-up delay, rise time, and hold time characteristics. Power dissipation/losses are detailed for different input conditions, and the electrical durability is specified across various operational conditions. The ripple is noted at 100mVpp, and the output stage capacitance is 900 µF.

Puls

SL10.309

Power Supply, 240W, 380-480VAC 3PH, 24-28VDC, 10-8.6A with Conformal Coating

Puls

ML60.122

PULS ML60.122 is a power supply unit (PSU) / converter designed for AC/DC applications with DIN rail mounting. It operates within an ambient air temperature range of -40 to +70°C and is designed for NEC Class 2 operation in cold environments down to -40°C. This unit has a rated current of 4.5A at 12Vdc and utilizes screw-clamp connections for connectivity. It supports a wide range of supply voltages from 85Vac to 264Vac (with specific nominal values listed) and from 88Vdc to 375Vdc, featuring a turn-ON voltage of 75Vac and a shutdown voltage of 65Vac. The ML60.122 measures 45mm in width, 75mm in height, and 91mm in depth, housed in a PC / ABS blend. It is compatible with single-phase (1AC) or DC networks, has a rated power of 54W, and offers an adjustable output voltage range of 12Vdc to 15Vdc with a 200mV turn-ON overshoot. The unit's protection functions include an active input inrush current limiter. Efficiency rates vary based on input voltage, with 0.876 at 230Vac, 0.858 at 120Vac, and 0.841 at 100Vac. It features a peak current consumption of 6A at 230Vac input, with specific time delays for start-up and rise times under different conditions. Power dissipation is noted at 7.6W, and the electrical durability is rated at a minimum of 56,000 hours at +40°C. The ripple is specified at 50mVpp across a 20Hz to 20MHz range with a 50Ω load, and the output stage capacitance is 3000µF.

Puls

PIM60.121

PULS PIM60.121 is a power supply unit that functions as an AC/DC PSU/converter with DIN rail mounting. It operates within an ambient air temperature range of -10 to +60°C, with linear derating up to +70°C, and features a NEC Class 2 DC-OK relay contact output. The unit provides a rated current of 2.5A at 24Vdc within -10 to +60°C and 1.9A at 24Vdc at +70°C, utilizing screw-clamp connections. It supports a supply voltage range of 90Vac-264Vac across various nominal voltages and frequencies, with specific input overvoltage and turn-on/shutdown voltages detailed. The PIM-series part measures W36mm x H90mm x D91mm, has an IP20 protection degree, and is housed in polycarbonate. Designed for single-phase networks, it offers a rated power of 60W at -10 to +60°C and 45.6W at +70°C, with an adjustable output voltage of 24Vdc-28Vdc. Protection functions include output overvoltage and overload/short-circuit protection, with specified current limits and conditions for back-feeding loads. The unit's efficiency rates are 0.918 and 0.907 for 230Vac and 120Vac inputs, respectively, with detailed current consumption, inrush peaks, time delay, hold time, power dissipation/losses, electrical durability, ripple, and capacitance specifications.

Puls

PIM36.241

PULS PIM36.241 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion capabilities. It operates within an ambient air temperature range of -10 to +60°C with linear derating up to +70°C. The unit is equipped with a NEC Class 2 DC-OK relay contact output and provides a rated current of 5A at 12Vdc within the -10 to +60°C range and 3.8A at 12Vdc at +70°C. Connection is facilitated through push-in spring connections. The supply voltage (AC) spans from 90Vac to 264Vac for nominal inputs like 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac at a frequency of 47-63Hz, with an input overvoltage tolerance of 264-300Vac for up to 500ms, a turn-ON voltage of 75Vac, and a shutdown voltage of 54Vac. This part of the PIM-series measures W36mm x H90mm x D91mm, has an IP20 degree of protection, and is housed in polycarbonate (PC). It supports a single-phase (1AC) network, has a net width of 36mm, and offers a rated power of 60W at -10 to +60°C, which derates linearly to 45.6W at +70°C. The output voltage (DC) is adjustable between 12Vdc and 15Vdc, with protection functions including output overvoltage protection and overload/short-circuit protection. Efficiency rates are 0.907 at 230Vac input and 0.902 at 120Vac input. Current consumption is 0.6A at 230Vac input (full output), 1A at 120Vac input (full output), and 1.15A at 100Vac input (full output), with a peak inrush of 44A at 230Vac input and 18A at 120Vac input. The unit has a start-up delay of 50-60ms, a rise time of 18ms max at nominal input with full constant current load and 0mF load capacitance, and a hold time of 107ms at 230Vac input. Power dissipation/losses are 6.2W at 230Vac input and 6.5W at 120Vac input under full output load. Electrical durability is noted at various conditions, with the highest being 724000 hours at 25°C, 2.5A, 1AC 230Vac input. Ripple is specified at 100mVpp (20Hz...20MHz; 50Ω), and the output stage capacitance is 2200µF.

Puls
